Quick Details
-
Range of Spindle Speed(r.p.m):
-
50 - 2000 r.p.m
-
Max. Turned Length (mm):
-
500 mm
-
Spindle Motor Power(kW):
-
1
-
Year:
-
new date
-
Place of Origin:
-
Shandong,China
-
Brand Name:
-
Matsumoto
-
Model Number:
-
JYP250VF
-
Voltage:
-
custom's requirment
-
Dimension(L*W*H):
-
1455*640*930mm
-
Weight (KG):
-
220 KG
-
Marketing Type:
-
Ordinary Product
-
Machinery Test Report:
-
Provided
-
Video outgoing-inspection:
-
Provided
-
Warranty of core components:
-
3 years
-
ITEM:
-
JYP250VF
-
Distance between centers:
-
500/750 mm
-
Swing over bed:
-
250 mm
-
Swing over cross slide:
-
145 mm
-
Spindle bore:
-
26 mm
-
Taper of spindle bore:
-
MT4
-
Cross slide travel:
-
115 mm
-
Top compound travel:
-
60 mm
-
Range of metric threads:
-
0.2-3.5 mm,18 kinds
-
Range of inch threads:
-
8-56 T.P.I,18 kinds
Quick Details
-
Max. Length of Workpiece (mm):
-
500
-
Machining Capacity:
-
Light Duty
-
Spindle Bore(mm):
-
26
-
Range of Spindle Speed(r.p.m):
-
50 - 2000 r.p.m
-
Max. Turned Length (mm):
-
500 mm
-
Spindle Motor Power(kW):
-
1
-
Year:
-
new date
-
Place of Origin:
-
Shandong,China
-
Brand Name:
-
Matsumoto
-
Model Number:
-
JYP250VF
-
Voltage:
-
custom's requirment
-
Dimension(L*W*H):
-
1455*640*930mm
-
Weight (KG):
-
220 KG
-
Marketing Type:
-
Ordinary Product
-
Machinery Test Report:
-
Provided
-
Video outgoing-inspection:
-
Provided
-
Warranty of core components:
-
3 years
-
ITEM:
-
JYP250VF
-
Distance between centers:
-
500/750 mm
-
Swing over bed:
-
250 mm
-
Swing over cross slide:
-
145 mm
-
Spindle bore:
-
26 mm
-
Taper of spindle bore:
-
MT4
-
Cross slide travel:
-
115 mm
-
Top compound travel:
-
60 mm
-
Range of metric threads:
-
0.2-3.5 mm,18 kinds
-
Range of inch threads:
-
8-56 T.P.I,18 kinds
Product Description
Specification
Features
Supersonic frequency hardened bed way.
Spindle speed readout.
Variable Speed.
Precision roller bearing for spindle.
High quality steel, ground and hardened gear inside headstock.
Various threads cutting function available.
Supersonic frequency hardened bed way.
Spindle speed readout.
Variable Speed.
Precision roller bearing for spindle.
High quality steel, ground and hardened gear inside headstock.
Various threads cutting function available.
|
MODEL
|
JYP250VF
|
|
|
Distance between centers
|
500/750 mm
|
|
|
Swing over bed
|
250 mm
|
|
|
Swing over cross slide
|
145 mm
|
|
|
Spindle bore
|
26 mm
|
|
|
Taper of spindle bore
|
MT4
|
|
|
Cross slide travel
|
115 mm
|
|
|
Top compound travel
|
60 mm
|
|
|
Range of metric threads
|
0.2-3.5 mm,18 kinds
|
|
|
Range of inch threads
|
8-56 T.P.I,18 kinds
|
|
|
Range of longitudinal feed
|
0.08-0.48mm/r
|
|
|
Range of cross feed
|
0.026-0.156 mm/r
|
|
|
Number of spindle speeds
|
Variable
|
|
|
Range of spindle speeds
|
50-2000 rpm
|
|
|
Tailstock quill travel
|
70 mm
|
|
|
Tailstock quill Taper
|
MT2
|
|
|
Motor
|
1kw
|
|
|
Packing size
|
1455/1500x640x930 mm
|
|
|
Weight
|
220kg(240kg)
|
|
|
Mill & drill
|
|
|
|
Max.drilling dia
|
16mm
|
|
|
Max.end milling capacity
|
16mm
|
|
|
Max.face milling capacity
|
52mm
|
|
|
Spindle travel
|
50mm
|
|
|
T slot width
|
10mm
|
|
|
Spindle speed
|
50-2250 rpm,variable
|
|
|
Motor
|
600W
|
|
Company Profile
SHANDONG MATSUMOTO MACHINE TOOL CO., LTD is a professional m
anufacturer
.Except domestic market,our cnc machines exported to Europe, the United States, Southeast Asia and other countries and regions. In order to provide customers the best service, what your requests, including the spare parts posting requests, quality modifying , price inquiry, delivery time checking, we will try our best to feed back within 24 hours.
The history of company development,in 1993, the company and Japan Akimoto Co., Ltd. technical cooperation,set up Matsumoto Machinery Factory, the production of automatic and semi-automatic machine tools.In 1994, the company cooperated with Japan Akimoto Co., Ltd. to produce high precision and high speed spindle.In September 2004, due to government demolition, the company moved to Tengzhou Industrial Park, Shandong Province, established Matsumoto Machine Tool Factory, specializing in the manufacture of precision machine tools. In 2020, due to the change of equity, the company was renamed as Shandong Matsumoto Machine Tool Co., Ltd.
Companies adhere to the "customer first, forge ahead" business philosophy and adhere to the "continuous innovation, customer satisfaction" quality policy,to provide our customers with quality services.
SHANDONG MATSUMOTO MACHINE TOOL CO., LTD looks forward to long-term cooperation with you for common development and achieving a win-win situation!
