Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
DIXSEN
-
Model Number:
-
XB2-BD33
-
Contact type:
-
N/O+N/C
-
Environment temperature:
-
-25℃~+55℃
-
Frequency:
-
50/60Hz
Quick Details
-
Protection Level:
-
IP40
-
Max. Current:
-
10A
-
Max. Voltage:
-
660V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
DIXSEN
-
Model Number:
-
XB2-BD33
-
Contact type:
-
N/O+N/C
-
Environment temperature:
-
-25℃~+55℃
-
Frequency:
-
50/60Hz
Knob switch XB2-BD21 BD33 BJ21 BJ33 Two-speed self-locking second and third gear Select transfer switch
The push button series was used in control circuit of AC 50Hz or 60Hz, voltage to 660V, DC voltage up to 440V below, it is used for controlling singnale and interlocking. The main body adopts zinc alloy or high grade anti-flaming plastic, the contact adopts special silver alloy, so it has strong anti-electrical erosion property, the signal lamp series is suitble for electrical applice circuit of AC voltage 380V, 50Hz or 60Hz, DC voltage up to 380V below, it is used as kinds of lights indication signal, warming signal, accident signal and other signals. Our products comply with GB/T14048.1 and IEC60947-5-1.
| Ambient temperature | Rated insulation voltage | Pollution class | Degree of protection | Altitude above sea level |
| -25℃~+55℃ | AC 600V | III | IP65 / IP40 | <2000m |
