1. 5 years Warranty;
2. Highest conversion efficiency of 17%;
3. Anti-reflective and anti-soiling surface power loss from dirt and dust.
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Roof Mounting
-
Certificate:
-
ce,rohs etc.
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
longvision
-
Model Number:
-
15kwh solar system
-
Output Voltage (V):
-
220v
-
Output Frequency:
-
50Hz/60Hz
-
Work Time (h):
-
24hours
-
Product name:
-
home solar panel system
-
Use life:
-
20 Years
-
Normal Voltage:
-
51.2V
-
Max. Charge/Discharge Current:
-
80A
-
Output Voltage:
-
230VAC±5%
-
Waterproof:
-
IP21
-
4kw/5kw Dimension:
-
635*400*155mm/795*400*155mm
-
4kw/5kw weight:
-
53.0kg/68kg
Quick Details
-
Application:
-
Home
-
Solar Panel Type:
-
Monocrystalline Silicon
-
Battery Type:
-
Lead-Acid, Lithium Ion
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Roof Mounting
-
Certificate:
-
ce,rohs etc.
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
longvision
-
Model Number:
-
15kwh solar system
-
Output Voltage (V):
-
220v
-
Output Frequency:
-
50Hz/60Hz
-
Work Time (h):
-
24hours
-
Product name:
-
home solar panel system
-
Use life:
-
20 Years
-
Normal Voltage:
-
51.2V
-
Max. Charge/Discharge Current:
-
80A
-
Output Voltage:
-
230VAC±5%
-
Waterproof:
-
IP21
-
4kw/5kw Dimension:
-
635*400*155mm/795*400*155mm
-
4kw/5kw weight:
-
53.0kg/68kg
Product Description
Product Description
How do I choose a solar power system which meet my requirements?
* Home Use( 5kw to 10kw) ;
* School and office( 1.5kw to 5kw );
* Farm use( 10kw to 20kw );
* Hospital project( 15kw );
* Home Use( 5kw to 10kw) ;
* School and office( 1.5kw to 5kw );
* Farm use( 10kw to 20kw );
* Hospital project( 15kw );
* Factory use(
20kw to 30kw
);
* More large volume of power system can be customized.
* More large volume of power system can be customized.
|
Load Name
|
Load’s Watt
|
Quantity
|
|
lights
|
11w
|
8
|
|
fan
|
80w
|
2
|
|
computer
|
150w
|
2
|
|
printer
|
250w
|
1
|
|
Fax machine
|
300w
|
2
|
|
Refrigerator
|
120w
|
1
|
|
Washing machine
|
300w
|
2
|
|
microwave
|
1000w
|
1
|
|
Electric cooker
|
300w
|
1
|
|
Air conditioner(2HP)
|
1500w
|
1
|
|
Color TV
|
100w
|
2
|
System Parameters
System Parameters
5KW Off Grid Solar Storage System
|
Item
|
Mode
|
Quantity
|
|
Solar Panels
|
PV380P
|
8pcs
|
|
MPPT Charge Controller Inverter
|
48V/5000w
|
1 set
|
|
Lifepo4 battery pack
|
48V80AH
|
1 set
|
|
PV Panel Mounting Bracket
|
Customized
|
1 set
|
|
Power Distribution Box
|
Customized
|
1 set
|
|
Cable
|
PV-1*6mm2
|
40m
|
|
PV Waterproof Connector
|
MC4
|
10pairs
|
Solar Power Inverter
1. Pure sine wave inverter;
2. Inverter running without battery ;
2. Inverter running without battery ;
3. Built-in MPPT solar controller;
4. Configurable AC/Solar Charger priority via LCD setting;
4. Configurable AC/Solar Charger priority via LCD setting;
Lithium Ion Batteries
1. Safety;
2. Fast charging;
3. Long span life;
4. Support customization;
5. Large capacity & small volume;
6. Environmental materials adoption;
7. Good high-temperature performance;
8. Advanced BMS protection function.
3. Long span life;
4. Support customization;
5. Large capacity & small volume;
6. Environmental materials adoption;
7. Good high-temperature performance;
8. Advanced BMS protection function.
1. Residential Roof(Pitched Roof);
2. Commercial Roof(Flat roof&workshop roof);
3. Ground Solar Mounting system;
4. Vertical wall solar mounting system;
5. Aluminum structure solar mounting system;
6. Car parking solar mounting system.
2. Commercial Roof(Flat roof&workshop roof);
3. Ground Solar Mounting system;
4. Vertical wall solar mounting system;
5. Aluminum structure solar mounting system;
6. Car parking solar mounting system.
