Quick Details
-
Voltage:
-
110v, 220v, 380v
-
Dimension(L*W*H):
-
55*40*35CM
-
After-sales Service Provided:
-
Overseas third-party support available
-
Type:
-
Cylindrical Grinding Machine
-
Swing dia. over bed:
-
280~400mm
-
Max. grinding diameter:
-
60~140mm
-
Spindle speed:
-
(50Hz)3750;(60Hz)4500
-
Main motor power:
-
370W
-
Packing case dimensions:
-
55*40*35cm
-
Net Weight:
-
32kg
-
Gross Weight:
-
40kg
-
Min. grinding diameter:
-
30mm
-
Max.grinding depth:
-
90mm
-
Max. Grinding Length:
-
250--2000mm
-
Certification:
-
ISO9001
-
Weight:
-
40KG
-
Max. Grinding Diameter:
-
140mm
-
Power:
-
370W
Quick Details
-
Model Number:
-
GA-60
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
unitech
-
Voltage:
-
110v, 220v, 380v
-
Dimension(L*W*H):
-
55*40*35CM
-
After-sales Service Provided:
-
Overseas third-party support available
-
Type:
-
Cylindrical Grinding Machine
-
Swing dia. over bed:
-
280~400mm
-
Max. grinding diameter:
-
60~140mm
-
Spindle speed:
-
(50Hz)3750;(60Hz)4500
-
Main motor power:
-
370W
-
Packing case dimensions:
-
55*40*35cm
-
Net Weight:
-
32kg
-
Gross Weight:
-
40kg
-
Min. grinding diameter:
-
30mm
-
Max.grinding depth:
-
90mm
-
Max. Grinding Length:
-
250--2000mm
-
Certification:
-
ISO9001
-
Weight:
-
40KG
-
Max. Grinding Diameter:
-
140mm
-
Power:
-
370W
Lathe Grinding Device for external and internal (GA-60)
| External grinding data | Internal grinding data | ||
| Max.Swing dia. over bed ( mm ) | Max. grinding diameter ( mm ) |
Min. grinding diameter(mm) |
Max.grinding depth(mm) |
| Φ280 | Φ60 | Φ30 | 90 |
| Φ300 | Φ75 | ||
| Φ320 | Φ100 | ||
| Φ400 | Φ140 | ||
| Spindle speed | (50Hz)3750 | Spindle speed | (50Hz)3700 |
| (60Hz)4500 | (60Hz)6500 | ||
| Main motor power | 370W | Net Weight | 32kg |
| Packing case dimensions | 55*40*35cm | Gross Weight | 40kg |
If you have any questions, please don't hesitate to let me know! TEL:0086-0632-5810219
