Quick Details
-
Dimension(L*W*H):
-
1000*600*1500mm
-
Weight (KG):
-
980
-
Power (kW):
-
3.16
-
Grinding diameter of OD/ID:
-
2~80 mm/10~60mm
-
Grinding length of OD/ID:
-
300 mm / 65mm
-
Max workpiece weight:
-
10 kg
-
Workbench Speed:
-
0.1~4 r/min
-
Certification:
-
ISO,CE
Quick Details
-
Place of Origin:
-
Guangdong
-
Brand Name:
-
QIANDAO
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
1000*600*1500mm
-
Weight (KG):
-
980
-
Power (kW):
-
3.16
-
Grinding diameter of OD/ID:
-
2~80 mm/10~60mm
-
Grinding length of OD/ID:
-
300 mm / 65mm
-
Max workpiece weight:
-
10 kg
-
Workbench Speed:
-
0.1~4 r/min
-
Certification:
-
ISO,CE
Product Description
Specification
|
Grinding diameter of OD
|
2~80mm
|
|
Grinding diameter of ID
|
10-60
|
|
Grinding length of OD
|
300mm
|
|
Grinding length of ID
|
80mm
|
|
Center height
|
115mm
|
|
Max workpiece weight
|
10kg
|
|
Workbench speed
|
0.1~4(r/min)
|
|
Grinding wheel line speed
|
35(m/sec)
|
|
Max travel of workbench
|
320
|
|
External grinding wheel size
|
Max 250*25*75 / Min 180*25*75
|
|
Grinding head spindle speed
|
2670rpm/min
|
|
Internal grinding head speed
|
15000rpm/min
|
|
Grinding head motor power
|
2.2KW
|
|
Headstock motor power
|
0.37KW
|
|
hydraulic System motor
|
0.55KW
|
|
Pump motor power
|
40W
|
|
Tail stock taper morse
|
Morse NO.3
|
|
Motor total power
|
3.16kw
|
|
size
|
1360x1240x1000mm
|
|
weight
|
1000KG
|
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
