Quick Details
-
Application:
-
Office Building
-
Design Style:
-
Modern
-
Type:
-
SubFloor Mgso4 Board
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SC
-
Raw material:
-
Magnesium oxide +MgSo4 +Perlite+Fiber Glass Mesh +Non-Woven Cloth
-
Size:
-
600*2700mm, 1220*2440mm or customized
-
Thickness:
-
16-20mm
-
Density:
-
1.0-1.3 g/cm3
-
Edge:
-
Square, shiplap, T&G
-
Surface:
-
Standard, smooth, sanding
-
Color:
-
White, grey
-
Fireproof Grade:
-
A1 Non-combustible
Quick Details
-
Warranty:
-
3 years
-
After-sale Service:
-
Online technical support
-
Project Solution Capability:
-
total solution for projects
-
Application:
-
Office Building
-
Design Style:
-
Modern
-
Type:
-
SubFloor Mgso4 Board
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
SC
-
Raw material:
-
Magnesium oxide +MgSo4 +Perlite+Fiber Glass Mesh +Non-Woven Cloth
-
Size:
-
600*2700mm, 1220*2440mm or customized
-
Thickness:
-
16-20mm
-
Density:
-
1.0-1.3 g/cm3
-
Edge:
-
Square, shiplap, T&G
-
Surface:
-
Standard, smooth, sanding
-
Color:
-
White, grey
-
Fireproof Grade:
-
A1 Non-combustible
Product Description
Subflooring Mgso4 Board
It made from magnesium oxide (Mgo), magnesium sulfate (Mgso4), bamboo filler and reinforced by fiber glass mesh.
Based on the latest advancement in cement and fiber-reinforcement technology, Mgso4 fire rated floor offer EXTREME STRENGTH and that is LIGHT WEIGHT and COST EFFECTIVE .
Based on the latest advancement in cement and fiber-reinforcement technology, Mgso4 fire rated floor offer EXTREME STRENGTH and that is LIGHT WEIGHT and COST EFFECTIVE .
It has the functions of fire, water, mould, sound and heat insulation.
Structural floors are lighter than precast or poured concrete, install in a similar way to wood decking, and are resistant to mildew, moisture and termites. Tongue and Groove, Ship-Lap edges available.
Subflooring Mgso4 Board
Sanded board structure and A unique tongue & groove flooring substrate, grooved down one long side with a matching tongue down the other.
It has a neat safety surface. Bending strength ≥20-25Mpa. Concentrated load up to 370Kgs.and Uniform load up to 500Kgs on 450mm joint center.
|
Product
|
Subfloor load bearing mgso4 board
|
|
Basic Compounds
|
(MgO)+(Mgso4s)+(glass fibre)+(Bamboo fibre)
|
|
LENGTH
|
8 ft(2440mm) 9ft(2700mm) Customized
|
|
WIDTH
|
4 ft(1220mm) 2ft(600mm) Customized
|
|
THICKNESS
|
15mm 18mm 20mm
|
|
USE
|
Internal, External subflooring and decking
|
|
Color
|
Grey and White
|
|
Surface texture
|
smooth one side; Sanded back
|
|
Edges
|
Tongue and Groove, Shiplap
|
|
Density
|
1.15T/M3
|
|
Combustibility / Fire Ratings
|
non-combustible / 12mm exceeds 120mins fire rating
|
|
Moisture content
|
≤8%
|
|
Bending Strength
|
≥20-25Mpa
|
|
Impact Strength
|
> 9kJ/m2
|
|
Modulus of elasticity
|
＞5000Mpa
|
|
Dry Shrinkage
|
≤0.3%
|
|
Wet Expansion Rate
|
≤0.3%
|
|
Thermal Conductivity
|
~0.44 W / mK
|
|
Thermal Expansion Hot/Cold
|
0,01 mm/mC (from temp +20C to -20C)
|
|
Surface Alkalinity
|
8-10 Ph
|
|
Asbestos Analysis
|
Absent - not measurable
|
|
Formaldehyde Analysis
|
Absent - not measurable
|
|
TVOC-ASTM D5116-10
|
Below measurable levels of test instruments
|
|
Chloride ion content-ASTMC 871-11
|
0.012%
|
Certifications
Packing & Delivery
|
Size
|
Weight-KG/Piece
|
Loading capacity in 20'ft CNT
|
|
3mm X 1220 X 2440
|
9.0
|
