Quick Details
-
Place of Origin:
-
chian
-
Dimension(Long * Breadth * High):
-
6450*2200*2970
-
Machine Weight:
-
5700 kg
-
Bucket capacity:
-
1.3m3
-
bucket width:
-
220
-
Rated load:
-
2500
-
Max Climb Capability:
-
30
-
Track width (left / right):
-
1670
-
Wheelbase (front / rear):
-
2630
-
Number of cylinders:
-
4
-
Tire size:
-
1670-24
-
Axle(Main drive and wheel reducer):
-
Big wheel side
-
multiway valve model:
-
20-2-2
Quick Details
-
Engine Brand:
-
Jade wood 85kw
-
Power:
-
85kw
-
Brand Name:
-
lehman
-
Place of Origin:
-
chian
-
Dimension(Long * Breadth * High):
-
6450*2200*2970
-
Machine Weight:
-
5700 kg
-
Bucket capacity:
-
1.3m3
-
bucket width:
-
220
-
Rated load:
-
2500
-
Max Climb Capability:
-
30
-
Track width (left / right):
-
1670
-
Wheelbase (front / rear):
-
2630
-
Number of cylinders:
-
4
-
Tire size:
-
1670-24
-
Axle(Main drive and wheel reducer):
-
Big wheel side
-
multiway valve model:
-
20-2-2
Product Description
Specification
|
TECHNICAL SPECIFICATIONS
ZL932 |
|
|
||
|
ENGINE – ZL932
|
|
|
||
|
Engine Model
|
YUNNEI YN27GBZ
|
|
||
|
Engine Net Power
|
58kw at 2.200 rpm
|
79hp
|
||
|
Maximum torque/engine speed
|
237 Nm/1.800 rpm
|
|
||
|
No. of cylinders
|
4
|
|
||
|
Displacement
|
3.3 L
|
201 in³
|
||
|
SERVICE REFILL CAPACITIES
|
|
|
||
|
Fuel Tank
|
70 L
|
18.4 gal
|
||
|
Hydraulic tank
|
70 L
|
18.4 gal
|
||
|
HYDRAULIC SYSTEM
|
|
|
||
|
Working pressure (max)
|
16mpa
|
160bar
|
||
|
No. of boom / bucket cylinders
|
2 / 1
|
|
||
|
Hydraulic control lever
|
Joystick Multifunctional lever ( Pilot optional )
|
|
||
|
WEIGHTS
|
|
|
||
|
Operating Weight
|
3300 kg
|
7275 lb
|
||
|
BUCKET CAPACITIES
|
|
|
||
|
Bucket Range Standard Bucket
|
1.0 m3
|
1.3 yd3
|
||
|
STEERING SYSTEM
|
|
|
||
|
System Form
|
Articulated power steering
|
|
||
|
Number of steering hydraulic cylinders
|
2
|
|
||
|
Steering type
|
Hydraulic assist
|
|
||
|
BRAKE SYSTEM
|
|
|
||
|
Operating brakes
|
Hydraulic-air disc brake, caliper on both axle.
|
|
||
|
Parking brake
|
Mechanical drum brake on gearbox.
|
|
||
|
CHASSIS AND TYRES
|
|
|
||
|
Type of driving
|
Full-time four-wheel drive
|
|
||
|
Front axle
|
Fixed rigid connect
|
|
||
|
Rear axle
|
Center-pin support, semi-floating, Oscillating ±11 degrees
|
|
||
|
Tires (standard)
|
Wave pattern 20.5/70-16
|
|
||
|
TRANSMISSION
|
|
|
||
|
Drive system
|
Torque converter hydraulic transmission
|
|
||
|
Hydraulic pump
|
Fixed-displacement gear pump, open system
|
|
||
|
Max. travel speeds (forwards/backwards) 30 km/h
|
|
|
||
|
Gears
|
4 Front 4 Rear
|
|
||
|
DIMENSIONS
|
|
|
||
|
Overall length
|
5400 mm
|
17'8.5"
|
||
|
Maximum width
|
1960 mm
|
6'5.1"
|
||
|
Overall height
|
2790 mm
|
9'1.8"
|
||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
