- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
ESG
-
Model Number:
-
ES-290-320w
-
Certificate:
-
CE, ISO
-
Product name:
-
Solar Panels
-
Application:
-
Solar Power System
-
Keyword:
-
solar panel
-
Key word:
-
solar panel
-
Thickness:
-
190 30um
-
Front:
-
108 Finger Grids
-
Efficiency:
-
19.4%-21.7%
-
keywords:
-
solar panel
-
Warrant:
-
10 Years
Quick Details
-
Type:
-
PERC, MWT, IBC, HJT, hbc
-
Cell Efficiency:
-
50HZ
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ESG
-
Model Number:
-
ES-290-320w
-
Certificate:
-
CE, ISO
-
Product name:
-
Solar Panels
-
Application:
-
Solar Power System
-
Keyword:
-
solar panel
-
Key word:
-
solar panel
-
Thickness:
-
190 30um
-
Front:
-
108 Finger Grids
-
Efficiency:
-
19.4%-21.7%
-
keywords:
-
solar panel
-
Warrant:
-
10 Years
Why Choose Us？
Products Description
|
Model
|
ES290W
|
ES300W
|
ES315W
|
ES320W
|
|||
|
Peak Power Watts(Pmax/W)
|
290
|
300
|
315
|
320
|
|||
|
Tolerance (%)
|
0~+3%
|
|
|
|
|||
|
Open Circuit Voltage(Voc) [V]
|
39.15
|
39.84
|
40.91
|
41.30
|
|||
|
Short Circuit Current(Isc) [A]
|
9.58
|
9.65
|
9.91
|
9.97
|
|||
|
Maximum Power Voltage (V)
|
32.10
|
32.65
|
33.55
|
33.87
|
|||
|
Maximum Power Current (A)
|
9.05
|
9.12
|
9.39
|
9.45
|
|||
|
Maximum system voltage (V)
|
1000V
|
|
|
|
|||
|
Operating Temperature(℃)
|
-40 -- +85 ℃
|
|
|
|
|||
|
Electric Performance Typical Performance Characteristics
|
ES320W
|
|
|
Short Circuit Current Temperature Coefficient %/℃
|
0.048
|
|
|
Open Circuit Voltage Temperature Coefficient %/℃
|
-0.290
|
|
|
Maximum Power Temperature Coefficient %/℃
|
-0.370
|
|
|
Performance Warranty: 90%output:12 years; 80%output:25 years
|
|
|
Physical Specification：
Dimension:1640*992*35MM
Weight:18.5KG/PCS
Packing: Each box capacity: 31 pcs
Product Feature
● Bypass diode minimizes the power drop by shade.
● The conversion efficiency of solar cell is above 21%.
● White tempered glass,EVA resin, weather proof film and anodized aluminum frame to provide efficient protection from the severest environmental conditions.
● Waterproof Perfect for grid applications.
● Product guarantee 10 years.
Quality Assurance
●Electrical Insulation test
●Outdoor exposure test
●Hot-spot endurance test
●UV-exposure
●Thermal cycling test
●Humidity freeze test
●Damp heat Test
●Outdoor exposure test
●Hot-spot endurance test
●UV-exposure
●Thermal cycling test
●Humidity freeze test
●Damp heat Test
GLASS
> Antireflective glass
> Translucency of normal luminance is increased by 2%
> Module efficiency is increased by 2%
> Self-cleaning function
> Service life is as long as 25 years (30 years optional)
> Antireflective glass
> Translucency of normal luminance is increased by 2%
> Module efficiency is increased by 2%
> Self-cleaning function
> Service life is as long as 25 years (30 years optional)
Solar Cell
> High Efficiency PV Cells
> Appearance Consistency
> Color sorting ensure consistent appearance on each module
> Anti-PID
> High Efficiency PV Cells
> Appearance Consistency
> Color sorting ensure consistent appearance on each module
> Anti-PID
TEVA
>91% Higher Transmittance EVA,
>Higher GEL Content To Provide Good Encapsulation And Protect Cells From Vibration With Longer Durability
>91% Higher Transmittance EVA,
>Higher GEL Content To Provide Good Encapsulation And Protect Cells From Vibration With Longer Durability
Junction Box, Cable and MC4
> IP67 Waterproof, Closed
> 4mm2, 6mm2 Wire Size Range
> -40 ℃ to +85 ℃ Temperature Range
> Innovative full-glue-filled junction box Outstanding sealability
> IP67 Waterproof, Closed
> 4mm2, 6mm2 Wire Size Range
> -40 ℃ to +85 ℃ Temperature Range
> Innovative full-glue-filled junction box Outstanding sealability
More Related Products:
Our Factory
Certifications
Our Exhibition
Our Team
Packing & Transport
Our Project：
100MW floating PV plant in Weishan, Jining
100kW commercial rooftop PV plant in Japan
40MW floating PV plant in Panji, Anhui
FAQ
Q1:What’s A grade wholesale price payment terms?
A1:We accepted almost all payment terms,like T/T,L/C,DA,DP,Western Union,MoneyGram
Q2: OEM Service
A2：reached 100PCS，we also can pintingyour LOGO on solar panel carton.
Q3: Warranty process.
A3: We can provide 1 ~ 8 years different warranty.
Q4:How long is your delivery time?
A4:Normally,the whole production cycle need 15 days from material to finished products,but we can send goods within 7 days,because we have stock.
A1:We accepted almost all payment terms,like T/T,L/C,DA,DP,Western Union,MoneyGram
Q2: OEM Service
A2：reached 100PCS，we also can pintingyour LOGO on solar panel carton.
Q3: Warranty process.
A3: We can provide 1 ~ 8 years different warranty.
Q4:How long is your delivery time?
A4:Normally,the whole production cycle need 15 days from material to finished products,but we can send goods within 7 days,because we have stock.
