Quick Details
-
Dimension(L*W*H):
-
1450*1000*1500mm
-
Weight:
-
600 KG
-
Machinery Function:
-
bone crusher
-
Type:
-
Meat Processing Machinery
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Name:
-
bone crusher machine
-
Power of bone cutter:
-
11-15kw
-
Size of bone cutter:
-
130*100*155cm
-
Function:
-
Crush many kinds of bones
-
Material:
-
SS304
-
Feature:
-
High Efficiency Easy Operation
-
Processing:
-
Bone crushing
-
Application:
-
animal bones
Quick Details
-
Brand Name:
-
TAIZY
-
Place of Origin:
-
Henan, China
-
Power:
-
11kw
-
Dimension(L*W*H):
-
1450*1000*1500mm
-
Weight:
-
600 KG
-
Machinery Function:
-
bone crusher
-
Type:
-
Meat Processing Machinery
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Name:
-
bone crusher machine
-
Power of bone cutter:
-
11-15kw
-
Size of bone cutter:
-
130*100*155cm
-
Function:
-
Crush many kinds of bones
-
Material:
-
SS304
-
Feature:
-
High Efficiency Easy Operation
-
Processing:
-
Bone crushing
-
Application:
-
animal bones
High Quality Multifunctional Bone Crusher Machine
*FEATURES OF BONE CRUSHER:
Bone Crusher machine
1. Partical size is adjustable
2. Both stainless steel and carbon steel are available
3. Suitable for crushing many kinds of bones
4. Compact structure and stable operation
*INTRODUCTION OF BONE CRUSHER:
The bone crusher is a high efficiency grinding equipment with newest technology. The principle of the bone crushing machine’s operation and work is vertical type. So, it has many advantages of running fast, not hot, convenient operation and washing.
The blade installation of the bone crushing machine can be adjusted. The blade also can be sharpened while it is blunt.
This machine can be used together with the conveyor belt, the automation in and out of the material, and reduce the dynamic strength. This machine has simple operation, convenient maintenance cleaning, compact structure, stable work, production, low temperature, don't hide materials, particle size adjustable etc.
Crushing range: 5-800mm
*SPECIFICATION OF BONE CRUSHER:
|
Model |
Capacity kg |
Feed diameter mm |
Power kw |
Size mm |
|
TZ-150 |
20-60 |
150*200 |
2.2 |
450*720*900 |
|
TZ-230 |
30-100 |
250*210 |
4 |
1000*700*1260 |
|
TZ-300 |
80-200 |
300*210 |
5.5 |
1200*820*1160 |
|
TZ-400 |
150-400 |
380*250 |
7.5 |
1080*820*1330 |
|
TZ-500 |
200-600 |
500*250 |
11-15 |
1700*1350*1760 |
|
TZ-600 |
300-900 |
600*320 |
22-30 |
1700*1480*1760 |
|
TZ-700 |
500-1500 |
700*480 |
37-45 |
2000*1600*2000 |
|
TZ-800 |
800-2200 |
800*650 |
55 |
1600*2100*2620 |
|
TZ-1000 |
1000-4000 |
1000*800 |
75 |
1800*2100*3115 |
