Quick Details
-
Product Name:
-
Storage Cabinet Lock
-
Size:
-
69*72.5*13.5 mm
-
Material of lock body:
-
430 Stainless Steel
-
Working voltage:
-
DC12V/DC24V
-
Working current:
-
2.4A/1.2A
-
Tensile strength:
-
240 KG
-
Warranty:
-
1 Year
-
Application:
-
Parcel delivery locker; vending machine; industrial cabinet; etc
-
Certification:
-
CE, FCC, RoHS
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
KERONG
-
Model Number:
-
KR-S99N
-
Product Name:
-
Storage Cabinet Lock
-
Size:
-
69*72.5*13.5 mm
-
Material of lock body:
-
430 Stainless Steel
-
Working voltage:
-
DC12V/DC24V
-
Working current:
-
2.4A/1.2A
-
Tensile strength:
-
240 KG
-
Warranty:
-
1 Year
-
Application:
-
Parcel delivery locker; vending machine; industrial cabinet; etc
-
Certification:
-
CE, FCC, RoHS
|
Model |
KR-S99N |
|
Brand |
KERONG |
|
Product name |
Storage Cabinet Lock |
| Size |
69*72.5*13.5 mm |
|
Weight with lock hook |
201 g |
|
Material of lock body |
430 Stainless Steel |
|
Material of lock tongue |
Zinc Alloy |
|
Surface treatment |
Passivation |
|
Usage |
storage locker; cabinet; logistic locker; vending machine ; deposit locker |
|
Door weight |
0.5KG~10KG |
|
Working voltage |
DC 12V/24V |
|
Working current |
2.4A/1.2A |
|
Maximum power |
28.8W |
|
Driven mode |
Solenoid drive |
|
Reaction time |
Less than 200ms |
|
Working temperature |
-20℃ ~ +60℃ |
|
Working humidity |
5% ~ 85%RH |
|
Working life |
500,000 times |
|
OEM |
Accepted |
|
Test |
Salt spray testing 48 hours |
|
Signal detection/ Travel switch (open/close) |
Omron (can choose other switch) |
|
Certification |
CE, FCC, RoHS |
2.Support custom wires and connectors.
3.Solenoid drive, support 12V & 24V.
4.The compact structure design leaves more space for the storage cabinet.
5.Japanese Omron switch has a long service life and detects the opening and closing of the lock.
6.Equipped with an emergency unlocking lever, which can be manually unlocked in an emergency.
7.Different lock hooks are suitable for different locker designs, and customized services can be provided.
8.Safety: The lock shell is made of 430 stainless steel, and there will be no obvious permanent deformation.
