Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
CNSUNNY
-
Model Number:
-
SZJ01
-
Voltage:
-
380v 50hz (optional)
-
Dimension(L*W*H):
-
1000X1130X1500mm
-
Weight (KG):
-
250 KG
-
Rated Power:
-
1.85kw
-
Dimensions:
-
1000*1130*1500mm
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
No-Load Rotational Speed:
-
2000r/min
-
lock-hole drilling machine:
-
pvc lock-hole drilling machine
Quick Details
-
type:
-
Drilling & Milling Machine
-
Max. Drilling Dia. (mm):
-
8 mm
-
Range of Spindle Speed(r.p.m):
-
2500 - 3000 r.p.m
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
CNSUNNY
-
Model Number:
-
SZJ01
-
Voltage:
-
380v 50hz (optional)
-
Dimension(L*W*H):
-
1000X1130X1500mm
-
Weight (KG):
-
250 KG
-
Rated Power:
-
1.85kw
-
Dimensions:
-
1000*1130*1500mm
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
No-Load Rotational Speed:
-
2000r/min
-
lock-hole drilling machine:
-
pvc lock-hole drilling machine
PVC win-door lock -hole drilling machine SZJ01/PVC Copy-routing Drilling Machine
Main features
- Copy-routing processing is availble
- Used for processing lock-holes and groves on aluminum windows and doors
- It consists of drill and the copy routing parts. One time clamping can achieve two working procedures which ensures the precise position of the holes and grooves.
Technique parameter
| Main motor power | 1.85kw |
| Working voltage | 380V 50HZ |
| Over all dimension(L*W*H) | 1000*1130*1500mm |
| Weight | 280kg |
| Processing hole size error | ±0.2mm |
| Processing deviation from straightness | ±0.1mm |
| Diameter of the three-holedrilling head | Ø12 |
| Centers distance of three-hole drilling head | 21.5*21.5 |
| Milling cutter diameter | Ø5 Ø8 |
| Cop-routing range | 290*100mm |
| Cutting profile surface roughness | Ra12.5m |
Contact person: Awen YIn
Mob:86-15063343341
Guarantee & Aftersales service:
1)Guarantee the complete machine for 18 months, except the consumable parts.
2) 24hour technical support by email or calling.
3) User-friendly english manual for machine using and maintaining.
