Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Sanjing
-
Model Number:
-
P01
-
Product name:
-
tempered room office wall glass partition prices price
-
Material:
-
tempered room office wall glass partition prices price
-
Color:
-
Customized
-
Style:
-
Modern Workstation
-
Size:
-
Customized Size
-
Service:
-
Customized Service
-
Certificate:
-
ISO9001/ISO14001/ISO18001/TUV
Quick Details
-
Application:
-
Courtyard, Leisure Facilities, Supermarket, Farmhouse, Laundry, Workshop, Kitchen, School, Bathroom, Babies and kids, Bedroom, Exterior, Dining, Warehouse, Home Office, Staircase, Outdoor, Living Room, Park, Wine Cellar, Office Building, Storage & Closet, Gym, Mall, Entry, Apartment, Sports Venues, Basement, Hospital, Villa, Hotel, Home Bar, Hall, Garage & Shed
-
Usage:
-
Industrial, Decoration, Solar, Greenhouse, Curtain Wall, Balustrades & Handrails, Image formation, Lighting, Bulletproof, Display screen
-
Thickness:
-
3mm-30mm
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Sanjing
-
Model Number:
-
P01
-
Product name:
-
tempered room office wall glass partition prices price
-
Material:
-
tempered room office wall glass partition prices price
-
Color:
-
Customized
-
Style:
-
Modern Workstation
-
Size:
-
Customized Size
-
Service:
-
Customized Service
-
Certificate:
-
ISO9001/ISO14001/ISO18001/TUV
half interior aluminum frosted tempered room office wall glass partition prices price
Glass partition offer an advantage with which drywall simply cannot compete.
The additional advantages of incorporating glass partition wall into an office floor plan, are in-part responsible for their rapidly increasing popularity with office interior designers. Increased affordability is another. A glass alternative to drywall will never go out of style and will provide a modern look that will convey a unique office aesthetic, much the same as you would want for your reception area.
|
|
||||
|
TYPE |
NG-28 |
NG-90 |
NG-100 |
NG-108 |
|
Panel suspension |
Non-loadbearing floor to ceiling system based on an aluminum framework with sound reducing panels, erected in a combination of single OR double glazed panels. |
|||
|
Track system |
head and floor channel |
head and floor channel |
head and floor channel |
head and floor channel |
|
Thickness |
28MM |
90MM |
100MM |
108MM |
|
Application height |
2.8M |
3.6M |
3.8M |
3.8M |
|
Max height |
3.0M |
3.8M |
4.0M |
4.0M |
|
Panel width |
<=1200MM |
<=1400MM |
<=1500MM |
<=1500MM |
|
Framework |
A pre-finished 1.4-2.0mm thickness aluminum head and floor channel. |
|||
|
Inner framework |
n/a |
1.0-1.2mm thickness galvanized steel keel |
||
|
Face material |
10MM single toughened glass |
6mm+78+6mm double toughened glass. Shutter as option |
6mm+78+6mm double toughened glass. Shutter as option |
6mm+78+6mm double toughened glass. Shutter as option |
|
Finishing |
Stain anodized or polyester power coating to all exposed aluminum components available in a wide range of colors as standard |
|||
|
Fire safety |
0.E30.EI60 |
0.E30.EI60 |
0.E30.EI60 |
0.E30.EI60 |
|
Tolerance |
±5 |
±5 |
±5 |
±5 |
|
Door unites |
A combination of style is available. Standard or full height frames in aluminum or timber fitted
|
|||
|
Locking |
Optional lock |
|||
|
Sound insulation |
35dB,43dB |
44dB,52dB |
44dB,52dB |
44dB,52dB |
We do better understand office glass partition !
Our wall partition is customized, the cost is calculated by area, the thickness of different walls and the price of various finishes are different. Therefore, we need you to provide detailed dimensions such as height width and finish requirements to get a quote. If possible, give me your layout!
You can customize office partition walls color, edge processing, thickness
Sizes are produced per customer request, once tempered, cannot be cut down. Other related product
About Measur office partition glass wall
- Measuring the site. In order for any room glass partition to be useful, the plan must carefully take into consideration the exact range of height between floor and ceiling,
- Determining ceiling type. tempered glass partition wall cannot be properly anchored to the existing ceiling without knowing in advance what it was constructed from, such as drywall, ceiling tile, or something else.
- Determining wall modularity. We take careful measurement of wall elevations, in respect to glazing, door, and solid wall segments.
- Knowing what type of flooring has been installed also plays a role, as floor coverings such as carpeting, tile, or other flooring requires the use of different anchors for typical frosted glass partition
- Reviewing door configurations and how they will affect the interior glass partition
- Assessing electrical, data, and communication needs.
- If you have any question,please let me know!
-
Packaging
Plywood Crate
Shipping
EXW or FOB Qingdao or CIF
Payment
TT/Trade Assurance/LC , 30% deposit
Delivery Time
According to clients's requirements
