Quick Details
-
Place of Origin:
-
Sichuan, China
-
Brand Name:
-
MIND
-
Product name:
-
Smart CPU Cards
-
Material:
-
PVC/PET/PETG
-
MOQ:
-
500pcs
-
Chip Available:
-
THD89
-
Size:
-
85.5*54mm/customized
-
Thickness:
-
0.84mm/Customized
-
Technical choices:
-
Magnetic strip,serial number,embossing names, hot-stamping
-
Distance:
-
About 5-10cm
-
Type:
-
dual interface cpu card Java GP card
-
Certificate:
-
ISO9001-2008
Quick Details
-
Special Features:
-
contact card
-
Communication Interface:
-
RFID
-
Frequency:
-
125KHz
-
Place of Origin:
-
Sichuan, China
-
Brand Name:
-
MIND
-
Product name:
-
Smart CPU Cards
-
Material:
-
PVC/PET/PETG
-
MOQ:
-
500pcs
-
Chip Available:
-
THD89
-
Size:
-
85.5*54mm/customized
-
Thickness:
-
0.84mm/Customized
-
Technical choices:
-
Magnetic strip,serial number,embossing names, hot-stamping
-
Distance:
-
About 5-10cm
-
Type:
-
dual interface cpu card Java GP card
-
Certificate:
-
ISO9001-2008
Customized PVC IC smart card with chip Clone card Visa Blank JAVA credit card
THD89-F350A is a 32 bits CPU dual interface smart card IC, providing 280KB of NVM space and 14.25KB of RAM space, which can be setas code and data space according to the user. It is suitable for contactless /contact smart card applications, such as bank card, etc.
Compatible with ISO/IEC14443 Type A protocol, the card can be operated by a standard Type A reader. It is also compatible with ISO/IEC 7816 protocol.
For software development convenience, the IC provides hardware DES/ TRNG/ CRC/ PKE, which effectively save the amount of software code and transaction processing time.
For better security and reliability, the IC provides enhanced security features, e.g., Electrical Environment Detectors, and Anti-SPA/DPA protections.
Compatible with ISO/IEC14443 Type A protocol, the card can be operated by a standard Type A reader. It is also compatible with ISO/IEC 7816 protocol.
For software development convenience, the IC provides hardware DES/ TRNG/ CRC/ PKE, which effectively save the amount of software code and transaction processing time.
For better security and reliability, the IC provides enhanced security features, e.g., Electrical Environment Detectors, and Anti-SPA/DPA protections.
Products Description
Development Toolkits: ✓ ULINK2 Emulator
✓ TMC target board
✓ Demo project and API (Application Program Interface) codes
✓ User Manual and Application Notes
ISO/IEC 7816 Slave interface:
✓ Support T=0/T=1 protocol
✓ Support 11 baud rates: F/D = 11H, 12H, 13H, 18H, 91H, 92H, 93H, 94H, 95H, 96H, 97H
✓ ISO/IEC 7816 interface DMA
✓ 3BH and 60H are sent automatically by hardware
✓ Support GSM power consumption standards
ISO/IEC 14443 interface:
✓ Compatible with ISO/IEC 14443 Type A
✓ Support baud rates:
- Normal rate: 106 kbit/s
- Enhanced rates: 212 kbit/s, 424 kbit/s, 848 kbit/s
✓ Support Crypto1
✓ TMC target board
✓ Demo project and API (Application Program Interface) codes
✓ User Manual and Application Notes
ISO/IEC 7816 Slave interface:
✓ Support T=0/T=1 protocol
✓ Support 11 baud rates: F/D = 11H, 12H, 13H, 18H, 91H, 92H, 93H, 94H, 95H, 96H, 97H
✓ ISO/IEC 7816 interface DMA
✓ 3BH and 60H are sent automatically by hardware
✓ Support GSM power consumption standards
ISO/IEC 14443 interface:
✓ Compatible with ISO/IEC 14443 Type A
✓ Support baud rates:
- Normal rate: 106 kbit/s
- Enhanced rates: 212 kbit/s, 424 kbit/s, 848 kbit/s
✓ Support Crypto1
|
Material
|
PVC/ABS/PET/Paper(Glossy / Matte/Frosted)
|
|
Size
|
CR80 85.5*54mm as credit card
|
|
Thickness
|
0.76mm
|
|
Contact IC chip
|
5542/5528/4428/4442/24C02/24C64,TG97,JCOP etc.
|
|
Chip Capacity
|
Contact IC chip: 256byte/1024byte/2k/16k/64k/80k
|
|
Standard
|
ISO7816-3
|
|
Magnetic strip
|
Loco 300oe,Loco 650oe,Hico 2750oe,Hico 4000oe
2 Ttrcks or 3 tracks Black / Silver / Brown / Gold magnetic stripe |
|
Printing
|
Heidelberg offset printing / Pantone color printing /Screen printing:
100% match customer required color or sample |
|
Surface
|
Glossy, matt, glitter, metallic, laswer, or with overlay for thermal
printer or with special lacquer for Epson inkjet printer |
|
|
Barcode: 13 barcode, 128 barcode, 39 barcode, QR barcode, etc.
|
|
|
Embossing numbers or letters in silver or gold color
|
|
|
Metallic printing in gold or silver background
|
|
|
Signature panel / Scratch-off panel
|
|
|
Laser engraving numbers
|
|
|
Gold/siver foil stamping
|
|
|
UV spot printing
|
|
|
Pouch round or oval hole
|
|
|
Security printing: Hologram, OVI securiting printing, Braille, Fluorescent
anti-counter feiting, Micro text printing |
|
Delivery
|
By Express, By sea or air
|
|
Packing details
|
200 pieces into a white box, then 15 boxes to a carton or custom on
demand |
