Rotary Screw Multi Stage Air Compressor 300 Cfm With Dryer

Rotary Screw Multi Stage Air Compressor 300 Cfm With Dryer

FOB Reference Price: Get Latest Price

≥1 Pieces

US $5000

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Place of Origin:: Shanghai, China

Pressure:: 7bar 8bar 10bar 13bar

Color:: Blue or OEM

Rotary Screw Multi Stage Air Compressor 300 Cfm With Dryer

Screw Air Compressor For Milking Workshop

Highly-quality shaft coupling elastic body can buffer and compensate for the imbalanced moment of operation. The elastomer is designed into and involute cambered surface, which effectively avoids stress concentration and improve the buffering effect of the elastomer to increase its bearing capacity. In addition, the high-quality materials ensure excellent durability for the elastomer and can better absorb the vibration arising from the rotation to remove noise

vertical air compressor

Advantage
Oil Filter:	Germany filters ensure longer working life and save the maintenance time and cost.
Stainless Steel Pipes:	High and low temperature resistant, high pressure resistant.
Compressed Air Vessel:	Reduction of pressure drops and energy costs, quality air with low oil content.
Air End:	Original Germany air end, advanced profile design.
Electric Motor:	Premium efficiency Totally motor (Class F insulation) protects against dust and chemicals etc.
Air Filter:	Two-stage dust removal and filtering system with efficiency of up to 99.9% even in heavy-duty environment.
Cooler:	High quality aluminum material, alternating expression cooler fins, ensure the perfect radiating effect.

Features:

5 Year Rotor Warranty
45,000-50,000 Working Hours Engineered Lifetime
Skf Explorer Bearings (Mainly)
Energy Saving Micro Control System, Fully Automated Operation
Easy Maintenance
Low-Noise Operation, Closed Cabinet Structure, Noise Reducing Dumping Mats Made Of Fire-Retardant Materials
Efficient, Safe And Reliable Fully Enclosed Motor Drive (Ip54, F Class / Ip55 Optional)
Energy Saving Air End 5:6 Helix
Networkable Link Between Compressors / Grouping With On-Line, Remote Monitoring And Dsc Network Functions
High Precision Heavy Duty Intake Filter 1Μm, 99.9% Efficiency
Optimized Oil Separation System Residual Oil Rate 1-3Mg/M3
Low Speed Air End Operation
Powerful Low Noise Exhaust Fan / On Top Exhaust
Automatic Control Of Functions / Maintenance Indicator
English Language Display, Easy Operation, Running Status At A Glance, Runningreal-Time Monitoring Data
Pressure And Temperature Control And Protection
Start Up Protection
English Language Display / English Language Manual

Specification

Model	Working Pressure		Air Delivery		Motor Power	Type of Driving	Type of Cooling	Dimension(mm)			Weight(kg)	Output pipe Diameter
	psig	bar	cfm	m3/min	kw/hp			L	W	H
CUD-30SA	100	7	134.2	3.8	22/30	Direct driven	Air Cooling/Water Cooling	1380	850	1150	640	11/4"
	116	8	127.1	3.6
	145	10	113.0	3.2
	181	13	88.3	2.5
CUD-40SA	100	7	187.1	5.3	30/40			1450	900	1220	900	11/4"
	116	8	176.6	5
	145	10	151.8	4.3
	181	13	127.1	3.6
CUD-50SA	100	7	233.0	6.6	37/50			1595	1000	1365	1060	11/2"
	116	8	218.9	6.2
	145	10	201.3	5.7
	181	13	162.4	4.6
CUD-60SA	100	7	282.5	8	45/60			1595	1000	1450	1150	11/2"
	116	8	271.9	7.7
	145	10	243.6	6.9
	181	13	211.9	6
CUD-75SA	100	7	370.8	10.5	55/75			2100	1250	1700	1750	2"
	116	8	346.0	9.8
	145	10	307.2	8.7
	181	13	257.8	7.3
CUD-100SA	100	7	480.2	13.6	75/100			2100	1250	1700	1840	2"
	116	8	459.0	13
	145	10	399.0	11.3
	181	13	356.6	10.1
CUD-120SA	100	7	572.0	16.2	90/120			2100	1250	1700	2030	2"
	116	8	543.8	15.4
	145	10	466.1	13.2
	181	13	395.5	11.2
CUD-150SA	100	7	734.4	20.8	110/150			2545	1450	1900	2920	DN65
	116	8	688.5	19.5
	145	10	582.6	16.5
	181	13	483.7	13.7
CUD-175SA	100	7	847.4	24	132/175			2545	1450	1900	3200	DN65
	116	8	812.1	23
	145	10	706.2	20
	181	13	547.3	15.5
ERC-200SA	100	7	981.6	27.8	160/200			2790	1550	2000	3600	DN65
	116	8	918.1	26
	145	10	829.8	23.5
	181	13	688.5	19.5
Motor Efficiency Class: Ultraefficient/IE3/IE2 as per your required Motor Protection Class: IP23/IP54/IP55 or as per your required Certification: CE/ISO9001/TUV/UL/SGS/ASME Voltage: 380V/3PH/50HZ/60HZ, 220V/3PH/50HZ/60HZ, 400V/3PH/50HZ/60HZ, 440V/3PH/50HZ/60HZ, 415V/3PH/50HZ/60HZ, 230V/3PH/50HZ/60HZ, dual voltage is also ok

