Quick Details
-
Place of Origin:
-
Shandong, China
-
Dimension(Long * Breadth * High):
-
5400*1720*2600mm
-
Machine Weight:
-
3700 kg
-
Bucket capacity:
-
1.2cbm
-
Product name:
-
FUKAI ZL-930 1.5 ton rated load mini front end wheel Loader engine
-
Maximum dumping reach:
-
1290mm
-
Service Brake:
-
Air Over Hydraulic Disc Brake
-
Max.dumping height:
-
3400mm
-
Engine:
-
WEICHAI /DEUTZ
-
System Working Pressure:
-
16.0MPa
-
wheel base:
-
2850mm
-
After-sales Service Provided::
-
rovided: Field installation, commissioning and training,
Quick Details
-
Engine Brand:
-
YUNNEI or other
-
Power:
-
65kw
-
Brand Name:
-
FUKAI, FUKAI
-
Place of Origin:
-
Shandong, China
-
Dimension(Long * Breadth * High):
-
5400*1720*2600mm
-
Machine Weight:
-
3700 kg
-
Bucket capacity:
-
1.2cbm
-
Product name:
-
FUKAI ZL-930 1.5 ton rated load mini front end wheel Loader engine
-
Maximum dumping reach:
-
1290mm
-
Service Brake:
-
Air Over Hydraulic Disc Brake
-
Max.dumping height:
-
3400mm
-
Engine:
-
WEICHAI /DEUTZ
-
System Working Pressure:
-
16.0MPa
-
wheel base:
-
2850mm
-
After-sales Service Provided::
-
rovided: Field installation, commissioning and training,
Contact:Kathy
Tel/Whatapp/WeChat/Skype:+86 19905354613
FUKAI ZL-930 1.5 ton rated load mini front end wheel Loader with yunnei engine
Precision hydraulic cylinder and the fourth generation hydraulic transmission system give large breakout force for earthmoving work.
Life higher and reach further with optional High Lift linkage available on all models.With quick loading Performance and Optimized linkage.Multi-work just simple to accomplish.
The thickened frame has strong impact resistance and remarkable passing performance,enabling the loader to pass unimpeded in the difficult working environment.
Gull-wing Engine Doors make access and daily maintenance easy.Large steps on the side of the frame also enhance accessibility.
Ladder with wide steps and well-placed hand holds to ease entry and exit from the cabin.
If you're looking for a small machine with bigger performances,then this compact wheel loader is made for you with its amazing lifting and dumping height and huge breakout force.When equipped with buckets.or with pallet forks,guaranteed max productivity.
FUKAI compact wheel loaders are an optimal choice for many applications.On construction sites,in the recycling industry or for agricultural works,with the hydraulic quick-coupler and a wide range of attachments,the machine are extremely versatile.
At FUKAI compact wheel loader,developing products and services that raise productivity - we are sure we can lower costs and increase profits for customers to help you works easier.
FUKAI ZL-930 1.5 ton rated load mini front end wheel Loader with yunnei engine
used 930/936/950 wheel loader with loader spare parts for sale
| Basic Parameter | Model | ZL-930 |
| Gross weight | 3700kg | |
| Rated Load | 1500kg | |
| Overall Dimension | 5400*1720*2600mm | |
| Bucket capacity | 0.6-1.0m^3 | |
| Max.Dumping Height | 4300mm | |
| Max.Dumping Distance | 1050mm | |
| Bucket width | 1.72m | |
| Max. Speed | 35km/h | |
| Air conditioner | optinal | |
| Pallet fork | ||
| Snow bucket | ||
| High dump bucket | ||
| Sweeper | ||
| Reverse camera | ||
| 4in1 bucket | ||
| Quick-hitch | ||
| Color | Customized,standard is yellow | |
| Engine | Model | YUNNEI YN27GBZ |
| Engine power | 55kw/74hp at rated engine speed 2200rpm | |
| Pattern | Direct injection,water-cooled,turbocharged,diesel engine | |
| Transmission System | Gearbox model | Hydraulic transmission |
| Gear shift | 4 forward 4 reverse | |
| Type | Automatic | |
| Axle | Planetary rigid axles(hub) | |
| Hydraulic system/Refill capacities | Open hydraulic system/32L | |
| Hydraulic pressure(max) | 16mpa/160bar | |
| Drive system | Torque converter hydraulic transmission | |
| Operating | Joystick control | |
| working pump | Gear pump | |
| Steering System | Steering System | Articulated frame steering |
| Braking System | Operating brake | Hydraulic-air disc brake,caliper on both axle |
| parking brake | Mechanical drum brake on gearbox | |
| Tyre | Model | 20.5/70-16(standard) |
| Pressure of tire | 0.25-0.35mpa | |
| Package | 3 Units in 40HQ | |
used 930/936/950 wheel loader with loader spare parts for sale
We need to drive the loader into the container, and use the forklift to load the cab, bucket and so on into the container.
Machine is without packaging.
Parts is in box or without packaging.
3 Units in 40HQ,1 Unit in 20GP.
used 930/936/950 wheel loader with loader spare parts for sale
FUKAI always treat after-sale service as important as sale.
During the warranty,if there is any quality issue(except easy- damaged parts),we will provide the new accessories for you through verifying.
Detail clauses and policies please check our website and product certificate.
