Quick Details
-
Brand Name:
-
Joyful Partner
-
Model Number:
-
B83310COB
-
Color Temperature(CCT):
-
3000k,4000k,6000k
-
Beam Angle(°):
-
15/25/38/60°
-
CRI (Ra>):
-
80
-
Input Voltage(V):
-
AC100-240V
-
Lamp Luminous Flux(lm):
-
1000
-
Working Lifetime(Hour):
-
50000
-
Working Temperature(℃):
-
-20 - 40
-
Product Weight（kg）:
-
0.9
-
Item Type:
-
LED Garden Spot Light
-
Consumption:
-
10 Watt
-
IP Rated:
-
IP66 Waterproof
-
Light source:
-
1*10W COB LED
-
Light Size:
-
Dia. 63mm*L114mm
-
Treatment:
-
Outdoor Powder Coating
-
Certification:
-
CE, RoHS, EMC, LVD
-
Working Temperature:
-
-20℃~40℃
-
Light Color:
-
Single Color(2700-6500K)
-
Front Cover:
-
Aluminum and Tempered Glass
Quick Details
-
IP Rating:
-
IP65
-
Lamp Body Material:
-
Aluminum
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Joyful Partner
-
Model Number:
-
B83310COB
-
Color Temperature(CCT):
-
3000k,4000k,6000k
-
Beam Angle(°):
-
15/25/38/60°
-
CRI (Ra>):
-
80
-
Input Voltage(V):
-
AC100-240V
-
Lamp Luminous Flux(lm):
-
1000
-
Working Lifetime(Hour):
-
50000
-
Working Temperature(℃):
-
-20 - 40
-
Product Weight（kg）:
-
0.9
-
Item Type:
-
LED Garden Spot Light
-
Consumption:
-
10 Watt
-
IP Rated:
-
IP66 Waterproof
-
Light source:
-
1*10W COB LED
-
Light Size:
-
Dia. 63mm*L114mm
-
Treatment:
-
Outdoor Powder Coating
-
Certification:
-
CE, RoHS, EMC, LVD
-
Working Temperature:
-
-20℃~40℃
-
Light Color:
-
Single Color(2700-6500K)
-
Front Cover:
-
Aluminum and Tempered Glass
Products Description
|
Item No.
|
Light Source
|
Lens Beam Angle(°)
|
Consumption (watt)
|
Input Voltage(V)
|
IK Rate
|
|
B83310COB B83510COB
|
1*10W CREE
|
15°/25°/38°/60°
|
10
|
DC12V/DC24V
|
4
|
|
B83310COB B83510COB
|
1*10W CREE
|
15°/25°/38°/60°
|
11
|
AC100-240V
|
4
|
|
Material specifications
|
|
|
|
Housing
|
Extruded aluminum alloy #6063,anodic oxidation or outdoor powder painting
|
|
|
Glass
|
Tempered glass.T=3mm
|
|
|
Lens
|
Optical lens,effciency≥85%
|
|
|
Cable gland
|
IP68,PG9 nickel coated copper
|
|
|
Gasket
|
Tooling shaped seal
|
|
|
LED
|
CREE COB LED,Ra>80
|
|
|
Driver
|
Constant current output
|
|
|
Spike
|
PVC(grey or black)
|
|
|
Mounting base
|
anodic oxidation or outdoor powder painting
|
|
|
Power cable
|
H05RN-F2*0.75mm²L=1m(low voltage)
H05RN-F3*0.75mm²L=1m(high voltage) |
|
|
Optional accessory
|
Honeycomb
|
|
|
|
Antiglare hood
|
|
1. Brand LED high lumen, energy saving, soft light,
2. Anti-oxidation pure-aluminum housing,
3. Upgrade IP66 Waterproof,
4. PWM/0-10V/DALI/TRIAC dimmable,
5. Installed easily by mounting base,U-style bracket or spike,
6. Housing color customizable.
3. Upgrade IP66 Waterproof,
4. PWM/0-10V/DALI/TRIAC dimmable,
5. Installed easily by mounting base,U-style bracket or spike,
6. Housing color customizable.
