Quick Details
-
Model Number:
-
MR1012050F
-
Dimension:
-
-
-
Output Power:
-
230w
-
Type:
-
Professional Stage Outdoor Speaker
-
Certification:
-
ISO9001
Quick Details
-
Warranty:
-
Other
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Model Number:
-
MR1012050F
-
Dimension:
-
-
-
Output Power:
-
230w
-
Type:
-
Professional Stage Outdoor Speaker
-
Certification:
-
ISO9001
| MODEL:MR1012050F | |||
| General Specifications | |||
| Nominal Diameter | 254mm/10 inch | ||
| Nominal Impedance | 8Ω | ||
| RMS Power Input | 230W | ||
| MAX Power Input | 460W | ||
| Sensitivity 1W/1M | 91dB | ||
| Frequency Range | 28-2.2KHz | ||
| Voice Coil Diameter | 50mm/2 inch | ||
| Voice Windinig Material | Copper | ||
| Voice Former Material | Kapton | ||
| Voice Winding Depth | 18mm | ||
| Magnetic Gap Depth | 8mm | ||
| Xmax | ±5mm | ||
| Surround Material | foam edge | ||
| Surround Design | M-roll | ||
| Magnet | Φ120 | Ferrite Ring | |
| Thiele & Small Parameters | |||
| Resonance Frequency | Fs | 28Hz | |
| DC Resistance | Re | 5.6Ω | |
| Mechanical Factor | Qms | 9.09 | |
| Electrical Factor | Qes | 0.29 | |
| Total Factor | Qts | 0.28 | |
| BL Factor | BL | 15T.m | |
| Effective Moving Mass | Mms | 66.9g | |
| Compliance | Cms | 497μm/N | |
| Equivalent Cas Air Load | Vas | 89.6L | |
| Effetive Piston Area | Sd | 356cm² | |
| η(Eta Zero) | η0 | 0.6% | |
| Mounting & Shipping Information | |||
| Overall Diameter | 260mm | ||
| Bolt circle diameter | 249mm | ||
| Baffle Cutout Diameter | 230mm | ||
| Depth | 135mm | ||
| Net Weight | 3.7kg | ||
| Shipping Weight | 4kg | ||
| Shipping Box(Single) | 26.5*26.5*14cm | ||
| Shipping Weight (4Unit) | 17kg | ||
| Shipping Box(Single) (4Unit) | 55*28*33cm | ||
