HAC-B1A21
2MP HDCVI IR Bullet Camera
> Max. 30fps@1080P
> HD and SD output switchable
> 3.6mm fixed lens (2.8mm, 6mm optional)
> Max. IR length 20m, Smart IR
> IP67, DC12V
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Dahua
-
Model Number:
-
HAC-T1A21
-
Product name:
-
4 IN 1 1080P 2MP Mini CCTV Camera
-
Resolution:
-
1920 x 1080
-
IR Distance:
-
20m
-
Lens:
-
2.8 mm; 3.6 mm; 6 mm
-
Video Output:
-
BNC port
-
switchable:
-
CVI/CVBS/AHD/TVI
-
Casing Material:
-
Plastic
-
WDR:
-
DWDR
-
Day/Night:
-
Auto(ICR)/Color/B/W
Quick Details
-
Special Features:
-
NIGHT VISION, Waterproof / Weatherproof
-
Function:
-
Waterproof / Weatherproof
-
Customized support:
-
Online technical support, Customized logo, OEM, ODM
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Dahua
-
Model Number:
-
HAC-T1A21
-
Product name:
-
4 IN 1 1080P 2MP Mini CCTV Camera
-
Resolution:
-
1920 x 1080
-
IR Distance:
-
20m
-
Lens:
-
2.8 mm; 3.6 mm; 6 mm
-
Video Output:
-
BNC port
-
switchable:
-
CVI/CVBS/AHD/TVI
-
Casing Material:
-
Plastic
-
WDR:
-
DWDR
-
Day/Night:
-
Auto(ICR)/Color/B/W
Hot Sale Cooper Series 1080P Full HD Mini Bullet Analog HDCVI Camera HAC-B1A21
Products Description
Product Paramenters
|
Camera
|
|
|
|
Image Sensor
|
2 MP CMOS
|
|
|
Max. Resolution
|
1920 (H) × 1080 (V)
|
|
|
Scanning System
|
Progressive
|
|
|
Electronic Shutter Speed
|
PAL: 1/25 s–1/100000 s
|
|
|
|
NTSC: 1/30 s–1/100000 s
|
|
|
Min. Illumination
|
0.02 lux@F2.0 (Color, 30 IRE)
|
|
|
|
0.002 lux@F2.0 (B/W, 30 IRE)
|
|
|
|
0 lux (Illuminator on)
|
|
|
S/N Ratio
|
>65 dB
|
|
|
Illumination Distance
|
20 m (65.62 ft)
|
|
|
Illuminator On/Off Control
|
Auto
|
|
|
Illuminator Number
|
1 (IR light)
|
|
|
Angle Adjustment
|
Pan: 0°–360°
|
|
|
|
Tilt: 0°–78°
|
|
|
|
Rotation: 0°–360°
|
|
|
Lens
|
|
|
|
Lens Type
|
Fixed-focal
|
|
|
Lens Mount
|
M12
|
|
|
Focal Length
|
2.8 mm; 3.6 mm; 6 mm
|
|
|
Max. Aperture
|
F2.0
|
|
|
Field of View
|
2.8 mm: H: 100°; V: 54°; D: 117°
|
|
|
|
3.6 mm: H:80°; V: 43°; D: 94°
|
|
|
|
6 mm: H: 43°; V: 24°; D: 50°
|
|
|
Iris Control
|
Fixed
|
|
|
Close Focus Distance
|
2.8 mm: 0.5 m (1.64 ft)
|
|
|
|
3.6 mm: 0.8 m (2.62 ft)
|
|
|
|
6 mm: 2.8 m (9.19 ft)
|
|
|
DORI Distance
|
Lens
|
|
|
|
2.8 mm
|
|
|
|
|
|
|
|
3.6 mm
|
|
|
|
|
|
|
|
6 mm
|
|
|
|
|
|
|
Video
|
|
|
|
Video Frame Rate
|
CVI:
|
|
|
|
PAL: 1080p@25 fps
|
|
|
|
NTSC: 1080p@30 fps
|
|
|
|
AHD:
|
|
|
|
PAL: 1080p@25 fps
|
|
|
|
NTSC: 1080p@30 fps
|
|
|
|
TVI:
|
|
|
|
PAL: 1080p@25 fps
|
|
|
|
NTSC: 1080p@30 fps
|
|
|
|
CVBS:
|
|
|
|
PAL: 960H;
|
|
|
|
NTSC: 960H
|
|
|
Resolution
|
1080p (1920 × 1080); 960H (960 × 576/960 × 480)
|
|
|
Day/Night
|
Auto(ICR)/Color/B/W
|
|
|
BLC
|
BLC; DWDR
|
|
|
WDR
|
DWDR
|
|
|
White Balance
|
Auto
|
|
|
Gain Control
|
Auto
|
|
|
Noise Reduction
|
2D NR
|
|
|
Illumination Mode
|
Smart IR
|
|
|
Certification
|
|
|
|
Certifications
|
CE-LVD: EN 62368-1;
|
|
|
|
CE-EMC: EN 55032; EN 55035;
|
|
|
|
FCC: 47 CFR FCC Part 15, Subpart B
|
|
|
Port
|
|
|
|
Video Output
|
Video output choices of CVI/TVI/AHD/CVBS by one
|
|
|
|
BNC port
|
|
|
Power
|
|
|
|
Power Supply
|
12 VDC ± 30%
|
|
|
Power Consumption
|
Max 2.3 W (12 VDC, IR on)
|
|
|
Environment
|
|
|
|
Operating Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
|
Operating Humidity
|
<95% (RH), non-condensing
|
|
|
Storage Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
|
Storage Humidity
|
<95% (RH), non-condensing
|
|
|
Anti-corrosion Level
|
Basic Protection
|
|
|
Structure
|
|
|
|
Casing Material
|
Plastic
|
|
|
Product Dimensions
|
Φ85.4 mm × 68.8 mm (Φ3.36" × 2.71")
|
|
|
Net Weight
|
0.09 kg (0.20 lb)
|
|
|
Gross Weight
|
0.13 kg (0.29 lb)
|
|
|
Installation
|
Wall mount; ceiling mount; vertical pole mount
|
|
