Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Spring
-
Model Number:
-
T22
Quick Details
-
Project Solution Capability:
-
graphic design
-
Application:
-
Apartment
-
Design Style:
-
Modern
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Spring
-
Model Number:
-
T22
Product Description
Specification
|
Parameter
|
|
|
|
|
|
|
|
|||||||
|
Max.Turning Angle
|
240
|
|
Lever Break Torque
|
|
|
>=8N.m
|
|
|||||||
|
Max.Temperature
|
90
|
|
Gland Nut Torque
|
|
|
8-10N.m
|
|
|||||||
|
|
|
|
Max.Opening Angle
|
|
|
22
|
|
|||||||
|
Pressure(bar)
|
0.5
|
1
|
1.5
|
2
|
2.5
|
3
|
3.5
|
|||||||
|
Average Flow Rate(L/min)
|
9.1
|
12.9
|
15.4
|
17.8
|
20.1
|
21.8
|
23.5
|
|||||||
|
Testing Performance
|
|
|
|
|
|
|
|
|||||||
|
Noise Level
|
Max.20db at 3bar(with noise reducer)
|
|
Noise Reducer
|
|
|
Selectable
|
|
|||||||
|
Air-Leak Test
|
0.8MPa(fully tested one by one)
|
|
Ceramic Disc
|
|
|
AL2O3 95%
|
|
|||||||
|
Burst Test
|
static water pressure max.3.5MPa
|
|
|
|
|
|
|
|||||||
|
Life Test
|
According to the En817,GB18145-2003 Standard>70.000cycles
according to the ASME,A112.18.1-2005 Standard>500.000cycles |
|
|
|
|
|
|
|||||||
|
Ceramic Disc Date
|
|
|
|
|
|
|
|
|||||||
|
Material:Ceramic disc
|
|
|
|
|
|
|
|
|||||||
|
Hardness:>1000 Hv5
|
|
|
|
|
|
|
|
|||||||
|
Flatness:<=0.3um
|
|
|
|
|
|
|
|
|||||||
|
Surface Roughness Ra:<=0.2um
|
|
|
|
|
|
|
|
|||||||
