Quick Details
-
Filling Accuracy:
-
99%
-
Voltage:
-
220V/50Hz
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
HL
-
Dimension(L*W*H):
-
Length 12.2 * width 3.5* height 3.8 m
-
Weight:
-
1500 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Filling speed:
-
1500bottle/min
-
Material:
-
SS304
-
accuracy:
-
99%
-
Dimension:
-
Length 12.2 * width 3.5* height 3.8 m
Quick Details
-
Machinery Capacity:
-
2000BPH
-
Packaging Material:
-
Metal, Glass
-
Filling Material:
-
Beer, Milk, Water, Oil, Juice
-
Filling Accuracy:
-
99%
-
Voltage:
-
220V/50Hz
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
HL
-
Dimension(L*W*H):
-
Length 12.2 * width 3.5* height 3.8 m
-
Weight:
-
1500 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Filling speed:
-
1500bottle/min
-
Material:
-
SS304
-
accuracy:
-
99%
-
Dimension:
-
Length 12.2 * width 3.5* height 3.8 m
Product Description
Automatic 15000cph Can Filler And Seamer Machine Beer/Juice/cola/beverage Filling Canning Line
This project book is a preliminary plan, if there is a change in the details of the project or after the technical exchange, the technical and commercial changes shall prevail
|
Number
|
systematic name
|
Product name
|
Model
|
Qty.
|
||||
|
15000 bottles/hour can beer filling and packaging production line
|
|
|
|
|
||||
|
1.
|
Automatic Cans unloading system
|
Automatic Depalletizers
|
15000 C/H
|
1SET
|
||||
|
|
|
including cans outlet platform
|
|
|
||||
|
2
|
Cans washing system
|
Automatic Empty can spray washing machine
|
XG-150
|
1SET
|
||||
|
3.
|
Filling system
|
Automatic filling and sealing machine
|
DY50-6
|
1SET
|
||||
|
4.
|
Sterilization system
|
Pasteur spray sterilizer
|
WP-12000
|
18m
|
||||
|
5.
|
|
Plate heat exchangers
|
20㎡
|
3SETS
|
||||
|
6.
|
Drive system
|
Linear conveying
|
SS-1
|
150m
|
||||
|
7.
|
|
90° curve conveying
|
SS-2
|
10 pcs
|
||||
|
8.
|
|
Carton conveying
|
ZSS-1
|
10m
|
||||
|
9.
|
|
Power head
|
matching
|
10pcs
|
||||
|
10.
|
|
Can tipper
|
matching
|
2SETS
|
||||
|
11.
|
Automatic packing system
|
the Can body blow dry machine
|
CG-1
|
1SET
|
||||
|
|
|
Small character inkjet printer
|
laser
|
1SET
|
||||
|
|
|
Automatic carton packing machine
|
XB-25
|
1SET
|
||||
|
12.
|
|
Large character inkjet printer
|
ink
|
1SET
|
||||
|
13.
|
Palletizing winding system
|
automatic palletizer
|
MD-25
|
1SET
|
||||
|
14.
|
|
Tray conveying
|
TSS-1
|
8m
|
||||
|
15.
|
|
Automatic winding machine
|
CRJ-25
|
1SET
|
||||
|
17.
|
Auxiliary equipment
|
|
|
|
||||
|
18.
|
Low pressure screw air compressor + trachea, joint
|
Demander's responsibility (supplier can provide)
|
|
|
||||
|
19.
|
Steam boiler + steam pipe, steam filter, insulation cotton, pressure reducing valve, etc
|
Demander's responsibility (supplier can provide)
|
|
|
||||
|
20.
|
Utility piping
|
|
|
|
||||
|
21.
|
Cables, bridges, etc. between the total electrical cabinet in the demand workshop and the sub-cabinet of the supplier equipment
|
Demander's responsibility (supplier can provide)
|
|
|
||||
|
22.
|
Other description
|
|
|
|
||||
|
23.
|
Installation and commissioning cost
|
A person who goes abroad to debug is 250 US dollars a day, and the needing party is responsible for the cost of round-trip air
tickets, visas and food, accommodation and travel during commissioning。 |
|
|
||||
|
24.
|
|
The required party prepares the tools, consumables, etc. required during commissioning.
|
|
|
||||
|
25.
