Quick Details
-
Brand Name:
-
CJSE LPG Tank
-
Dimension(L*W*H):
-
DN3000 x 13070 x 16/18mm
-
Capacity:
-
100m3
-
Weight:
-
20015
-
Inner Material:
-
Q345R carbon steel
-
Outer Material:
-
Q345R carbon steel
-
Design Pressure(MPa):
-
1.77
-
Design Standard:
-
ASME/GB150
-
Working Temperature(℃):
-
-19 - 50 ℃
-
Product name:
-
lpg gas bullet tank 50ton horizontal fixed bulk lpg storage tanks
-
Filling medium:
-
Liquid Petroleum Gas (propane)
-
Working pressure:
-
1.63 MPa
-
Material of LPG Tank:
-
Q345R carbon steel
-
Corrosion allowance:
-
1 mm
-
Certification:
-
ASME ISO9001 ISO14001
-
Key words:
-
lpg storage tank, lpg tank,lpg gas tank
-
Volume available:
-
5m3 to 200m3 lpg storage tank
-
LPG Tank Type:
-
Horizontal Ground LPG Storage Tank
-
Keyword:
-
50ton propane tank 100m3 tank LPG storage tank
Quick Details
-
Volume (m³):
-
100cbm
-
Max Working Pressure(MPa):
-
1.82 MPa
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
CJSE LPG Tank
-
Dimension(L*W*H):
-
DN3000 x 13070 x 16/18mm
-
Capacity:
-
100m3
-
Weight:
-
20015
-
Inner Material:
-
Q345R carbon steel
-
Outer Material:
-
Q345R carbon steel
-
Design Pressure(MPa):
-
1.77
-
Design Standard:
-
ASME/GB150
-
Working Temperature(℃):
-
-19 - 50 ℃
-
Product name:
-
lpg gas bullet tank 50ton horizontal fixed bulk lpg storage tanks
-
Filling medium:
-
Liquid Petroleum Gas (propane)
-
Working pressure:
-
1.63 MPa
-
Material of LPG Tank:
-
Q345R carbon steel
-
Corrosion allowance:
-
1 mm
-
Certification:
-
ASME ISO9001 ISO14001
-
Key words:
-
lpg storage tank, lpg tank,lpg gas tank
-
Volume available:
-
5m3 to 200m3 lpg storage tank
-
LPG Tank Type:
-
Horizontal Ground LPG Storage Tank
-
Keyword:
-
50ton propane tank 100m3 tank LPG storage tank
Our product Advantages
Specification
|
LPG Gas Tank Type
|
|
III
|
|
Capacity of LPG Tank
|
cbm
|
50
|
|
Orientation of LPG Tank
|
|
Horizontal Single Layer LPG TANK
|
|
Working Pressure
|
MPa
|
1.63
|
|
Design Pressure
|
MPa
|
1.77
|
|
Max.allowance working pressure
|
MPa
|
1.82
|
|
Working Temperature
|
℃
|
-19~50
|
|
Design Temperature
|
℃
|
-20/54
|
|
Medium of LPG Tank
|
|
LPG (Propane)
|
|
Density of Medium
|
kg/m3
|
560
|
|
Main Material
|
|
Q345R
|
|
Filling Ratio
|
|
0.9
|
|
Setting Pressure of Safety Valve
|
MPa
|
1.82
|
|
Design Life
|
|
20 Years
|
|
Heat Treatment
|
|
Post-weld heat treatment for LPG Tank
|
|
Hydrostatic test pressure
|
MPa
|
2.28
|
|
Air tightness test pressure
|
MPa
|
1.77
|
|
Design, Manufacturing and Inspection Standard
|
|
GB150/ASME for LPG TANK
|
