Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
WEIHANG
-
Model Number:
-
PCT-222
-
Keywords:
-
Electric Wire Connector
-
Item:
-
PCT-222
-
Modle:
-
PCT-222/PCT-223/PCT-224/PCT-225
-
Color:
-
Grey
-
Certificate:
-
CE ROHS
-
Material:
-
PA66
-
Rated Voltage:
-
250V
-
Rated Current:
-
32A
-
MOQ:
-
100pcs
-
Market:
-
Global
Quick Details
-
Type:
-
Connector
-
Application:
-
Power
-
Gender:
-
Female/Male
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
WEIHANG
-
Model Number:
-
PCT-222
-
Keywords:
-
Electric Wire Connector
-
Item:
-
PCT-222
-
Modle:
-
PCT-222/PCT-223/PCT-224/PCT-225
-
Color:
-
Grey
-
Certificate:
-
CE ROHS
-
Material:
-
PA66
-
Rated Voltage:
-
250V
-
Rated Current:
-
32A
-
MOQ:
-
100pcs
-
Market:
-
Global
Product Description
Product raw materials
The product adopts PA engineering plastic, which is not easily deformed or discolored, and the shell is flame retardant and
high-temperature resistant！
The product adopts PA engineering plastic, which is not easily deformed or discolored, and the shell is flame retardant and
high-temperature resistant！
Specification
|
Model Number
|
PCT-222
|
PCT-223
|
PCT-224
|
PCT-225
|
|
No of circuits
|
2P
|
6P
|
8P
|
3P
|
|
Wire Section
|
0.08-2.5mm²（single hard conductor）
|
0.08-2.5mm²（single hard conductor）
|
0.08-2.5mm²（single hard conductor）
|
0.08-2.5mm²（single hard conductor）
|
|
|
0.08-4mm²（Stranded flexible conductor）
|
0.08-4mm²（Stranded flexible conductor）
|
0.08-4mm²（Stranded flexible conductor）
|
0.08-4mm²（Stranded flexible conductor）
|
|
Material
|
PA66
|
PA66
|
PA66
|
PA66
|
|
Material of Contact
|
Copper
|
Copper
|
Copper
|
Copper
|
|
Rated Voltage
|
400V
|
400V
|
400V
|
400V
|
|
Rated Current
|
32A
|
32A
|
24A
|
24A
|
|
Packing
|
50PCS/Bag,2500PCS/CTN
|
50PCS/Bag,2500PCS/CTN
|
100PCS/Bag,5000PCS/CTN
|
100PCS/Bag,5000PCS/CTN
|
|
Certificate
|
CE Rohs
|
CE Rohs
|
CE Rohs
|
CE Rohs
|
|
Logo&Color
|
Can be customized
|
Can be customized
|
Can be customized
|
Can be customized
|
|
Product Size
|
38.2*12.5*13.2mm
|
38.2*17.8*13.2mm
|
38.2*23.7*13.2mm
|
39.2*28.6*14.6mm
|
