Quick Details
-
Marketing Type:
-
New Product 2024
-
Usage:
-
inverter busbar bend stamp machine
-
Color:
-
Grey and red
-
Spinner:
-
2.0 KW*2
-
Arm Axis:
-
2.0 KW*3
-
Feature:
-
CUT/STAMP/BEND 3IN1
-
Model No.:
-
US-TP35-6
-
Axis Qty:
-
8
-
Keyword:
-
INVERTER BUS BAR BENDING
-
key words:
-
INVERTER BUS BAR STAMPING
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Union Spring
-
Weight (KG):
-
3000
-
Marketing Type:
-
New Product 2024
-
Usage:
-
inverter busbar bend stamp machine
-
Color:
-
Grey and red
-
Spinner:
-
2.0 KW*2
-
Arm Axis:
-
2.0 KW*3
-
Feature:
-
CUT/STAMP/BEND 3IN1
-
Model No.:
-
US-TP35-6
-
Axis Qty:
-
8
-
Keyword:
-
INVERTER BUS BAR BENDING
-
key words:
-
INVERTER BUS BAR STAMPING
Products Description
|
Model NO.
|
US-TP35-6
|
|
Busbar Range
|
W: 10.0-35.0 mm T: 2.0-6.0 mm
|
|
Axis
|
8 sets
|
|
Punching Axis
|
7.5KW
|
|
Wire Feeding Axis
|
2.7KW
|
|
Spinner Axis
|
2.0KW*2
|
|
Arm Axis
|
2.0KW*3
|
|
Dimension
|
2600*2000*2100mm
|
|
Weight
|
2500KW
|
US-TP35-6 Busbar Cutting Stamping Bending Machine
1. Simple version style
2. Cutting, Stamping, and Bending 3 in 1, one machine can make 3 steps
3. Simple and efficient straightening device
4. Cost effective and easy to operate, friendly customer style
Details Images
1、Automatic wire decoiler
The automatic wire feeder adopts Japanese Panasonic inverter control technology, which has the characteristics of accurate wire feeding, automatic adjustment of wire feeding speed, automatic alarm shutdown, and novel appearance.
2、Transformer
Transformer can be used for direct voltage conversion in different countries, the standard is 220V to 380V Customized
3、Straightener
The straightening device ensures that the steel wire after straightening has no internal stress and the
steel wire is smooth, which facilitates the subsequent processing work.
4、Machine panel
The eight slides work together, the assembly precision of the parts is high, and the machine runs for a long time.
5、Sanyo motor
Japan imported Sanyo Electric .Features: high precision motor, good stability, maintenance free, long use time