|
Consumables
|
Free one-year consumables are provided, after one year at cost
|
|
|
||||
Specification
Part 1- Automatic Depalletizers (including cans outlet platform)
Specification
1. Production capacity: 12000-24000 cans / hour
2. Power supply: power supply: 380V×50Hz×3
3. Air source: use pressure 6kg/cm2
4. The size of the pallet used: 1100mm × 1400mm
5. Removable maximum height: 2300mm
6. Body size: length 12.2 meters × width 3.5 meters × height 3.8 meters.
Part 2 -Empty can spray washing machine
1. Built-in ¢32mm stainless steel sprinkler pipe;
2. Reserved ¢89mmx long 1500mm stainless steel drainage pipe interface;
3. Drop tank cage 8000L, composed of ¢8mm stainless steel strip;
4. The support frame is composed of 38mm × 38mm stainless steel square tube;
5. Flushing pressure 0.25-0.3Mpa;
6. Flushing medium: purified water;
Part 3- Can tipper
The can is turned upside down
The structure is made of stainless steel strip with diameter of 8mm, and the whole process is rotated 180 degrees up and down;
(2) supporting parts are made of stainless steel.
Part 4 -
Can beer isobaric filling and sealing integrated machine
Specification
Model DY50-6
Production capacity 10000-18000 cans/hour (355ml)
The number of filling valves is 50
Number of closures: 6
Maximum filling pressure 0.5 MPa
Filling temperature 4~5°C
Compressed air pressure <0.5Mpa
Compressed air consumption 5 m³/h
Power 15kw
Dimensions 3600×2600×2365mm
Machine weight 8500kg
Part 5- Pasteur spray sterilizer
Specification
1. Sterilization treatment object: beer, juice and other beverages
2. Sterilized beverage containers: PET bottles, two-piece cans and three-piece metal cans.
3. Capacity specifications of sterilized beverages: the height is below 125mm.
4. Rated processing capacity: ≤ 18,000 cans/hour
6. Sterilization temperature: 65 °C
7. Steam pressure for production: 0.6Mpa
Part 6-the Can body blow dry
Specification
Equipment size: 1200X600X800mm
Equipment power: 11KW (two 5.5KW high-power fans)
Part 7 -ink-jet printer
Specification
1. Font dot matrix 7×6, 7×8, 8×12, 12×12, 16×16, 24×24, 5×5
2. The number of printing lines is adjustable from 1-3 lines
3. Font height 1.2-15MM adjustable
4. Printing speed 2 m/s (single line 7×6)
5. Printing direction all-round adjustment
6. Font width up to 9 times
7. Printed content Chinese, English, Arabic numerals, graphic identification, etc
8. Printing format Product batch number, number, count, Chinese and English, graphics, automatic continuous printing, delayed printing, orthography, reverse character, inverted printing and other arrangements
9. Pinyin input method, location input method, built-in full set of Chinese character library, direct dot matrix editing
10. It can be docked with the computer to achieve garbled printing
11. Can receive BMP patterns compiled by computers
12. With encoder synchronization, photoelectric synchronization, photoelectric synchronization fixed distance, online detection of N times printing function
13. Power 120W
14. Power supply 220V± 10% VAC, 50HZ
15. Ambient temperature 5-40°C
16. Ambient humidity 10%-90%RH (no condensation)
17. Dimension 530X420X290mm
18. Weight 18KG
19. Box stainless steel
Part 8- Fully automatic packing machine with paper tray film
1. Production capacity: 25 cases/min, stepless continuous adjustable
2. Productivity: about 98%
3. Glue consumption per box: 2 ~ 4G
4. Packaging form: 640ml standard bottle for 3×4 packaging or 330ml bottle for 4×6 packaging specifications
5. Applicable bottle size: Diameter 60 ~ 90mm height 120 ~ 280mm
6. Machine dimensions: Length × width × height =10400×1800×2600 (mm)
7. Compressed air pressure used by the machine: 0.4 ~ 0.6mpa air consumption :0.2nm³/min
8. Total power: 20KW
9. Machine weight: 4000K
Part 9- Robotic palletizers
Specification
Controlled axis 4 axes （A．B．C．D）
Installation Floor mount
Motion Range A（front and back）1300/1500mm
B（up and down） 2000/2300mm
C（left and right） 330°
D（tongs） 330°
Max.Load Capacity 130Kg/210Kg
Handing Capcity MAX1500/1700times／hour
Electric servo drive by AC servo motor ±0.5mm
Power Consumption 6.5KW
Weight 1300Kg
Voltage AC 220/380V, 50Hz
Power 3.5KW / 4.5KW (excluding air compressor)
0.5 0.7 Mpa pressure
Gas consumption is 0.15m3 at 1200 cases
The size of the whole machine W6000×L3500×H2200 (host size)
Carton size according to standard carton
Note: Incoming and outgoing directions are made according to the actual site of customers and drawings.
