Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
PANPOWER
-
Model Number:
-
WSYT
-
Input Voltage:
-
220VAC
-
Output Voltage:
-
110V/120V/220V/230V/240V
-
Output Frequency:
-
50/60Hz
-
Size:
-
460*235*200mm
-
Certificate:
-
CE TUV
-
Warranty:
-
12 months
-
Weight:
-
9kg~27.5kg
-
Display:
-
LCD
-
Waveform:
-
Pure sine wave
-
Rated power:
-
1KW~7KW
-
Application:
-
Home Appliance
-
Color:
-
Blue/Green/Orange/Other
-
OEM:
-
Accept OEM Logo
-
MPPT:
-
Acceptale
-
Package:
-
Wooden case
-
Protection:
-
Overload
-
Battery type:
-
12V/24V
Quick Details
-
Output Type:
-
Single
-
Type:
-
DC/AC Inverters
-
Inverter Efficiency:
-
≥89%
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
PANPOWER
-
Model Number:
-
WSYT
-
Input Voltage:
-
220VAC
-
Output Voltage:
-
110V/120V/220V/230V/240V
-
Output Frequency:
-
50/60Hz
-
Size:
-
460*235*200mm
-
Certificate:
-
CE TUV
-
Warranty:
-
12 months
-
Weight:
-
9kg~27.5kg
-
Display:
-
LCD
-
Waveform:
-
Pure sine wave
-
Rated power:
-
1KW~7KW
-
Application:
-
Home Appliance
-
Color:
-
Blue/Green/Orange/Other
-
OEM:
-
Accept OEM Logo
-
MPPT:
-
Acceptale
-
Package:
-
Wooden case
-
Protection:
-
Overload
-
Battery type:
-
12V/24V
Main Features
* Type: Low frequency with transformer;
* Power: 1KW~7KW;
* DC voltage: 12V/24V/36V/48V;
* AC output voltage: 110V/120V/220V/230V/240V;
* Frequency: 50/60Hz auto;
* Pure sine wave & AVR output;
* With internal PWM solar charger controller;
* Selectable charging current based on applications；
* Configurable AC/Solar input priority via LCD setting;
* Compatible to mains voltage or generator power;
* Can with communication RS232/USB/SNMP/Wifi；
* Smart battery charger design to optimize battery performance;
* Stable performance, safe and reliable, long service life.
* Power: 1KW~7KW;
* DC voltage: 12V/24V/36V/48V;
* AC output voltage: 110V/120V/220V/230V/240V;
* Frequency: 50/60Hz auto;
* Pure sine wave & AVR output;
* With internal PWM solar charger controller;
* Selectable charging current based on applications；
* Configurable AC/Solar input priority via LCD setting;
* Compatible to mains voltage or generator power;
* Can with communication RS232/USB/SNMP/Wifi；
* Smart battery charger design to optimize battery performance;
* Stable performance, safe and reliable, long service life.
System Diagram
Product Paramenters
|
Model
|
WSYT1K
|
WSYT1.5K
|
WSYT2K
|
WSYT3K
|
WSYT4K
|
WSYT5K
|
WSYT6K
|
WSYT7K
|
||||||||
|
Rated power
|
1KW
|
1.5KW
|
2KW
|
3KW
|
4KW
|
5KW
|
6KW
|
7KW
|
||||||||
|
Surge power
|
3KW
|
4.5KW
|
6KW
|
9KW
|
12KW
|
15KW
|
18KW
|
21KW
|
||||||||
|
AC Input & Output
|
|
|
|
|
|
|
|
|
||||||||
|
Voltage
|
220VAC
|
|
|
|
|
|
|
|
||||||||
|
Selectable Voltage Range
|
145-275VAC (220VAC)
|
|
165-275VAC (220VAC)
|
|
|
|
|
|
||||||||
|
Frequency Range
|
50Hz/60Hz automatic recognition
|
|
|
|
|
|
|
|
||||||||
|
AC Voltage Regulation
|
220vac±2% (DC Batt. mode)
|
|
|
|
|
|
|
|
||||||||
|
Transfer Time
|
≤4ms
|
|
|
|
|
|
|
|
||||||||
|
Wave Form
|
Pure Sine Wave
|
|
|
|
|
|
|
|
||||||||
|
Transformer type
|
Toroidal or EI
|
|
|
|
|
|
EI
|
|
||||||||
|
Transfer efficiency
|
≥89%（full load）
|
|
|
|
|
|
≥87%（full load）
|
|
||||||||
|
Battery
|
|
|
|
|
|
|
|
|
||||||||
|
Battery Voltage
|
12V/24V
|
|
12V/24V/48V
|
|
24V/
48V
|
48V
|
|
|
||||||||
|
Type
|
Gel/SLA/AGM/Water/Lithium(lifepo4) Battery
|
|
|
|
|
|
|
|
||||||||
|
DC Charge Voltage
|
12~16VDC (12V)/20~32VDC (24V)/40~64VDC (48V)
|
|
|
|
|
|
|
|
||||||||
|
Overcharge Protection
|
Battery voltage ≧16VDC (12V) ≧32VDC (24V) ≧64VDC (48V)
|
|
|
|
|
|
|
|
||||||||
|
Solar Charge & Ac Charger
|
|
|
|
|
|
|
|
|
||||||||
|
Maximum PV Array Open Circuit Voltage
|
100VDC
|
|
|
|
|
|
|
|
||||||||
|
Maximum Pv Array Power
|
720W
|
720W
|
2400W
|
2400W
|
2880W
|
|
|
|
||||||||
|
Maximum Ac Charge Current
|
5A~30A(adjustable)
|
|
|
|
|
|
|
|
||||||||
|
Maximum Solar Charge Current（PWM）
|
30A
|
|
50A
|
|
60A
|
|
|
|
||||||||
|
Maximum Charging Current
|
60A
|
|
80A
|
|
90A
|
|
|
|
||||||||
|
Working mode
|
|
|
|
|
|
|
|
|
||||||||
|
01 mode
|
AC mains priority mode（ups）
|
|
|
|
|
|
|
|
||||||||
|
02 mode
|
ECO mode（ups）
|
|
|
|
|
|
|
|
||||||||
|
03 mode
|
DC battery priority mode（solar inverter）
|
|
|
|
|
|
|
|
||||||||
|
Communication Port(optional)
|
|
|
|
|
|
|
|
|
||||||||
|
Type
|
USB/RS232/ RS485/SNMP/Wifi（optional）
|
|
|
|
|
|
|
|
||||||||
|
Physical
|
|
|
|
|
|
|
|
|
||||||||
|
Dimension, D*W*H(MM)
|
460*235*200
|
|
|
|
580*335*200
|
|
|
|
||||||||
|
N.W.(KGS)
|
9
|
9.5
|
18
|
21
|
27.5
|
32
|
35
|
40
|
||||||||
|
Environment
|
|
|
|
|
|
|
|
|
||||||||
|
Humidity
|
0~95%（NO CONDESNSATION)
|
|
|
|
|
|
|
|
||||||||
|
Operating Temperature
|
0~60℃
|
|
|
|
|
|
|
|
||||||||
|
Storage Temperature
|
0~60℃
|
|
|
|
|
|
|
|
||||||||
|
*Product Specifications Are Subject To Change Without Further Notice
|
|
|
|
|
|
|
|
|
||||||||
