Quick Details
-
Weight (KG):
-
500
-
Voltage:
-
220V 50/60Hz
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
QIBO
-
Dimension(L*W*H):
-
(L)3770x(W)670x(H)1450mm
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Control:
-
by dual frequency conversion
-
packing speed:
-
up to 230bags/min
-
bag length:
-
can be variable by screen setting
-
bag width:
-
can be adjustable in define range
-
conveying:
-
by chain
-
packing materials:
-
heat sealing film, such as bopp/cpp
-
packing products:
-
various food products, daily commodities
-
Automaticity:
-
Fully Auto
-
Sealing type:
-
Hot Sealing
Quick Details
-
Function:
-
Sealing, Wrapping
-
Packaging Type:
-
Bags, case, Film, Foil, Pouch, Stand-up Pouch
-
Packaging Material:
-
Metal, Paper, Plastic
-
Weight (KG):
-
500
-
Voltage:
-
220V 50/60Hz
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
QIBO
-
Dimension(L*W*H):
-
(L)3770x(W)670x(H)1450mm
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Control:
-
by dual frequency conversion
-
packing speed:
-
up to 230bags/min
-
bag length:
-
can be variable by screen setting
-
bag width:
-
can be adjustable in define range
-
conveying:
-
by chain
-
packing materials:
-
heat sealing film, such as bopp/cpp
-
packing products:
-
various food products, daily commodities
-
Automaticity:
-
Fully Auto
-
Sealing type:
-
Hot Sealing
Machine Features
1. Dual frequency conversion control, bag length can be set and cut in one step, saving time and film.
2. Interface features easy and quick setting and operation.
3. Self failure diagnosis, clear failure display.
4. High sensitivity photoelectric eye color tracing, numerical input of cutting sealing position for extra accuracy.
5. Temperature independent PID control, more suitable for packaging different materials.
6. Positioned stop function, without sticking knife or wasting film.
Applications
Packaging various kinds of regular objects like biscuits, pies, chocolates, instant noodles, drugs, daily appliances, industrial parts, paper boxes, plates etc.
Technical Parameters
| M achine type | QB-250B | QB-250D |
| Film width | Max 300mm | Max 320mm |
| Bag length | 65-190mm or 120-280mm | 90-220mm |
| Bag width | 30-110mm | 30-110mm |
| Product height | Max 40mm | Max 55mm |
| Film roll diameter | Max 320mm | Max 320mm |
| Packing speed | 40-230bag/min | 40-230bag/min |
| Power | 220V 50/60Hz 2.4Kw | 220V 50/60Hz 2.4Kw |
| Machine size(mm) | L 3770 x W670 x H 1450 | L 3770 x W670x H 1450 |
| Machine weight | 500kg | 500kg |
