Quick Details
-
Brand Name:
-
RT
-
Weight:
-
10 KG
-
Main material:
-
Polyester fiber (PET)
-
Filtration class:
-
G2, G3, G4 (EN779)
-
Filter object:
-
≥5μm coarse dust and foreign matter
-
Final resistance:
-
250Pa(Suggestion)
-
Average weight efficiency:
-
95%(ASHRAE52.1-1992)
-
Flammability rating:
-
F1 (DIN 53438), B1 (GB/T 17591-2006)
-
Dust holding capacity:
-
400g/m2, 500g/m2, 600g/m2
-
Temperature resistance:
-
100℃
-
Temp. short peak:
-
120℃
-
Humidity resistance:
-
100%
Quick Details
-
Core Components:
-
air filter material
-
Efficiency:
-
95%
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
RT
-
Weight:
-
10 KG
-
Main material:
-
Polyester fiber (PET)
-
Filtration class:
-
G2, G3, G4 (EN779)
-
Filter object:
-
≥5μm coarse dust and foreign matter
-
Final resistance:
-
250Pa(Suggestion)
-
Average weight efficiency:
-
95%(ASHRAE52.1-1992)
-
Flammability rating:
-
F1 (DIN 53438), B1 (GB/T 17591-2006)
-
Dust holding capacity:
-
400g/m2, 500g/m2, 600g/m2
-
Temperature resistance:
-
100℃
-
Temp. short peak:
-
120℃
-
Humidity resistance:
-
100%
Application :
Suitable for pre-filtration of various ventilation systems, air-conditioning systems, and dust removal systems;
F eature s:
Resistant to fracture, high elasticity;
Step by step encryption of filter fibers and stratified filtration
Large dust holding capacity and stable performance;
Long service life;
Silicone-free;
Available to supply in cut pad or rolls;
Washable.
Technical Parameters
|
Main material |
Polyester fiber( PET ) |
|
Filtration class |
G2, G3 , G4(EN779) |
|
Filter object |
≥5μm coarse dust and foreign matter |
|
Final resistance |
250Pa(Suggestion) |
|
Average weight efficiency |
95%(ASHRAE52.1-1992) |
|
Flammability rating |
F1(DIN 53438), B1(GB/T 17591-2006) |
|
Dust holding capacity |
400g/m2 , 500g/m2 , 600g/m2 |
|
Temperature resistance |
100 ℃ |
|
Temp. short peak |
120℃ |
|
Humidity resistance |
100% |
Specification:
|
Model |
Filtration class |
Thickness ( mm ) |
Weight ( g/m 2 ) |
I.N.P (Pa) |
Rated air velocity ( m/s) |
CMH |
|
RT-C05 |
G2 |
5 |
120 |
15 |
1.5 |
5400 |
|
RT-C10 |
G3 |
10 |
150 |
18 |
1.5 |
5400 |
|
RT-C15 |
G4 |
15 |
180 |
22 |
1.5 |
5400 |
|
RT-C20 |
G4 |
20 |
220 |
28 |
1.5 |
5400 |
|
RT-C22 |
G4 |
22 |
250 |
30 |
1.5 |
5400 |
