Quick Details
-
Capacity:
-
200
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Inlight or OEM
-
Main components:
-
Water tank,Solar collector,Solar workstation
-
Tank capacity:
-
100 liters to 1200 liters (Customized volume available)
-
Inner tank material:
-
Stainless steel or enamel
-
Heat preservation layer:
-
Polyurethane foam(PU foam)
-
Solar collector type:
-
Tubular solar collector
-
Bracket material:
-
Aluminum alloy or stainess steel
-
Install location:
-
Pitched roof,groud or wall mounting
-
Max working pressure:
-
7 bar (0.7MPa)
-
Frost resistance:
-
Yes, > - 40 C
-
Hail resistance:
-
Yes, < dia 30mm
Quick Details
-
Type:
-
Evacuated Tube
-
Circulation Type:
-
Indirect / Closed Loop (Active)
-
Heating System:
-
Thermosyphon (Passive)
-
Capacity:
-
200
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Inlight or OEM
-
Main components:
-
Water tank,Solar collector,Solar workstation
-
Tank capacity:
-
100 liters to 1200 liters (Customized volume available)
-
Inner tank material:
-
Stainless steel or enamel
-
Heat preservation layer:
-
Polyurethane foam(PU foam)
-
Solar collector type:
-
Tubular solar collector
-
Bracket material:
-
Aluminum alloy or stainess steel
-
Install location:
-
Pitched roof,groud or wall mounting
-
Max working pressure:
-
7 bar (0.7MPa)
-
Frost resistance:
-
Yes, > - 40 C
-
Hail resistance:
-
Yes, < dia 30mm
Haining Yinuo electric Co., Ltd manufactures and supplies all kinds of solar water heaters, solar collectors.
Our professional group will design the best solar heating system solutions for your domestic house, hotel, hospital or industry plants.
Contact us freely to get the professional advice and customized solutions.
| European Standard Anti-freeze Water heating Solar Kits | ||||||||
| 1. Solar Water Heater Storage Tank Capacity: 80L,100L,120L,150L,200L,250L,300L,400L,500L,600L,700L,800L,1000L,1200L | ||||||||
| 2. Heat Collecting Type: Glass evacuated tube solar collector | ||||||||
| 3. Inner Storage Tank Material: Food-grade stainless steel SUS304-2B or SUS316 1.0mm - 2.0 MM or enamel inner tank | ||||||||
| 4. Tank Exterior Shell Material: High-quality white coated color steel or stainless steel 0.4MM | ||||||||
| 5. Heat Insulation: High-density polyurethane integrated foam-forming layer with 72~80 hours heat preservation | ||||||||
| 6. Thickness of Insulation Layer: 50mm, 55mm, 60mm | ||||||||
| 7. Coils in tank as heat exchanger in tank: Stainless steel, or copper coils | ||||||||
| 8. Quantity of coils in tank:1 roll,2 rolls,3 rolls or four rolls | ||||||||
| 9. Vacuum Tube Model: Φ47/1500mm, Φ47/1800mm, Φ58/1800mm | ||||||||
| 10. Vacuum Tube Material: Borosilicate glass 3.3 | ||||||||
| 11. Vacuum Tube Absorbing Coating: Single or tripple target magnetron sputtering AL/AL-ALN or Cu-SS-ALN/AIN | ||||||||
| 12. Bracket: Hot-dip galvanized steel,stainless steel or aluminum alloy | ||||||||
| 13. Angle of bracket: 10°-50°, universal bracket suitable for slope and flat roof installation | ||||||||
| 14. Accessories: Stainless bolts & nuts, anti-aging silicon gasket, dustproof rubber seal, plastic air-vent cap | ||||||||
| 15. Hot Water Output:45-95°C | ||||||||
| 16. Designed Pressure:6 Bar |
