Vehicle gps tracking systems tk 105B with RFID reader camera speed limiter vehicle gprs gsm gps tracker

Quick Details

Quick Details

Vehicle gps tracking systems tk 105B with RFID reader camera speed limiter vehicle gprs gsm gps tracker

Vehicle gps tracking systems tk 105B with RFID reader camera speed limiter vehicle gprs gsm gps tracker

FOB Reference Price: Get Latest Price

≥1 Pieces

US $39

≥90000 Pieces

US $9

Free Inquiry

Customized Request

Product Details

{{item.text}}

Screen Type:: no

Warranty:: 36 Months

Place of Origin:: Guangdong, China

Brand Name:: iStartek

Model Number:: 4G VT900 L

Product Name:: speed limiter vehicle gprs gsm gps tracker

Sensor:: Motion Sensor

I/O:: 1RS232+1AD+3IN+2OUTPUT

Weight:: 90g

Size:: 65mm x 61mm x 26mm

Backup Battery:: 500mAh

Operating temperature:: -20° to 65° C

GSM Module:: LYNQ L306

GPS Band:: LYNQ N10

Certificate:: ISO9001:2008, CE, CCC, FCC, NBTC, DLT, AIS 140, LTFRB

Car Fitment:: Abarth

Resolution:: 1920*720

Function:: RFID/Magnetic Card Reader

Screen Type:: no

Warranty:: 36 Months

Place of Origin:: Guangdong, China

Brand Name:: iStartek

Model Number:: 4G VT900 L

Product Name:: speed limiter vehicle gprs gsm gps tracker

Sensor:: Motion Sensor

I/O:: 1RS232+1AD+3IN+2OUTPUT

Weight:: 90g

Size:: 65mm x 61mm x 26mm

Backup Battery:: 500mAh

Operating temperature:: -20° to 65° C

GSM Module:: LYNQ L306

GPS Band:: LYNQ N10

Certificate:: ISO9001:2008, CE, CCC, FCC, NBTC, DLT, AIS 140, LTFRB

4G & 2G / GPS+ Beidou

4G 3G 2G GPS+Beidou positioning

Support RFID/MSR

Privacy Protection by identification

Support Temperature Sensor

Keep fresh transportation of the cold chain

Support OBD/CANBUS

Easy installation for reading vehicle fuel value

Support Alcohol Sensor

Drunk driving alarm to improve driver safety

Support Fuel Sensor

Capacitive and ultrasonic fuel sensor optional

Support iButton

Low cost for identification solution

Support 37+ Alarms

For driving behavior monitoring and vehicle safety protection

Product Advantages

Coupon & Apply

Hot Get Free Samples

Parameter/Accessory

Items	Specifications
Product	Thai DLT RFID Reader Vehicle 3G GPS Tracker,4G Car GPS Tracker Anti Jammer with Fuel Senser and Engine shut off
Power Supply	9V - 36V / 1.5A
Backup Battery	500mAh
Normal power consumption	55mA/h
Dimension	65mm x 61mm x 26mm
Weight	90g
Work time	30 hours in power-saving mode and 7.5 hours in normal mode
Operating temperature	-20° to 65° C
Humidity	5% to 95% Non-condensing
Frequency	VT900-LMN: Cat-M/NB/GSM (4G) LTE-FDD: B1/B2/B3/B4/B5/B8/B12/B13/B17/B18/B19/B20/B25/B26/B28 LTE-TDD: B39 (for Cat M only) EGPRS: 850/900/1800/1900MHz VT900-LEC (EU): Cat-1 (4G) LTE-FDD: B1/B3/B7/B8/B20/B28 WCDMA: B1/B8 GSM: B3/B8 VT900-LNS (US): Cat-1 (4G) LTE-FDD: B2/B4/B5/B12/B13/B25/B26 WCDMA: B2/B4/B5
GPS Module	LYNQ N
GPS Sensitivity	-159Db
GPS Frequency	L1, 1575.42 MHz
C/A Code	1.023 MHz chip rate
Channels	20 channel all-in-view tracking
Position Accuracy	2.5 meters, 2D RMS
Velocity Accuracy	0.1 m/s
Time Accuracy	1 us synchronized to GPS time
Default datum	WGS-84
Reacquisition	0.1 sec., average
Hot start	1 sec., average
Warm start	38 sec., average
Cold start	42 sec., average
Altitude Limit	18,000 meters (60,000 feet) max
Velocity Limit	515 meters/second (1000 knots) max
LED	2 LED lights to show GPS/GSM status
Flash Memory	8MB
Interface	3 digital inputs (1 negative, 1 positive triggering and 1 input changeable) 1 analog input 2 output 1 RS232

Production Flow

About Us

W e provide free GPS Tracking System for one year, simple and easy for management and tracking!

Web-based tracking system
Android APP
IOS APP

Features	Descriptions
Time Zone & Local Language	More than 10 languages and timezone settings
Multiple Account Support	Allow you to set up an account for company user to management many vehicles
Group Management	The user can manage the vehicle by setup difference groups
Reporting and Export	The overview report, Speeding report, Mileage report, Stop Report
Real-Time Tracking	Track the vehicle by real-time
Location History	Replay the location history
SOS Alarm	SOS Alert
Communication Failure Monitoring	Monitor the vehicle when it is not reporting
Over Speed Monitoring	Monitor the vehicle when it is over a speed
Online Vehicle Engine Control	Turn on or turn off the engine
Geo-fence Notification	Set up a zone to monitor the vehicle to enter or exit this zone.
Landmark	Mark the new point in the map by yourself
