Quick Details
-
Brand Name:
-
TBL(Silicone Potting Compund)
-
Model Number:
-
TBL-6619
-
Type:
-
Thermal potting sealant
-
Product name:
-
Silicone Potting Compund
-
Color:
-
White/Black/Gray
-
Appearance:
-
Liquid Two Component
-
Features:
-
Fast solidify; Fast surface dry
-
MOQ:
-
100KG
-
Viscosity:
-
Favorable
-
Material:
-
100% Silicone
-
Feature:
-
Bonding Strength
-
Application:
-
Sealing Construction
-
Keywords:
-
Silicone Potting Compound
Quick Details
-
CAS No.:
-
68083-19-2
-
Other Names:
-
Silicone Potting Compund
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
TBL(Silicone Potting Compund)
-
Model Number:
-
TBL-6619
-
Type:
-
Thermal potting sealant
-
Product name:
-
Silicone Potting Compund
-
Color:
-
White/Black/Gray
-
Appearance:
-
Liquid Two Component
-
Features:
-
Fast solidify; Fast surface dry
-
MOQ:
-
100KG
-
Viscosity:
-
Favorable
-
Material:
-
100% Silicone
-
Feature:
-
Bonding Strength
-
Application:
-
Sealing Construction
-
Keywords:
-
Silicone Potting Compound
Specification
|
Reference Standards
|
Property
|
Unit
|
Value
|
|||
|
Properties before curing 1 at 25±2℃
|
|
|
|
|||
|
GB/T 14074
|
Appearance (A)
|
/
|
Black
|
|||
|
|
Appearance (B)
|
/
|
White
|
|||
|
GB/T 279
|
Viscosity (A)
|
mPa.s
|
5000-6000
|
|||
|
|
Viscosity (B)
|
mPa.s
|
5000-6000
|
|||
|
GB/T 13354
|
Density (A)
|
g/cm3
|
1.65±0.1
|
|||
|
|
Density (B)
|
g/cm3
|
1.65±0.1
|
|||
|
Serviceability2 at 25±2℃
|
|
|
|
|||
|
GB/T 13477.5
|
Tack-free time at 25℃
|
min
|
15-45
|
|||
|
Enterprise Standard
|
Working Time at 25℃
|
h
|
1-3
|
|||
|
Enterprise Standard
|
Working Time at 25℃
|
min
|
15-30
|
|||
|
Properties cured 7 days3 at 25±2℃
|
|
|
|
|||
|
GB/T 531.1
|
Hardness
|
Shore A
|
50±5
|
|||
|
ASTM D5470
|
Thermal Conductivity
|
W/m.k
|
≥0.6
|
|||
|
GB/T 1695
|
Dielectric Strength
|
kV/mm
|
≥20
|
|||
|
GB/T 1693
|
Dielectric Constant
|
/
|
≥2.8
|
|||
|
GB/T 1692
|
Volume Resistivity
|
Ω·cm
|
≥1×1014
|
|||
|
Note：1 and 2 Inspection per batch. 3 regular random inspection.
|
|
|
|
|||
Product Description
TBL-6619 Thermal Potting Silicone Sealant
Thermal conductivity, Flame Retardant Black Addition
Type Potting Silicone Sealant
Product Features
Good fluidity, Easy potting
Can be cured at room temperature or under heating
UL94-V0 tested
100% Solid, no curing by-products
Working Temperature -50℃～200℃
Complies with ROHS
Typical Application
High Power Module
Controller
Inverter
Automotive Electronics Product
LED Drive Power
Note
The sealant will be delaminated during storage, and it will be stirred evenly before mixing, which will not affect the properties of the product.
