Quick Details
-
Application:
-
Home Gate
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
Giant or OEM
-
Model Number:
-
PKM-C01-L
-
Type:
-
Automatic Door Operators
-
Product Name:
-
swing arms motor operator
-
Power supply:
-
~220V(+10%)/50Hz
-
Current:
-
5A
-
Electric Motor Power:
-
24V 40W*2
-
Max Single-leave Length:
-
2
-
Max Single-leave Weight:
-
150KG
-
Max Stroke:
-
300mm
-
Motor Speed:
-
250RPM
-
Working Life:
-
At least 48,000 times open/close
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support, Return and Replacement
-
Project Solution Capability:
-
Others
-
Application:
-
Home Gate
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
Giant or OEM
-
Model Number:
-
PKM-C01-L
-
Type:
-
Automatic Door Operators
-
Product Name:
-
swing arms motor operator
-
Power supply:
-
~220V(+10%)/50Hz
-
Current:
-
5A
-
Electric Motor Power:
-
24V 40W*2
-
Max Single-leave Length:
-
2
-
Max Single-leave Weight:
-
150KG
-
Max Stroke:
-
300mm
-
Motor Speed:
-
250RPM
-
Working Life:
-
At least 48,000 times open/close
Features
1.DC24V Low voltage motor that is safe and compatible with back up power supply.
2.Metal pinion gear driving design with low working noise.
3.Manual release with secure customized key in case of power failure.
4.Soft start , soft stop.
5.Adjust opening/Closing interval time of double gate leaves.
6.Auto-Stop if any obstacles detected during operation.
7.Built-in max motor running time adjustable for multiple safety protection.
8.Separately adjust the force of double gate leaves.
9.Single Leaf of double leaves operation.
10.Easy installation and low maintenance.
11.12 months guarantee, Lifelong post sales services.
Technical Data
| Power Supply | 220V/110V |
| Motor Power | 24VDC 40W*2 |
| Current | 5A |
| Motor Speed | 250RPM |
| Actuator Running Speed | 1.6CM/S |
| Actuator Stroke | 300MM |
| Max Single leaf Width | 2M |
| Max Single leaf Weight | 150KG |
| Working Temperature | -20~50℃ |
| Protection Class | IP55 |
