Quick Details
-
Brand Name:
-
Jingxinlong
-
Fork Length:
-
1150mm
-
Fork Width:
-
155
-
Overall Dimensions:
-
1570*786*1597mm
-
Weight (KG):
-
280 kg
-
Product Name:
-
Electric Pallet Truck
-
Certification:
-
ISO
Quick Details
-
Min. Lifting Height:
-
90mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Jingxinlong
-
Fork Length:
-
1150mm
-
Fork Width:
-
155
-
Overall Dimensions:
-
1570*786*1597mm
-
Weight (KG):
-
280 kg
-
Product Name:
-
Electric Pallet Truck
-
Certification:
-
ISO
who are we?
A Chinese factory specializing in the production of forklifts, hydraulic pallet trucks, stackers, lifting platforms, etc.
Click here get fr
Free Custom Gifts
| capacity | kg | 500 | 500 | 500 |
| loading center | mm | 400 | 400 | 400 |
| wheelbase | mm | 860 | 860 | 860 |
| front wheel distance | mm | 380 | 380 | 380 |
| rear track | mm | 670 | 670 | 670 |
| min.fork height | mm | 90 | 90 | 90 |
| max.fork height | mm | 800 | 1000 | 1300 |
| steeling wheel | mm | Φ100x45 | Φ100x45 | Φ100x45 |
| loading wheel | mm | Φ70x60 | Φ70x60 | Φ70x60 |
| overall lenghth | mm | 1600 | 1600 | 1600 |
| overall width | mm | 780 | 780 | 780 |
| fork size | mm | 1150*540 | 1150*540 | 1150*540 |
| forkwidth | mm | 535 | 535 | 535 |
| turning radius | mm | 1100 | 1200 | 1200 |
| lifting speed | mm/s | 80 | 80 | 80 |
| descent speed | mm/s | 90 | 90 | 90 |
| lifting motor power | kw | 12v/0.8 | 12v/0.8 | 12v/0.8 |
| battery | V/AH | 12/45 | 12/45 | 12/45 |
| type of driving | pedestrian | pedestrian | pedestrian | |
| material of wheel | Polyurethane | Polyurethane | Polyurethane | |
| net weight | kg | 243 | 250 | 265 |
