Quick Details
-
Warranty:
-
25 years
-
Brand Name:
-
SSS Solar
-
Model Number:
-
SSS-(400-420)-108M
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1722mm*1134mm*30mm
-
Application:
-
Solar Power System
-
Solar cell:
-
A-grade
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP68 Rated
-
Connector:
-
MC4 Compatible Connector
-
Frame Color:
-
Color Silvery
-
Glass:
-
3.2mm, Low Iron Tempered Glass
-
Output cable:
-
4.0 Square Millimeter
-
Weight:
-
20.5kg
-
Certificate:
-
CE TUV
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, All Black
-
Panel Efficiency:
-
21%
-
Warranty:
-
25 years
-
Brand Name:
-
SSS Solar
-
Model Number:
-
SSS-(400-420)-108M
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1722mm*1134mm*30mm
-
Application:
-
Solar Power System
-
Solar cell:
-
A-grade
-
Frame:
-
Anodized Aluminium Alloy
-
Junction Box:
-
IP68 Rated
-
Connector:
-
MC4 Compatible Connector
-
Frame Color:
-
Color Silvery
-
Glass:
-
3.2mm, Low Iron Tempered Glass
-
Output cable:
-
4.0 Square Millimeter
-
Weight:
-
20.5kg
-
Certificate:
-
CE TUV
As for the solar panels model , now we mainly manufacture 410w 430w 440w 450w 500w 550w 570w 575w 580w solar panels with TUV and CE certificate.
Kindly send us an inquiry for more details if the models not showed in this page.
Product Description
|
ELECTRICAL CHARACTERISTICS(STC)
|
|
|
|
|
|
|||||
|
MODULE TYPE
|
SSS(400-420)-108M-B8-H
|
|
|
|
|
|||||
|
Maximum Power (Pmax)
|
400W
|
405W
|
410W
|
415W
|
420W
|
|||||
|
Open-circuit Voltage (Voc)
|
37.14V
|
37.23V
|
37.32V
|
37.41V
|
37.50V
|
|||||
|
Maximum Power Voltage (Vmp)
|
31.01V
|
31.21V
|
31.45V
|
31.69V
|
31.93V
|
|||||
|
Short-circuit Current (Isc)
|
13.79A
|
13.87A
|
13.95A
|
14.03A
|
14.11A
|
|||||
|
Maximum Power Current (Imp)
|
12.90A
|
12.98A
|
13.04A
|
13.10A
|
13.16A
|
|||||
|
Module Efficiency (%)
|
20.48%
|
20.74%
|
21.00%
|
21.25%
|
21.50%
|
|||||
|
Power Tolerance
|
0~+5W
|
|
|
|
|
|||||
|
Temperature Coefficient of lsc
|
0.05%/°C
|
|
|
|
|
|||||
|
Temperature Coefficient of Voc
|
-0.31%/°C
|
|
|
|
|
|||||
|
Temperature Coefficient of Pmax
|
-0.35%/°C
|
|
|
|
|
|||||
|
Standard Test Environment : lrradiance 1000W/m, Cell temperature 25"C Spectrum AM1.5
|
|
|
|
|
|
|||||
|
ELECTRICAL CHARACTERISTICS(NOCT)
|
|
|
|
|
|
|||||
|
MODULE TYPE
|
SSS(400-420)-108M-B8-H
|
|
|
|
|
|||||
|
Maximum Power(Pmax)
|
302W
|
306W
|
310W
|
314W
|
318W
|
|||||
|
Open-circuit Voltage (Voc)
|
34.88V
|
35.12V
|
35.36V
|
35.60V
|
35.84V
|
|||||
|
Maximum Power Voltage (Vmp)
|
29.26V
|
29.47V
|
29.68V
|
29.89V
|
30.10V
|
|||||
|
Short-circuit Current (sc)
|
11.03A
|
11.10A
|
11.16A
|
11.22A
|
11.28A
|
|||||
|
Maximum Power Current (Imp)
|
10.32A
|
10.38A
|
10.43A
|
10.50A
|
10.57A
|
|||||
|
Standard Test Environment : lrradiance 800W/m?, Ambient temperature 20"C, Spectrum AM1.5, Wind speed 1m/s
|
|
|
|
|
|
|||||
Strict QC System
Project Cases
Certifications
Packing & Delivery
|
Payment Terms & Delivery Time
|
|
|
|
|
||||
|
Payment Terms |
TT
|
EXW
|
30% T/T in advance
|
70% negotiable
|
||||
|
|
|
FOB/FCA
|
|
|
||||
|
|
|
CNF CFR
|
|
|
||||
|
|
|
CIF
|
|
|
||||
|
|
|
DDU/DAP
|
|
|
||||
|
|
L/C
|
L/C amount above 50,000 usd, we can accept L/C at sight
|
|
|
||||
|
|
West union
|
Amount lower than 5000usd
|
|
|
||||
|
Other payment
|
To be negotiable
|
|
|
|
||||
|
Delivery Time
|
7~30 days after receiving the payment
|
|
|
|
||||
FAQ
Q: Are you manufacturer ?
A: Yes,we have our own R&D team and sales team,We provide you one-stop service.
Q: Do you have CE,ROHS,ISO,TUV?
A: Yes,our products are approved by CE,ROHS,ISO,TUV
Q: Is OEM &ODM available in your factory ?
A: Yes, you just offer us necessary documents and then we will produce the products as your requirements.
Q: What is your Packing details?
A: 1.Wooden case or carton package,standard export packages
2. All of the productions are inspected carefully by QC before delivery.
Q: What is your Min.order?
A: There's no minimum quantity
A: Yes,we have our own R&D team and sales team,We provide you one-stop service.
Q: Do you have CE,ROHS,ISO,TUV?
A: Yes,our products are approved by CE,ROHS,ISO,TUV
Q: Is OEM &ODM available in your factory ?
A: Yes, you just offer us necessary documents and then we will produce the products as your requirements.
Q: What is your Packing details?
A: 1.Wooden case or carton package,standard export packages
2. All of the productions are inspected carefully by QC before delivery.
Q: What is your Min.order?
A: There's no minimum quantity
Q: Our advantages
A: 1. Ready To Ship 2. Sample Available
3. One-Stop Service 4. Online customization
5. Many years' experiences of manufacturing since 2007 and services available in 24 hours
A: 1. Ready To Ship 2. Sample Available
3. One-Stop Service 4. Online customization
5. Many years' experiences of manufacturing since 2007 and services available in 24 hours