Model	Working Pressure		Air Delivery		Motor Power	Type of Driving	Type of Cooling	Dimension(mm)			Weight(kg)	Output pipe Diameter
	psig	bar	cfm	m3/min	kw/hp			L	W	H
CUD-250SA	100	7	1147.6	32.5	185/250	Direct driven	Air Cooling/Water Cooling	2790	1550	2000	3780	DN65
	116	8	1094.6	31
	145	10	918.1	26
	181	13	762.7	21.6
CUD-270SA	100	7	1218.2	34.5	200/270			2850	1700	2000	4400	DN80
	116	8	1165.2	33
	145	10	988.7	28
	181	13	829.8	23.5
CUD-300SA	100	7	1341.8	38	220/300			3150	2000	2120	4930	DN100
	116	8	1288.8	36.5
	145	10	1129.9	32
	181	13	953.4	27
CUD-330SA	100	7	1518.3	43	250/330			3150	2000	2120	5450	DN100
	116	8	1430.1	40.5
	145	10	1288.8	36.5
	181	13	1129.9	32
CUD-375SA	100	7	1818.5	51.5	280/375			4000	2000	2100	6150	DN125
	116	8	1765.5	50
	145	10	1589.0	45
	181	13	1306.5	37
CUD-420SA	100	7	1977.4	56	315/420			4600	2300	2400	7500	DN125
	116	8	1942.1	55
	145	10	1730.2	49
	181	13	1447.7	41
CUD-470SA	100	7	2259.8	64	355/470			4600	2300	2400	8100	DN150
	116	8	2189.2	62
	145	10	1906.7	54
	181	13	1624.3	46
CUD-550SA	100	7	2577.6	73	400/550			5000	2350	2400	8400	DN150
	116	8	2471.7	70
	145	10	2153.9	61
	181	13	1836.1	52
CUD-600SA	100	7	2860.1	81	450/600			5500	2590	2800	9000	DN150
	116	8	2789.5	79
	145	10	2471.7	70
	181	13	2083.3	59
CUD-670SA	100	7	3142.6	89	500/670			5500	2590	2800	9500	DN200
	116	8	3072.0	87
	145	10	2718.9	77
	181	13	2365.8	67
CUD-750SA	100	7	3601.6	102	560/750			6500	2700	3000	10000	DN200
	116	8	3460.4	98
	145	10	3072.0	87
	181	13	2718.9	77
Motor Efficiency Class: Ultraefficient/IE3/IE2 as per your required Motor Protection Class: IP23/IP54/IP55 or as per your required Certification: CE/ISO9001/TUV/UL/SGS/ASME Voltage: 380V/3PH/50HZ/60HZ, 220V/3PH/50HZ/60HZ, 400V/3PH/50HZ/60HZ, 440V/3PH/50HZ/60HZ, 415V/3PH/50HZ/60HZ, 230V/3PH/50HZ/60HZ, dual voltage is also ok
