Quick Details
-
Model Number:
-
202 louvered pergola
-
Name:
-
Garden Aluminium Louvered Pergola
-
Material:
-
Aluminum Alloy Pergola
-
Color:
-
white , black , gery , customized color
-
Applicationn:
-
sun shade pergola,outdoor garden design
-
Function:
-
UV Protection, Waterproof, Sunshade
-
Remote control:
-
Individual control or group control
-
Product Size:
-
3m x 3m ; 5m x 3m ; 4m x 4m;customized size
-
Features:
-
Rainproof Garden Louver pergola
-
Keyword:
-
Louvered Pergola
-
Optional Accessories:
-
Side Screen/Heater/Sensor Aluminum Motorized Pergola
Quick Details
-
Pressure Treated Wood Type:
-
NATURE
-
Place of Origin:
-
shanghai
-
Brand Name:
-
SUNC
-
Model Number:
-
202 louvered pergola
-
Name:
-
Garden Aluminium Louvered Pergola
-
Material:
-
Aluminum Alloy Pergola
-
Color:
-
white , black , gery , customized color
-
Applicationn:
-
sun shade pergola,outdoor garden design
-
Function:
-
UV Protection, Waterproof, Sunshade
-
Remote control:
-
Individual control or group control
-
Product Size:
-
3m x 3m ; 5m x 3m ; 4m x 4m;customized size
-
Features:
-
Rainproof Garden Louver pergola
-
Keyword:
-
Louvered Pergola
-
Optional Accessories:
-
Side Screen/Heater/Sensor Aluminum Motorized Pergola
|
|
Blade
|
Beam
|
Post
|
||
|
Size
|
202mm*33mm
|
202*160mm
|
150mm*150mm
|
||
|
Thickness of material
|
2.8mm
|
3.5mm
|
2.0mm
|
||
|
Materia
|
Aluminum alloy 6063 T5
|
|
|
||
|
Max safe span range
|
4000mm
|
6000mm
|
2800mm or customized
|
||
|
Color
|
Dark Grey with Shiny Silver Traffic White and Customized Color AccordingtoRAL Color Number
|
|
|
||
|
Motor
|
Motor can inside and outside (inside keep in 15 square meter, outside keepin 3 0 square meter)
|
|
|
||
|
LED
|
Standard LED on blades and in around, RGB can be optional
|
|
|
||
|
Typical Finishe
|
Durable Powder Coated or PVDF Coating for Exterior Application
|
|
|
||
|
Motor Certification
|
IP67 testing report, TUV, CE, SGS
|
|
|
||
Product Details
LED Light
Rotating louver,remote control,rain and sun protection.
Grooves
Additional water gutters at thetop perfectly channel rainwaterthrough pipes to the ground.
Rotating louvers roof
Rotating louver,remote control,rain and sun protection.
100% Waterproof Sunshade Aluminium Pergola
Each piece of aluminum alloy shuttersis equipped with a waterproof groove,which leads to the drainage port of thecolumn from the
groove,and the rainwater is discharged to the ground,thereby enhancing the experience ofrainy days.
groove,and the rainwater is discharged to the ground,thereby enhancing the experience ofrainy days.
Our Advantages
Appearance and Surface( SUNC )
Shanochad all aliminum alioy material, unifor sprayingrust prevention and corrosion resistance
Other
The spraying of a brand is uneven. rusty andshort service time
Wind Bearing Design ( SUNC )
Stiffeners are added to the damp inner wall to enhance thiebeaning and wind resistance of the colurnn
Other
Product instability caused by a brand wind conference
German Welding Process( SUNC )
The assemmbly process af screws without leakage is fashianableand beautiful Stiffeners are added to the damp inner wall to enhancethe bearing and wind resistance of the column: The maximumload-bearina capacity is 200 kg /square meter
Other
Leakage ol a brand screw
The blade and lamp belt are made separately( SUNC )
Tne blade liaht is embedded inside.the tidal blade and blade lampbelt are made separatelywithout redundant lines
Other
The blade liaht strip is attached to the bladeand the blade lamp belt is messy all with lines
Gutter( SUNC )
The tide tank is formed in one line, without hidden dangerof water leakage
Other
When a brand ls assembled separately, it is
very easy to leak
Flume forming( SUNC )
Wide and deep guttersno water accumulation duringrainstorms fast flow rate
Other
The sink is relatively small, easy to accumulatewater rainwater pouring in when the rainstormdiffuses
Operational System
Optional Accessories
Color Choices
Project Showcase
Customer Feedback
Production & Packing
FAQ
Q1: What is material of your pergola made of?
