payload 300kg working temperature -20~55 4 Extended Controllable Channel teleoperated wheel robot tank
payload 300kg working temperature -20~55 4 Extended Controllable Channel teleoperated wheel robot tank
payload 300kg working temperature -20~55 4 Extended Controllable Channel teleoperated wheel robot tank
payload 300kg working temperature -20~55 4 Extended Controllable Channel teleoperated wheel robot tank
payload 300kg working temperature -20~55 4 Extended Controllable Channel teleoperated wheel robot tank
payload 300kg working temperature -20~55 4 Extended Controllable Channel teleoperated wheel robot tank
payload 300kg working temperature -20~55 4 Extended Controllable Channel teleoperated wheel robot tank
payload 300kg working temperature -20~55 4 Extended Controllable Channel teleoperated wheel robot tank

payload 300kg working temperature -20~55 4 Extended Controllable Channel teleoperated wheel robot tank

FOB Reference Price: Get Latest Price
≥1 Sets
US $1300
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Product Name:
Remote control track chassis
Application:
Industrial Filed
Material:
Iron
Function:
Conveying Goods
Size:
900*920*580mm
Capacity:
300kg
Control Method:
Remote Control
Color:
Yellow
Usage:
Unloading Cargo
MOQ:
1 Set

Quick Details

Marketing Type:
Hot Product 2023
Place of Origin:
Shandong, China
Brand Name:
VIGORUN
Product Name:
Remote control track chassis
Application:
Industrial Filed
Material:
Iron
Function:
Conveying Goods
Size:
900*920*580mm
Capacity:
300kg
Control Method:
Remote Control
Color:
Yellow
Usage:
Unloading Cargo
MOQ:
1 Set
Product Paramenters
Model
RRB300
RTC300
Walking Speed
0-6km/h
0-4km/h
Working Temperature
-20~55°
-20~55°
Remote Control Range
200m
200m
Walking Motor
Motor Type
Brush electric traction
Brush electric traction
Voltage / Power
24V / 350W
24V / 1000W
Reduction Ratio
23.2:1
30:1
Rotating Speed
75RPM
80RPM
Output Torque
55Nm
80Nm
Wheel
15X6.00-6 vacuum tire
/
Rubber Track
Width
/
150mm
Pitch
/
60mm
Links
/
32
Driving Wheel
Pitch
/
60mm
Tooth number
/
11
Battery
24V 20Ah
24V 20Ah
Remote Control Channel
7
7
Extended Controllable Channel
4
4
Max Payload
300kg
300kg
Wheelbase/Truck Bed
810mm
695*595*175mm
Track
890mm
/
Overlay Panel
990*625mm
/
Machine Size
1070*1035*430mm
900*920*580mm
Machine Weight
98kg
113kg
Package Size
1150*1120*600mm
980*1000*750mm
Gross Weight
130kg
145kg
Key Components

Frame

The frame of the fuselage is reinforced to prevent deformation and displacement. The bottom of the fuselage is reinforced to carry heavy loads.

Tires

The tires are lawn tires with a width of 15cm, which are beautiful, durable, large in width and strong in support.

Track

The track is 15cm wide and capable of working in muddy, rough, and sloping environments.

Emergency Stop Button

It serves as a safety mechanism that allows for the immediate and abrupt stopping of a system or machinery. When pressed, this button activates an emergency braking system, which triggers a rapid and forceful cessation of the operation.

Motor Controller

It adopts the mature walking motor controller on our remote control lawn mower, which has the characteristics of sensitive response and fast response speed.

Function Expansion HUB

The function expansion HUB can control additional 4 channels. It can easily control and expand other functions required by customers without professional remote control knowledge.
Features

1) Beautiful The remote control chain chassis is beautiful in appearance. The fuselage is large, and the space reserved for development is sufficient.
2) Strong
The bottom of the fuselage is reinforced to carry heavy loads. The installation position of the travel motor has also been reinforced to prevent deformation and displacement.
3) Mature technology
This product is modified on the basis of our very mature remote control lawn mower, an economical chassis product. The built-in smart chip can intelligently detect the current and heating conditions, which can ensure stable use all year round.
4) Scalability
On the basis of our chassis, you can freely add other functional modules to create a new vehicle that meets your own needs.
