Quick Details
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Ground Mounting
-
Certificate:
-
TUV, VDE-AR-N 4105, VDE 0126, VDE,EN 50549-1:2019,VFR 2019, IEC/EN 62109-1/-2,IEC
-
Warranty:
-
25 Years
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Lovsun
-
Model Number:
-
400W Solar Kit
-
Load Power (W):
-
400w
-
Output Voltage (V):
-
220/230/240 V
-
Output Frequency:
-
50/60 HZ
-
Work Time (h):
-
24 hours
-
Max Input Voltage:
-
60Vdc
-
Max Input Current:
-
11.5
-
Rated Output Current:
-
1.59/1.52/1.46
-
Nominal Output Voltage:
-
220/230/240v
-
Type:
-
DC/AC Inverters
-
Displacement power factor:
-
0.8 leading to 0.8 lagging
-
Max DC Input Current (Adc):
-
12A X 2
-
Night Time Tare Loss (Wp):
-
0.11
-
Product name:
-
800W balcony solar energy system
Quick Details
-
Application:
-
Home
-
Solar Panel Type:
-
Monocrystalline Silicon
-
Battery Type:
-
NONE
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Ground Mounting
-
Certificate:
-
TUV, VDE-AR-N 4105, VDE 0126, VDE,EN 50549-1:2019,VFR 2019, IEC/EN 62109-1/-2,IEC
-
Warranty:
-
25 Years
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Lovsun
-
Model Number:
-
400W Solar Kit
-
Load Power (W):
-
400w
-
Output Voltage (V):
-
220/230/240 V
-
Output Frequency:
-
50/60 HZ
-
Work Time (h):
-
24 hours
-
Max Input Voltage:
-
60Vdc
-
Max Input Current:
-
11.5
-
Rated Output Current:
-
1.59/1.52/1.46
-
Nominal Output Voltage:
-
220/230/240v
-
Type:
-
DC/AC Inverters
-
Displacement power factor:
-
0.8 leading to 0.8 lagging
-
Max DC Input Current (Adc):
-
12A X 2
-
Night Time Tare Loss (Wp):
-
0.11
-
Product name:
-
800W balcony solar energy system
Product Description
Technical Specifications
|
Input Data(DC)
|
|
|
|
Commonly used module power(Wp)
|
280～470
|
|
|
Module compatibility
|
60-cell or72-cell PV modules
|
|
|
Peak power MPPT voltage range(V)
|
33～48
|
|
|
Start-up voltage(V)
|
22
|
|
|
Perating voltage range(V)
|
16～60
|
|
|
Maximum input voltage(V)
|
60
|
|
|
Maximum input current(A)
|
11.5
|
|
|
Maximum input short circuit current(A)
|
15
|
|
|
Output Data(AC)
|
|
|
|
Rated output power(VA)
|
350
|
|
|
Rated output current (A)
|
1.59/1.52/1.46
|
|
|
Nominal output voltage(V
|
220/230/240①
|
|
|
Nominal frequency(Hz)
|
50/60①
|
|
|
Displacement power factor
|
0.8 leading to 0.8lagging
|
|
|
Total harmonic distortion
|
<3%
|
|
|
Maximum units per branch(10AWG)
|
18/19/20
|
|
|
Efficiency
|
|
|
|
CEC peak efficiency
|
96.70%
|
|
|
CEC weighted efficiency
|
96.50%
|
|
|
Nomia MPPTefincy
|
99.80%
|
|
|
Nominal power consumption(mW)
|
< 50
|
|
|
Mechanical Data
|
|
|
|
Ambient temperature range(℃)
|
-40～+65
|
|
|
Dimensions(WxHxD mm)
|
184.5×204.5×26
|
|
|
Weight(kg)
|
1.7
|
|
|
Fnclosure rating
|
Outdoor-NEMA(IP 67)
|
|
|
Ccolng
|
Natural convection
|
|
|
Features
|
|
|
|
Communication
|
2.4G Hz Proprietary RF(Nordic)
|
|
|
Monitoring
|
Sofia Pro Cloud②
|
|
|
Compliance
|
VDE-R-N 4105:2018,EN 50549-1:2019,VFR 2019,
IEC/EN 62109-1/-2,IEC/EN 61000-6-1/-2/-3/-4.IEC/EN 61000-3-2/-3 |
|
Monitoring & Controlling
Pack&shipping
Delivery & Payment Terms
|
Payment Terms
|
T/T
|
EXW
|
30% in advance for deposit payment, the balance payments will be paid before shipment.
|
|
|||
|
|
|
FOB
|
|
|
|||
|
|
|
CFR/C&F
|
30% in advance for deposit payment, the balance will be paid against copy of B/L
|
|
|||
|
|
|
CIF
|
|
|
|||
|
|
L/C
|
Optional for the amount of above 50,000 usd, L/C at sight is acceptable.
|
|
|
|||
|
|
West Union
|
|
|
|
|||
|
|
Paypal
|
|
|
|
|||
|
Delivery Time
|
7~15 days after receiving the payment or the deposit payment
|
|
|
|
|||
We recommend you use alibaba Insurance Order Online, you will enjoy
Products quality protection
On time shipment
Payment safety protection
The third party inspection is optional
