Quick Details
-
Rated Input Voltage:
-
220 V
-
Rated Output Voltage (MIG):
-
1 V
-
Wire Feeding Speed:
-
2.5 m/min
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
KEYUE
-
Dimensions:
-
610*400*605
-
Usage:
-
Welding Carbon Steel
-
Weight (KG):
-
29 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Type:
-
IGBT
-
Function:
-
MMA,MIG,Lift TIG
-
Welding Material:
-
Carbon Steel
-
Voltage:
-
3PH AC380V±15%
-
Weight:
-
29KG
-
Power:
-
8.3KVA
-
Certification:
-
CCC/CE/ROHS
Quick Details
-
Wire Melting Type:
-
Short Circuit Transfer
-
Max. Load Power Capacity:
-
6.2KVA
-
Rated Duty Cycle @40°C (MIG):
-
80%
-
Rated Input Voltage:
-
220 V
-
Rated Output Voltage (MIG):
-
1 V
-
Wire Feeding Speed:
-
2.5 m/min
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
KEYUE
-
Dimensions:
-
610*400*605
-
Usage:
-
Welding Carbon Steel
-
Weight (KG):
-
29 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Type:
-
IGBT
-
Function:
-
MMA,MIG,Lift TIG
-
Welding Material:
-
Carbon Steel
-
Voltage:
-
3PH AC380V±15%
-
Weight:
-
29KG
-
Power:
-
8.3KVA
-
Certification:
-
CCC/CE/ROHS
- Support: MIG, TIG (Lift TIG) and MMA
- Wire: 0.8-1.0m solid cored wire and flux-cored wire
- Protection: over-heat and over current.
- Material: Stainless steel, Carbon steel and so on
| Model | MIG-250 |
| Input voltage(V) | 3PH AC380V±15% |
| Input power(KVA) | 8.3 |
| Input current (A) | 12.3 |
| Rated output | 26.5V/250A |
| Output current(A) | 60-250 |
| No-load voltage (V) | 64±5 |
| Duty Cycle% (40℃ 10min) | 250 60% |
| 193A 100% | |
| Efficiency (%) | 80 |
| Protection grade | IP21 |
| Insulation grade | F |
| Net weight (KG) | 29 |
| Gross weight (KG) | 33 |
| Dimension of machine (mm) | 610*400*605 |
| Dimension of package (mm) | 630*400*610 |
|
Material |
Sheet thickness (mm) |
Stick diameter (mm) |
Current range(A) |
Model |
|
Carbon steel Stainless steel Low alloy steel
|
≥0.8 |
0.8/1.0 |
50-200 |
MIG-200 |
|
≥0.8 |
0.8/1.0 |
60-250 |
MIG-250 |
|
|
≥0.8 |
1.0/1.2 |
60-350 |
MIG-350 |
|
|
≥0.8 |
1.0/1.2/1.6 |
60-500 |
MIG-500 |
|
|
Carbon steel Stainless steel Low alloy steel Aluminum
|
≥0.8 |
0.8/1.0 | 30-185A | MIG-200P |
|
≥0.8 |
2.5/3.2/4.0/5.0 |
25-350 |
MIG-350H |
|
|
≥0.8 |
5.0/6.0/8.0 |
25-500 |
MIG-500H |
