Main charaters: In the production of small diameter pipe and requirements under the condition of high output, especially shows the advantages of using dual-strand extrusion. The characteristics of our dual-strand downstream equipments is with two sets of independent control circuit, the speed of each pipeline can be adjusted respectively, and can even produce different diameter of the pipe at the same time.Four strand extrusion line is suitable for Max 32mm pipe with high-speed production, unilateral pipe speed up to 25m/min.
This extrusion line adopts special screw and mould design, materials uniform plasticizing, fast production speed, low energy consumption. Control is easy to operate, reduce the technical requirements of the operation of operating workers. And effectively save the workshop space.
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
FAYGO PLAST
-
Voltage:
-
380V 50Hz 3phase(customized)
-
Dimension(L*W*H):
-
28*4*4.5m
-
Power (kW):
-
55
-
Weight:
-
9000 KG
-
Screw&barrel:
-
38CrMoAlA
-
Contactor:
-
SIEMENS
-
Inverter:
-
ABB
-
Cooling way:
-
Recycling water cooling
-
Temperature-controlled:
-
Japanese OMORN
-
Name:
-
PVC Pipe Extrusion Line
-
Certification:
-
CE,,ISO9001
-
suitable material:
-
PVC powder
-
Application Field:
-
Electric Conduit/water pipe
-
Color:
-
Customizable
Quick Details
-
Screw Design:
-
Double-screw
-
Screw L/D Ratio:
-
28:1
-
Screw Speed (rpm):
-
38 rpm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
FAYGO PLAST
-
Voltage:
-
380V 50Hz 3phase(customized)
-
Dimension(L*W*H):
-
28*4*4.5m
-
Power (kW):
-
55
-
Weight:
-
9000 KG
-
Screw&barrel:
-
38CrMoAlA
-
Contactor:
-
SIEMENS
-
Inverter:
-
ABB
-
Cooling way:
-
Recycling water cooling
-
Temperature-controlled:
-
Japanese OMORN
-
Name:
-
PVC Pipe Extrusion Line
-
Certification:
-
CE,,ISO9001
-
suitable material:
-
PVC powder
-
Application Field:
-
Electric Conduit/water pipe
-
Color:
-
Customizable
Product Description
PVC PPR PEHD plastic extruder twin screw extruder plastic pipe making machine
Specification
|
Pipe diameter(mm)
|
Extruder type
|
Max output(kg/h)
|
Extruder main motor(kw)
|
more models based on your requirements
|
|
16-32mm, 4 cavity
|
SJZ65/132
|
180-250
|
37
|
|
|
16-63mm, 2 cavity
|
SJZ65/132
|
180-250
|
37
|
|
|
50-110mm, 2 cavity
|
SJZ80/156
|
400-550
|
55
|
|
|
50-160mm
|
SJZ65/132
|
180-250
|
37
|
|
|
75-250mm
|
SJZ65/132
|
180-250
|
37
|
|
|
110-315mm
|
SJZ80/156
|
400-550
|
55
|
|
|
160-450mm
|
SJZ80/156
|
400-550
|
55
|
|
|
315-630mm
|
SJZ92/188
|
750-850
|
110
|
|
|
710-1000mm
|
SJZS135/28
|
1100-1200
|
160
|
|
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Installation
This is the factory of our Brazilian customer, we have cooperate for over 10 years. All their pipe lines are from us.
We will be very happy if we can use our knowledge, experience in the plastic extrusion area to help you, give you some solution.
This is our engineers in Iraq, we will send engineer to your factory when our machines arrived, and provide installation, training, etc.
If you need any solution about plastic extrusion machinery, welcome come to us
After sale service is very impotant to our company, we always keep it in mind.
Our factory & office
This is part of our factory, we are machine manufacturer, welcome to visit our factory if you have time!
This is part of our office and part of us, we are a strong tean and big familiy, we are always stand-by to provide servise for all our customers.
