Quick Details
-
Brand Name:
-
KFT
-
Dimension(L*W*H):
-
2200*1100*1050mm
-
Weight:
-
550 KG
-
Features:
-
ATV Backhoe
-
Key Selling Points:
-
ATV Backhoe with 360 degrees
-
COLOR:
-
Customized
Quick Details
-
Marketing Type:
-
New Product 2023
-
Application:
-
Digging
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
KFT
-
Dimension(L*W*H):
-
2200*1100*1050mm
-
Weight:
-
550 KG
-
Features:
-
ATV Backhoe
-
Key Selling Points:
-
ATV Backhoe with 360 degrees
-
COLOR:
-
Customized
Application:
2) It is used for dicthing in farms and grazing lands, digging pool, cleaning waterways as well as assistant excavating work in construction and building roads;
3) Hydraulic transmission is used. featured with compact structure. Flexibility, convenient operation and quick mounting and dismounting.
|
Model |
BHR5 |
|
Motor |
15 hp/Engine speed 3600rpm |
|
Reach |
2300mm |
|
Excavation depth |
2040mm |
|
Digging range |
126° |
|
Maximum height of the backhoe with load |
1400mm |
|
Width of the outrigger when mounted |
2000mm |
|
Total width |
2000mm |
|
Wheels |
16’’ |
|
Ball Coupling |
50mm or 50.8mm |
|
Weight |
550 kgs |
|
Packaging size |
2125* 1100 *10 50 mm |
|
Bucket |
9’’ |
|
Oil capacity |
14.6L |
|
Cylinder |
3 pcs - Cylinder Diameter & Stroke: Ø76x305mm |
|
System pressure |
16Mpa |
