Quick Details
-
Brand Name:
-
KEYPLUS
-
Model Number:
-
HT-21
-
Product Name:
-
Hotel Door Lock
-
Application:
-
Hotel
-
Material:
-
Zinc Alloy
-
Color:
-
Black,Sliver,Gold
-
Unlock way:
-
Card+Mechanical Key
-
Mortise:
-
ANSI Standard Mortise or DIN Standard
-
M1 sensor frequency:
-
13.56MHZ
-
Door thickness:
-
40-55mm
-
Warranty:
-
1-2 Years
-
Power supply:
-
4*1.5V AA Battery
-
Certification:
-
CE,FCC
Quick Details
-
Door Type:
-
Wood door, Steel door, Stainless Steel door, Aluminum door
-
Network:
-
TCP, SDK
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
KEYPLUS
-
Model Number:
-
HT-21
-
Product Name:
-
Hotel Door Lock
-
Application:
-
Hotel
-
Material:
-
Zinc Alloy
-
Color:
-
Black,Sliver,Gold
-
Unlock way:
-
Card+Mechanical Key
-
Mortise:
-
ANSI Standard Mortise or DIN Standard
-
M1 sensor frequency:
-
13.56MHZ
-
Door thickness:
-
40-55mm
-
Warranty:
-
1-2 Years
-
Power supply:
-
4*1.5V AA Battery
-
Certification:
-
CE,FCC
Product Description
HT-21 ,comes with Zinc Alloy lock case,three-latches and 304 Stainless steel lock body.
The Indoor knob lock design with anti-disturbance function,that it is popular for hotel and residence .The system alarming automatically if there is any illegal operation.
You can check the opening records with management software.
Features
1. Lock surface made using advance IML technology,minimalist morden design
2. ANSI Standard mortise lock
3. Declaration of conformity CE
4. FCC/IC conformity
Functions
1. Managment Software System by free
2. ANSI Standard mortise lock
3. Declaration of conformity CE
4. FCC/IC conformity
Functions
1. Managment Software System by free
2. Unlock with Mifare Smart Card
3. Kaba Key Cylinder design
4. Alarming Function when the door is not close well
5. Emergency Function
6. No need Website Connection To Open the Door
7. Three Latch Lock Body Safety design
8. USB Power for Emergency Situation
9. Opening Records for Checking
3. Kaba Key Cylinder design
4. Alarming Function when the door is not close well
5. Emergency Function
6. No need Website Connection To Open the Door
7. Three Latch Lock Body Safety design
8. USB Power for Emergency Situation
9. Opening Records for Checking
Technical Specification
|
Product Name
|
Hotel Locks
|
|
Brand
|
KEYPLUS
|
|
Model Number
|
HT-21
|
|
Ways to Unlock
|
Mifare Card/Mechenical keys
|
|
Size
|
H272.5mm*63mm
|
|
Material
|
Zinc Alloy+Stainless steel
|
|
Color
|
Black ,Sliver,Gold
|
|
Registered Cards Number
|
No limitation
|
|
Reading Time
|
<1s
|
|
Reading Range
|
<3cm
|
|
Opening Records
|
1000
|
|
M1 Sensor Frequency
|
13. 56MHZ
|
|
Static Current
|
<15μA
|
|
Dynamic Current
|
<120mA
|
|
Lower Voltage Warning
|
<4. 8V (250 times at least)
|
|
Working Temperature
|
-10ºC~50ºC
|
|
Working Humidity
|
20%~80%
|
|
Working Voltage
|
4PCS LR6 Alkaline Batteries
|
|
Door Thickness Request
|
40mm~55mm (available for others)
|
|
Door Type
|
Wood door, Steel door, Stainless Steel door, Brass door
|
Product Detail Pictures
|
Basic (necessary) components of hotel lock system include
|
|
|
|
Computer
|
It is used to install lock management software, prepared by hotel.
|
|
|
Software
|
Send you for free.It is management system. Work on window XP, 7, 8, and 10.Compatible with most of the common property management
systems(PMS) interface. |
|
|
Card Reader/Authorize Card
|
It is used to read and encode(issue) the card. USB port.
|
|
|
M1 Cards
|
One Lock need at least one pcs card, for open door.
|
|
|
Locks
|
Install on to the door. Independent, wireless, battery-operated. It stores latest 250 events.Perfect reading. Advanced security
performance. |
|
|
Optional components:
|
|
|
|
Handset
|
Data collector It is used to collect the unlocking records from the locks, and read on the computer.
|
|
|
Power-saving switch
|
Device allow the key card to turn on the lighting system and air controller of the room.
|
|
|
Elevator controller
|
Elevator using
|
|