A1: The material of beam, post and beam are all aluminium alloy 6063 T5.The material of accessories are all stainless steel 304
and brass h59.
Q2: What is the longerst span of your louver blades?
A2: The maximum span of our louver blades is 4m without any sagging.
Q3: Can it be mounted to the wall of house?
A3: Yes, our aluminum pergola can be attached to an existing wall.
Q4: What color fo you have？
A4: Usual 2 standard color of RAL 7016 anthracite grey or RAL 9016 traffic white or customized Color.
Q5: Whats the size of pergola do you do?
A5: We are the factory, so usual we custom made any sizes according to customers' request.
Q6: What's the rainfall intensity, snow load and wind resistance?
A6: Rainfall intensity:0.04 to 0.05 l/s/m2
Snowload:Up to 200kg/m2
Wind resistance: It can resist 12 winds for closed blades.
Q7: What types of features can I add to the awning?
A7: We also supply an integrated LED lighting system, zip track blinds, side screen, the heater and automatic wind and rain sensor
that will automatically close the roof when it starts raining.
Q8: What's your delivery time?
A8: Usually 10-20 working days upon receipt of 50% deposit.
Q9: What's your payment term?
A9: We accept 50% payment in advance，and the balance of 50% will be paid before shipment.
Q10: What about your package?
A10: Wooden box packaging.(not log, no fumigation required)
Q11: What about your product wattanty?
A11: We provide 8 years of pergola frame structure warranty, and 2 years of electrical system warranty.
Q12: Will you provide you th deaiilsed installation or video?
A12: Yes, we will provide you the installation instruction or video.
A1: The material of beam, post and beam are all aluminium alloy 6063 T5.The material of accessories are all stainless steel 304
and brass h59.
Q2: What is the longerst span of your louver blades?
A2: The maximum span of our louver blades is 4m without any sagging.
Q3: Can it be mounted to the wall of house?
A3: Yes, our aluminum pergola can be attached to an existing wall.
Q4: What color fo you have？
A4: Usual 2 standard color of RAL 7016 anthracite grey or RAL 9016 traffic white or customized Color.
Q5: Whats the size of pergola do you do?
A5: We are the factory, so usual we custom made any sizes according to customers' request.
Q6: What's the rainfall intensity, snow load and wind resistance?
A6: Rainfall intensity:0.04 to 0.05 l/s/m2
Snowload:Up to 200kg/m2
Wind resistance: It can resist 12 winds for closed blades.
Q7: What types of features can I add to the awning?
A7: We also supply an integrated LED lighting system, zip track blinds, side screen, the heater and automatic wind and rain sensor
that will automatically close the roof when it starts raining.
Q8: What's your delivery time?
A8: Usually 10-20 working days upon receipt of 50% deposit.
Q9: What's your payment term?
A9: We accept 50% payment in advance，and the balance of 50% will be paid before shipment.
Q10: What about your package?
A10: Wooden box packaging.(not log, no fumigation required)
Q11: What about your product wattanty?
A11: We provide 8 years of pergola frame structure warranty, and 2 years of electrical system warranty.
Q12: Will you provide you th deaiilsed installation or video?
A12: Yes, we will provide you the installation instruction or video.
