*High Anti-PID resistant *Low breakage rate
*High module efficiency up to 20%
*High salt mist and ammonia resistance
*Easy for rooftop installation
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
25 years linear power output warranty
-
Brand Name:
-
JA
-
Model Number:
-
JAM72S30 525-550/MR
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2279*1134*35mm
-
Product name:
-
500 watt solar panel
-
Application:
-
Solar Power System
-
Solar cell:
-
182*182mm
-
Junction Box:
-
IP68 Rated
-
Frame:
-
Anodized Aluminium Alloy
-
Weight:
-
28.6kg
-
Connector:
-
Compatible Connector
-
Keyword:
-
Pv Module
-
Name:
-
Solar Panels 500 Watt
-
Cable:
-
4mm2
-
Certificate:
-
TUV/CE/IEC61215/IEC61730/ISO
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell
-
Panel Efficiency:
-
20.3%~21.3%
-
Warranty:
-
25 years linear power output warranty
-
Brand Name:
-
JA
-
Model Number:
-
JAM72S30 525-550/MR
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2279*1134*35mm
-
Product name:
-
500 watt solar panel
-
Application:
-
Solar Power System
-
Solar cell:
-
182*182mm
-
Junction Box:
-
IP68 Rated
-
Frame:
-
Anodized Aluminium Alloy
-
Weight:
-
28.6kg
-
Connector:
-
Compatible Connector
-
Keyword:
-
Pv Module
-
Name:
-
Solar Panels 500 Watt
-
Cable:
-
4mm2
-
Certificate:
-
TUV/CE/IEC61215/IEC61730/ISO
Product Description
Electrical Parameters at STC and NOCT
|
Type
|
JAM72S30-525/MR
|
JAM72S30-530/MR
|
JAM72S30-535/MR
|
JAM72S30-540/MR
|
JAM72S30-545/MR
|
JAM72S30-550/MR
|
||||||
|
Rated Maximum Power(Pmax) [W]
|
525 397
|
530 401
|
535 405
|
540 408
|
545 412
|
550 416
|
||||||
|
Open Circuit Voltage(Voc) [V]
|
49.15 46.05
|
49.30 46.18
|
49.45 46.31
|
49.60 46.43
|
49.75 46.55
|
49.90 46.88
|
||||||
|
Maximum Power Voltage(Vmp) [V]
|
41.15 38.36
|
41.31 38.57
|
41.47 38.78
|
41.64 38.99
|
41.8 39.20
|
41.96 39.43
|
||||||
|
Short Circuit Current(lsc) [A]
|
13.65 10.97
|
13.72 11.01
|
13.79 11.05
|
13.86 11.09
|
13.93 11.13
|
14.00 11.17
|
||||||
|
Maximum Power Current(lmp) (A]
|
12.76 10.35
|
12.83 10.39
|
12.90 10.43
|
12.97 10.47
|
13.04 10.51
|
13.11 10.55
|
||||||
|
Module Efficiency [%]
|
20.3%
|
20.5%
|
20.7%
|
20.9%
|
21.1%
|
21.3%
|
||||||
|
Power Tolerance 0~+5W
|
|
|
|
|
|
|
||||||
|
Temperature Coefficient of Isc(α_jsc) +0.045%/°C
|
|
|
|
|
|
|
||||||
|
Temperature Coefficient of Voc(β_Voc) -0.275%/°C
|
|
|
|
|
|
|
||||||
|
Temperature Coefficient of Pmax(γ_Pmp) -0.350%/°C
|
|
|
|
|
|
|
||||||
|
STC（Standard Testing Conditions）：Irradiance 1000W/㎡,Cell Temperature 25℃.Spectra at AM1.5
NOCT(Nominal Operating Cell Temperature)：Irradiance 800W/㎡,Ambient Temperature 20℃， Spectra at AM1.5 Wind at 1m/s |
|
|
|
|
|
|
||||||
|
OPERATING CONDITION
|
|
|
|
|
||||
|
Maximum System Voltage
|
|
|
1000V/1500V DC(IEC)
|
|
||||
|
Operating Temperature
|
|
|
•40°C~+85°C
|
|
||||
|
Maximum Series Fuse
|
|
|
25A
|
|
||||
|
Maximum Static Load,Front
|
|
|
5400Pa
|
|
||||
|
Maximum Static Load,Back
|
|
|
2400Pa
|
|
||||
|
NOCT
|
|
|
45±2°C
|
|
||||
|
Safety Class
|
|
|
Glass Ⅱ
|
|
||||
|
Fire Performance
|
|
|
UL Type 1
|
|
||||
Details Images
Frame
*Conventional frame
*Boost bearing capability and prolong service life
*Serrated-clip design tensile strength
*Seal-lip design glue injection
*Silver or black frames are optional
*Boost bearing capability and prolong service life
*Serrated-clip design tensile strength
*Seal-lip design glue injection
*Silver or black frames are optional
*Long service life
*Heat dissipation
*IP68 protection level
*Conventional standalone edition and engineering custom edition
*Quality diode ensures module running safety
*Heat dissipation
*IP68 protection level
*Conventional standalone edition and engineering custom edition
*Quality diode ensures module running safety
Packing & Delivery
Certifications
Delivery & Payment Terms
|
Payment Terms
|
T/T
|
EXW
|
30% in advance for deposit payment, the balance payments will be paid before shipment.
|
|
|||
|
|
|
FOB
|
|
|
|||
|
|
|
CFR/C&F
|
30% in advance for deposit payment, the balance will be paid against copy of B/L
|
|
|||
|
|
|
CIF
|
|
|
|||
|
|
L/C
|
Optional for the amount of above 50,000 usd, L/C at sight is acceptable.
|
|
|
|||
|
|
West Union
|
Optional for amount of order less than 5000 usd
|
|
|
|||
|
|
Paypal
|
|
|
|
|||
|
Delivery Time
|
7~30 days after receiving the payment or the deposit payment
|
|
|
|
|||
