48V/51.2V 50-200AH
2.56-10.24KWH
2.56-10.24KWH
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Sunpal
-
Model Number:
-
WallArk
-
Battery Size:
-
48V 50-200AH
-
Place of Origin:
-
Anhui, China
-
Weight:
-
29-92kg
-
Nominal Voltage:
-
48V
-
Capacity Ah:
-
50-200AH
-
Capacity Energy:
-
2.56-10.24KWH
-
Maximum Charging Current:
-
0.7C
-
Maximum Discharging Current:
-
1C
-
BMS:
-
Built-in
-
Life Cycling (0.5C 25℃):
-
6000 cycles @ 0.5C
-
Warranty:
-
10 Year, 10YEARS
-
Certification:
-
MSDS, UN38.3, ROHS, IEC62619, CE
-
IP Class:
-
IP54
Quick Details
-
Storage Type:
-
-20°C~45°
-
Anode Material:
-
LFP
-
Application:
-
Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, Electric Folklifts, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies
-
Brand Name:
-
Sunpal
-
Model Number:
-
WallArk
-
Battery Size:
-
48V 50-200AH
-
Place of Origin:
-
Anhui, China
-
Weight:
-
29-92kg
-
Nominal Voltage:
-
48V
-
Capacity Ah:
-
50-200AH
-
Capacity Energy:
-
2.56-10.24KWH
-
Maximum Charging Current:
-
0.7C
-
Maximum Discharging Current:
-
1C
-
BMS:
-
Built-in
-
Life Cycling (0.5C 25℃):
-
6000 cycles @ 0.5C
-
Warranty:
-
10 Year, 10YEARS
-
Certification:
-
MSDS, UN38.3, ROHS, IEC62619, CE
-
IP Class:
-
IP54
Product Description
Specification
|
Model
|
WallArk-2500
|
WallArk-5000
|
WallArk-7500
|
WallArk-10K
|
|||
|
Capacity Energy
|
2.56kWh
|
5.12kWh
|
7.68kWh
|
10.24kWh
|
|||
|
Capacity Ah
|
50Ah
|
100Ah
|
150Ah
|
200Ah
|
|||
|
Suggested SOC
|
10-100%
|
|
|
|
|||
|
Usable Capacity
|
2.3kWh
|
4.6kWh
|
6.9kWh
|
9.2kWh
|
|||
|
Nominal Voltage
|
48/51.2V
|
|
|
|
|||
|
Operation Voltage
|
42V - 54V (48V) or 44.8V – 57.6V (51.2V)
|
|
|
|
|||
|
Maximum Charging Current
|
35A
|
70A
|
70A
|
150A
|
|||
|
Maximum Discharging Current
|
50A
|
100A
|
100A
|
200A
|
|||
|
BMS
|
Robust Multi Point Monitoring BMS
|
|
|
|
|||
|
Scalable(Parallel Function)
|
Yes, Maximum 15 Packs
|
|
|
|
|||
|
Life Cycling (0.5C 25℃)
|
6000 Cycles @ 0.5C
|
|
|
|
|||
|
Warranty
|
10 Years
|
|
|
|
|||
|
Operation Temperature
|
Chrage : 0 ~ 45℃, Dischrage : -20 ~ 45℃
|
|
|
|
|||
|
Storage Temperature
|
-20 ~ 45℃
|
|
|
|
|||
|
Net Weight
|
29kG
|
52kG
|
66kG
|
92kG
|
|||
|
Dimensions (H x W x D)
|
350x520x165 mm
|
480x520x165mm
|
560x537x174mm
|
866x537x174mm
|
|||
|
Certifications
|
MSDS, UN38.3, RoHS, IEC62619, CE
|
|
|
|
|||
|
IP Grade
|
IP54
|
|
|
|
|||
|
Communication
|
RS232, RS485, CAN (Compitable with most brand inverters in market)
|
|
|
|
|||
Product Details Images
Products Series
Wall Mounted Battery Solution
Ground Mounted Battery Solution
Voltage 51.2V
2.6-10.4KWH
2.6-10.4KWH
Stack Mounted High Voltage Battery Solution
Voltage 260-350V
8KWH-20KWH
8KWH-20KWH
Compatiable Inverters
|
Type
|
Single Phase
|
3 Phase
|
Split Phase
|
||
|
Output Power
|
3-16KW
|
5-30KW
|
5-8KW
|
||
|
Output Voltage
|
220/230/240V
|
220/380V, 230/400
|
120/240V
|
||
|
Battery Type
|
Lead Acid or Lithium Ion 40-60V
|
|
|
||
