Quick Details
-
Brand Name:
-
HW
-
Model Number:
-
S5700-28P-LI-AC
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
S5700-28P-LI-AC
-
Warranty:
-
1 Year
Quick Details
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
256Gbps
-
Brand Name:
-
HW
-
Model Number:
-
S5700-28P-LI-AC
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
S5700-28P-LI-AC
-
Warranty:
-
1 Year
HW 24-port S5700-28P-LI-AC Gigabit network management core 4 optical port switch rack
Overview
HW S5700-28P-LI-AC is based on a new generation of high-performance hardware and HW's unified VRP (Versatile Routing Platform) platform. It has large-capacity and high-density gigabit ports, which fully meets the needs of enterprise users for campus network access, convergence, and IDC. Multiple application scenarios such as gigabit access and gigabit to desktop. This series of switches integrate advanced technologies such as reliability, safety, and environmental protection, and adopt simple and convenient installation and maintenance methods to help customers reduce the pressure of network planning, construction and maintenance, and help enterprises build future-oriented IT networks.
Specification
| The main parameters | |
| Product Type | Fast Ethernet Switch |
|---|---|
| Application level | Application level |
| Transmission rate | 10/100/1000Mbps |
| Exchange method | Store-forward |
| Backplane bandwidth | 256Gbps |
| Packet forwarding rate | 66Mpps/96Mpps |
| MAC address table | 16K |
| Port parameters | |
| Port structure | Modular |
|---|---|
| Number of ports | 28 |
| Port description | 24 10/100/1000Base-T Ethernet ports, 4 Gigabit SFP ports |
| Features | |
| Stacking function | Not stackable |
|---|---|
| VLAN |
Supports 4K VLANs Support Guest VLAN, Voice VLAN Support GVRP protocol Support MUX VLAN function Support VLAN based on MAC/protocol/IP subnet/policy/port Support 1:1 and N:1 VLAN Mapping function |
| QOS |
Supports rate limiting on the inbound and outbound directions of the port Support message redirection. S upport port-based traffic monitoring, support dual-speed three-color CAR function. Support 8 queues per port Support WRR, DRR, SP, WRR+SP, DRR+SP queue scheduling algorithm Support 802.1p and DSCP priority re-marking of packets Support L2 (Layer 2) ~ L4 (Layer 4) packet filtering function, providing packet filtering based on source MAC address, destination MAC address, source IP address, destination IP address, TCP/UDP protocol source/destination port number, protocol, and VLAN Features Supports queue-based rate limiting and port shaping functions |
| Multicast management |
Support IGMP v1/v2/v3 Snooping and fast leave mechanism Support intra-VLAN multicast forwarding and multicast multi-VLAN replication Supports multicast load sharing of bundled ports Support controllable multicast Support port-based multicast traffic statistics |
| Network Management |
Support Virtual Cable Test (Virtual Cable Test) Support Telnet remote configuration and maintenance Support SNMPv1/v2c/v3 Support RMON Support eSight network management system, support WEB network management features Support HTTPS Support system log, hierarchical alarm Support 802.3az energy efficiency Ethernet EEE Support power failure alarm Dying gasp function (except battery switch series) Support machine sleep |
| Security management |
User hierarchical management and password protection Support anti-DOS, ARP attack function, ICMP anti-attack Support combination binding of IP, MAC, port, VLAN Support port isolation, port security, Sticky MAC Support MFF Support black hole MAC address Support MAC address learning limit Support IEEE 802.1X authentication, support single port maximum number of users limit Support AAA authentication, support Radius, HWTACACS, NAC and other methods Support SSH V2.0 Support HTTPS Support CPU protection function Support blacklist and whitelist |
| Other parameters | |
| Power supply voltage |
AC: Rated voltage range: AC 100-240V; 50/60Hz Maximum voltage range: AC 90-264V; 50/60Hz DC: Rated voltage range: DC -48--60V Maximum voltage range: DC -36--72V |
|---|---|
| Power supply | <24W |
| Product size | 442×220×43.6mm |
| Environmental standards |
orking temperature: 0-45℃ Working humidity: 5%-95% |
| Other parameters | Ring network protection technology: support RRPP ring topology and RRPP multi-instance; support SmartLink tree topology and SmartLink multi-instance, provide millisecond protection of active and standby links; support Smart Ethernet protection SEP protocol; support ERPS Ethernet ring protection Protocol (G.8032); supports STP (IEEE 802.1d), RSTP (IEEE 802.1w) and MSTP (IEEE 802.1s) protocols; supports BPDU protection, root protection and loopback protection; supports BPDU Tunnel |
| Other features |
Lightning protection: Lightning protection capability of service ports: 7KV
Access security: support DHCP Relay, DHCP Server, DHCP Snooping, DHCP Security |