2200 pieces, 8 wooden pallets
|
|
6mm X 1220 X 2440
|
18.0
|
1100 pieces, 8 wooden pallets
|
|
8mm X 1220 X 2440
|
24.0
|
824 pieces, 8 wooden pallets
|
|
9mm X 1220 X 2440
|
27.0
|
732 pieces, 8 wooden pallets
|
|
10mm X 1220 X 2440
|
30.0
|
660 pieces, 8 wooden pallets
|
|
12mm X 1220 X 2440
|
36.0
|
550 pieces, 8 wooden pallets
|
|
15mm X 1220 X 2440
|
45.0
|
440 pieces, 8 wooden pallets
|
|
16mm X 1220 X 2440
|
48.0
|
412 pieces, 8 wooden pallets
|
|
18mm X 1220 X 2440
|
54.0
|
364 pieces, 8 wooden pallets
|
|
19mm X 1220 X 2440
|
57.0
|
348 pieces, 8 wooden pallets
|
|
20mm X 1220 X 2440
|
60.0
|
328 pieces, 8 wooden pallets
|
|
25mm X 1220 X 2440
|
75.0
|
264 pieces, 8 wooden pallets
|
Our Factory
Customer Photos
FAQ
FAQ
1.What is Mgo Board made of? What is the chloride content?
All Mgo Board consists of 3 elements, magnesium oxide, salt and crystal water.
The main component of Mgo Board is MgO which is completely non-flammable and can be used for fire protection.
There are mainly two different types of salt:
-Magnesium oxychloride hydrated /Mgcl2
-Magnesium oxysulfate hydrate/Mgso4
Mgoso4 board uses magnesium sulfate instead of magnesium chloride.
MgSo4 panels incredibly waterproof by preventing moisture from absorbing back into the halogens in the board.
According to The China Magnesium Oxide Board Industry Association issued a new standard of magnesia board industry, dissolvable
(free) chloride ion content is below 5%, Content of Chloride is below 10%.
Mgso4 board Chloride content is below 0.012%, with reference to ASTM C871-11
you don't have to worry about "crying boards" when you use Mgso4 board on steel or metal frame.
2. Is
Mgo Board
waterproof?
Mgo Board is considered to be moisture resistant, but during prolonged exposure, moisture can affect it and it will
experience hydrothermal expansion. When used outdoors, Mgo board should be covered or coated to protect it from the environments,
we can do waterproofing before leaving the factory, such as adding waterproofing elements or sealing with UV paint.
3. Is Mgo Board safe product?
Yes. Mgo Board is safer than many comparable building products. It is a mineral based product made with non-toxic
ingredients.It is completely recyclable and resistant to mold, mildew, fungus and allergens. It is also free of carcinogens and silicas.
4.What dimensions are commonly used to define Mgo Board ?
Mgo Board are sold in 4 × 8 ft,4x9 ft,4x10ft sheets other small size can customized and in multiple thickness from 3mm to
30mm.
Mgo Board is considered to be moisture resistant, but during prolonged exposure, moisture can affect it and it will
experience hydrothermal expansion. When used outdoors, Mgo board should be covered or coated to protect it from the environments,
we can do waterproofing before leaving the factory, such as adding waterproofing elements or sealing with UV paint.
3. Is Mgo Board safe product?
Yes. Mgo Board is safer than many comparable building products. It is a mineral based product made with non-toxic
ingredients.It is completely recyclable and resistant to mold, mildew, fungus and allergens. It is also free of carcinogens and silicas.
4.What dimensions are commonly used to define Mgo Board ?
Mgo Board are sold in 4 × 8 ft,4x9 ft,4x10ft sheets other small size can customized and in multiple thickness from 3mm to
30mm.
