Quick Details
-
Warranty:
-
25 YEARS
-
Brand Name:
-
SunEvo
-
Model Number:
-
SE6-60H
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2172 x 1303 x 35mm
-
Number of Cells:
-
120 Cells (6x20)
-
Weight:
-
30.9kg
-
Front Side Glass:
-
High transparency solar glass 3.2mm
-
Backsheet:
-
White
-
Frame:
-
Silver / Black, anodized aluminium alloy
-
Junction Box:
-
IP68 Rated, 3 Diodes
-
Cable:
-
4.0mm2, Portrait: 300mm / Landscape: 1400mm
-
Wind/Snow Load:
-
2400Pa/5400Pa
-
Connector:
-
MC Compatible
-
Certificate:
-
CE / CB / TUV
Quick Details
-
Cell size:
-
210mmx210mm
-
Type:
-
PERC, Half Cell, HJT, N-TYPE, TOPCON
-
Panel Efficiency:
-
21.7%
-
Warranty:
-
25 YEARS
-
Brand Name:
-
SunEvo
-
Model Number:
-
SE6-60H
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2172 x 1303 x 35mm
-
Number of Cells:
-
120 Cells (6x20)
-
Weight:
-
30.9kg
-
Front Side Glass:
-
High transparency solar glass 3.2mm
-
Backsheet:
-
White
-
Frame:
-
Silver / Black, anodized aluminium alloy
-
Junction Box:
-
IP68 Rated, 3 Diodes
-
Cable:
-
4.0mm2, Portrait: 300mm / Landscape: 1400mm
-
Wind/Snow Load:
-
2400Pa/5400Pa
-
Connector:
-
MC Compatible
-
Certificate:
-
CE / CB / TUV
Solar Panel Detail
|
Maximum Power
(Pmax/W)
|
595
|
600
|
605
|
610
|
390
|
615
|
400
|
||||||
|
Maximum Power Voltage (Vmp/V)
|
34.16
|
34.36
|
34.56
|
34.76
|
36.05
|
34.96
|
36.75
|
||||||
|
Maximum Power Current (Imp/A)
|
17.41
|
17.46
|
17.50
|
17.55
|
10.82
|
17.59
|
10.89
|
||||||
|
Open Circuit Voltage (Voc/V)
|
41.25
|
41.45
|
41.65
|
41.85
|
42.35
|
42.05
|
42.91
|
||||||
|
Short Circuit Current (Isc/A)
|
18.50
|
18.55
|
21.718.61
|
18.66
|
11.48
|
18.71
|
11.56
|
||||||
|
Module Efficiency (%)
|
21.0
|
21.2
|
21.4
|
21.6
|
21.4
|
21.7
|
22.0
|
||||||
|
Power Output Tolerance (W)
|
0~+5
|
|
|
|
|
|
|
||||||
|
Temperature Coefficient of Isc
|
+0.05%/°C
|
|
|
|
|
|
|
||||||
|
Temperature Coefficient of Voc
|
-0.28%/°C
|
|
|
|
|
|
|
||||||
|
Temperature Coefficient of Pmax
|
-0.36%/°C
|
|
|
|
|
|
|
||||||
Certifications
Smart Manufacturing
Modularized fully automated production lines enable fast delivery and cost savings. To achieve high utilization rate and efficiency, SunEvo divided the whole production chain into separate but closely united automated production sectors. Over 40 patents are applied on production process optimization, which could effectively avoid manual errors and make sure all the production processes from raw material inspection to packing are all monitored online and saved for later use. This system ensures that the materials from the beginning of production to the packaging is all monitored online.
Quality Control
Stringent quality control is the cornerstone of SunEvo's manufacturing. Our customers have come to expect uncompromising quality standards in our products. To meet this expectation of high quality, we continue to invest in state-of-the art equipment and professional training of our employees . We are proud of our product quality and their reliable performance even in the most extreme conditions. SunEvo has received certifications for Quality Management System (ISO 9001:2015), Environment Management System (ISO 14001:2015) and Occupational Health and Safety Management System (ISO45001:2018) from both DNV GL and GZCC.
Solar Cell String EL Testing
Each solar PV cell string must be tested by EL machine to ensure every single solar cell is perfect.
Each Solar Module must be tested by EL machine before lamination to ensure every solar cell string is perfect.
Each Solar Module must be inspected by QC after lamination to ensure there is no defect during lamination.
Final EL Testing 100% ensure zero intenal electric defect for each solar module.
Output power testing ensure 100% positive power tolerance and excellent power performance.
Each Solar Module must be inspected by QC before packaging to ensure there is no defect during production process.
Product Packaging
Global Project Case
Utility Scale
With years of professional experience, SunEvo can provide you the perfect module product for your perfect projects so as to maximize your benefits of investments.
Commercial
Either self-consumption or selling to the grid, commercial projects provide system owners with a new way of investment, in which module plays a key role. And SunEvo was, is, and will always be a reliable partner which you won`t regret to choose.
Residential
Thousands of houses around the globe are equipped with SunEvo solar panel systems, so they can now enjoy the clean power with a lower electricity bill and moreover, make profits from them.
OEM & ODM Services
Laminated Logo
Laminated Barcode
Product Label
Module Package
Specification Datasheets
Marketing Material
Contact Us
FAQ
Q1:who are we?
A1:We are based in Anhui, China, start from 2017,sell to Southern Europe (40.00%),Southeast Asia (20.00%), Africa (18.00%), Domestic Market(2.00%),South Asia(2.00%),North America(2.00%),Northern Europe (2.00%),Central America (2.00%), Western Europe(2.00%),Eastern Asia(2.00%),Mid East(2.00%),Oceania(2.00%),Eastern Europe (2.00%), South America (2.00%). There are total about 101-200 people in our office.
Q2:How does your factory control the quality?
A2:We adopt iso 9001 quality system to control the quality. We have incoming quality control department to test and confirm raw material meets high quality producing requirements, production quality control department contains. The first inspection, in-process quality control, acceptance inspection and full inspection, outgoing quality control department confirm no defective batteries come out from the factory.
Q3:Can I have a sample order?
A3:Yes, we welcome sample order to test and check quality.
Q4:Do you support customized design?
A4:Yes,we can accept your customized requirements,we can also help you create your new designs.
Q5:How can I place an order?
A5:You can contact us for the details and after all the details confirmed,you can place an order.
If you want to know more information, you can send inquiry to our team, we will cover more details.
