Quick Details
-
Brand Name:
-
SRNE
-
Model Number:
-
MC2450N10
-
Work Time (h):
-
24 Hours
-
Max PV Power:
-
1320W
-
Max PV Voltage:
-
100V
-
Certificate:
-
CE/ISO9001/ETL
-
Warranty:
-
3Years
-
System voltage:
-
12V/24V
-
Battery voltage:
-
9V~32V
-
Maximum PV open circuit voltage:
-
92V(25℃);100V(Lowest ambient temperature)
-
Rated charging current:
-
50A
-
Maximum PV input power:
-
660W/12V 1320W/24V
-
Operating temperature:
-
-35℃ ~ +45℃
-
IP rating:
-
IP32
-
Net Weight:
-
1335g
-
Communication mode:
-
TTL Serial communication
-
Dimensions(mm):
-
183*127*69.5
Quick Details
-
Type:
-
MPPT
-
Application:
-
Charger Controller, Collector Controller, Solar Working Station, Lighting Controller, Voltage Controller, Solar System Controller
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SRNE
-
Model Number:
-
MC2450N10
-
Work Time (h):
-
24 Hours
-
Max PV Power:
-
1320W
-
Max PV Voltage:
-
100V
-
Certificate:
-
CE/ISO9001/ETL
-
Warranty:
-
3Years
-
System voltage:
-
12V/24V
-
Battery voltage:
-
9V~32V
-
Maximum PV open circuit voltage:
-
92V(25℃);100V(Lowest ambient temperature)
-
Rated charging current:
-
50A
-
Maximum PV input power:
-
660W/12V 1320W/24V
-
Operating temperature:
-
-35℃ ~ +45℃
-
IP rating:
-
IP32
-
Net Weight:
-
1335g
-
Communication mode:
-
TTL Serial communication
-
Dimensions(mm):
-
183*127*69.5
Product Description
Specification
|
item
|
value
|
|
Place of Origin
|
China
|
|
|
Guangdong
|
|
Brand Name
|
SRNE
|
|
Model Number
|
MC2450N10
|
|
Type
|
MPPT
|
|
Application
|
Charger Controller, Collector Controller, Solar Working Station, Lighting Controller, Voltage Controller, Solar System Controller
|
|
Work Time (h)
|
24 Hours
|
|
Max PV Power
|
1320W
|
|
Max PV Voltage
|
100V
|
|
Certificate
|
CE/ISO9001/ETL
|
|
Warranty
|
3Years
|
|
System voltage
|
12V/24V
|
|
Battery voltage
|
9V~32V
|
|
Maximum PV open circuit voltage
|
92V(25℃);100V(Lowest ambient temperature)
|
|
Rated charging current
|
50A
|
|
Maximum PV input power
|
660W/12V
1320W/24V |
|
Operating temperature
|
-35℃ ~ +45℃
|
|
IP rating
|
IP32
|
|
Net Weight
|
1350g
|
|
Communication mode
|
TTL Serial communication
|
|
Dimensions(mm)
|
150*105.6*61.5
|
Packing & Delivery
carton box
