Quick Details
-
Weight (KG):
-
800 KG
-
Max.Working Width(mm):
-
914mm
-
Cutting capacity:
-
910x380x4800mm (36"x15"x188")
-
Frame:
-
4pcs
-
Product name:
-
sawmill
-
Function:
-
Cutting Logs
-
Motor Power:
-
27HP
-
Weight:
-
760KG
-
After-sales Service Provided:
-
Online support
-
After Warranty Service:
-
Video technical support
-
Showroom Location:
-
None
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
Wemax
-
Application:
-
DIY
-
Weight (KG):
-
800 KG
-
Max.Working Width(mm):
-
914mm
-
Cutting capacity:
-
910x380x4800mm (36"x15"x188")
-
Frame:
-
4pcs
-
Product name:
-
sawmill
-
Function:
-
Cutting Logs
-
Motor Power:
-
27HP
-
Weight:
-
760KG
-
After-sales Service Provided:
-
Online support
-
After Warranty Service:
-
Video technical support
-
Showroom Location:
-
None
Application:
it is suitable for the scale production of sawmill and is widely used in wood processing in the original forest area.
Features:
1.hand forward and backward,hand lifting.
2.Power is gasoline engine and electric motor
3.Sawing hard wood customer recommends the use of STARRETT BRAND
Advantage:
1.The machine has the features of high cutting speed,high cutting rate,high quality of final product,great reduce the lost of sawdust.
2.It is simple installation, easy operation, labor saving , and high productivity.
3.simple , safe and pro-environment;
4.Automatic control the timber thickness, high-precision.
5.High cutting efficiency, smooth; high flatness of the cutting plate;
6,The thickness of processing wood can be adjusted according to your need
7.There's no need the professional sawyers, the ordinary workers can operate the machine expertly.
|
Model |
RS3 6 G |
RS3 6 E |
|
Power |
Gasoline 27 HP(L ONCIN , Electric start) |
Electric M otor 11 KW |
|
Displacement |
764cc |
400V 50HZ 3phase |
|
Cutting capacity |
910x380x4800 mm ( 36 ” x15 ” x 1 88 ”) |
910x380x4794 mm ( 36 ” x15 ” x 1 88 ”) |
|
Frame |
4pcs |
4pcs |
|
Blade size |
4576x40x0.9 mm (1 80 ” x 1 -1/2 ” x 0.0 35 ”) Carbide 208 teeth |
4576x40x0.9 mm (1 80 ” x 1 -1/2 ” x 0.0 35 ”) Carbide 208 teeth |
|
Standard t rack size |
6000x1010mm (236 ” x40 ” ) |
6000x1010mm (236 ” x40 ” ) |
|
Safe cutting Speed |
20-30 s/m |
20-30 s/m |
|
Distance teeth |
22mm (0.86”) |
22mm (0.86”) |
|
Blade Wheel Dia. |
508 mm ( 20 ”) |
508 mm ( 20 ”) |
|
Blad e auto lube system |
Yes |
No |
|
Adjustable blade guide |
Yes |
Yes |
|
Quick lock log clamp |
Yes |
Yes |
|
Packing |
2080x75 0 x105 0mm |
2080x75 0 x95 0mm |
|
Weight |
722 / 782 kg |
761 / 821 kg |
