Quick Details
-
Jacket:
-
PVC
-
Place of Origin:
-
Hebei, China
-
Standards:
-
IEC,BS,VDE,AS/NZS,ICEA
-
Core:
-
1~5
-
Conductor Type:
-
Stranded
-
Conductors:
-
Copper/Aluminum
-
Capacity:
-
5000km/month
-
Max. Service Temperature:
-
90 Celsius Degree
-
Voltage Rating:
-
Low, Medium Voltage
-
Certification:
-
ISO 9001, ISO14001, SABS etc
-
Product:
-
4 core 35mm2 copper cable
Quick Details
-
Insulation Material:
-
Xlpe
-
Application:
-
Underground, Power Transmission
-
Conductor Material:
-
Copper
-
Jacket:
-
PVC
-
Place of Origin:
-
Hebei, China
-
Standards:
-
IEC,BS,VDE,AS/NZS,ICEA
-
Core:
-
1~5
-
Conductor Type:
-
Stranded
-
Conductors:
-
Copper/Aluminum
-
Capacity:
-
5000km/month
-
Max. Service Temperature:
-
90 Celsius Degree
-
Voltage Rating:
-
Low, Medium Voltage
-
Certification:
-
ISO 9001, ISO14001, SABS etc
-
Product:
-
4 core 35mm2 copper cable
3 Core Armoured Cable LV MV Power Cable with Copper Conductor PVC/XLPE Insulation SWA Armoured Power Cable 4 core 35mm2 copper cable
Description
1.The long-time permissible working temperature of cable conductive core is not more than 70 °C.
2.During short circuit (max. permanent time is not more than 5 seconds), the max temperature of cable conductor is not more than 165°C.
3.The difference level of laying cable is not restricted.When laying the cable,ambient temperature is not lower than 0°C.
4.They have good chemical stability,and properties of acid resistance,alkali resistance,salt resistance,oil resistance,solvent resistance and flame resistance.rty
5.Light weight,good bending property and easy installation and maintenance.
Application
With the characteristics of stable capability,advanced technology,broad material resources,low price, good flexible and easy to lay and maintain, the XLPE Insulated and Sheathed Power Cable are suitable to be laid for distribution line with A.C.50HZ and rated voltage up to 35kV.
Standard
IEC,BS,VDE,AS/NZS,ICEA,JIS and so on,designing and manufacturing special power cable according to the other standards required by the customer
Specification
| Number of the core | Model | Specification | Main application | |
| copper conductor | aluminum conductor | |||
| single core and three core |
YJV YJY |
YJLV YJLY |
XLPE insulation PVC or PE sheath power cable | Laying indoor tunnel, cable trench and pipe, can also be buried in loose soil, unable to bear external mechanical pressure , but can withstand a certain amount of traction laying |
| Single core |
YJV62 YJV63 YJY62 YJY63 |
YJLV62 YJLV63 YJLY62 YJLY63 |
XLPE insulation non-magnetic metal tape armored PVC or PE sheath power cabe | Laying indoor, tunnel, cable trench and pipelines, can withstand the mechanical exogenous process, but unable to bear large tension |
| Three cores |
YJV22 YJV23 YJY22 YJY23 |
YJLV22 YJLV23 YJLY22 YJLY23 |
XLPE insulation steel tape armored PVC or PE sheath power cable | |
| Single core |
YJV72 YJV73 YJY72 YJY73 |
YJLV72 YJLV73 YJLY72 YJLY73 |
XLPE insulation non-magnetic metal wire armored PVC or PE sheath power cable | Laying in the shaft, water and under theconditions of the occasion with drop, cable can withstand mechanical exogenous process an considerable tension |
| Three cores |
YJV32 YJV33 YJY32 YJY33 |
YJLV32 YJLV33 YJLY32 YJLY33 |
XLPE insulation thin steel wire armored PVC or PE sheath power cable | |
| Three cores |
YJV42 YJV43 YJY42 YJY43 |
YJLV42 YJLV43 YJLY42 YJLY43 |
XLPE insulation thick steel wire armored PVC or PE sheath power cable | Laying in the water, sea, larger fall and the places need across, the thick steel wire armored cable can withstand greater tension than the thin |
| type | core No | voltage(KV) | ||||
| 0.6/1.0 | 3.6/6 6/6 | 6/10 8.7/10 | 8.7/15 12/20 | 18/20 21/35 26/35 | ||
| conductor norminal area mm2 | ||||||
| YJV YJV32(42) | 1 | 1.5-30 | 25-630 | 25-630 | 25-400 | 50-500 |
| YJLV YJLV32(42) | 1 | 4-300 | 35-630 | 35-630 | 35-300 | 50-630 |
| YJV22 | 1 | 2.5-300 | 25-500 | 25-500 | 35-500 | |
| YJLV22 | 1 | 4-300 | 35-500 | 35-500 | 35-500 | |
| YJV YJLV | 2 | 1.5-240 | ||||
| YJV22 YJLV22 | 2 | 4-240 | ||||
| YJV YJV22 | 3 | 1.5-240 | 25-300 | 25-300 | 35-300 | 50-300 |
| YJLV YJLV22 | 3 | 4-240 | 35-300 | 35-300 | 35-300 | 50-300 |
| YJV32 YJLV32 | 3 | 25-240 | 25-300 | 35-300 | 35-300 | 50-300 |
| YJV42 YJLV42 | 3 | 50-240 | 35-185 | 35-185 | 35-150 | 50-300 |
| YJV YJLV YJV22 YJLV22 | 3+1 | 2.5-240 | ||||
| YJV YJLV YJV22 YJLV22 | 4 | 2.5-240 | ||||
| YJV YJLV YJV22 YJLV22 | 4+1 | 2.5-240 |
|
1. Rated voltage: Uo/U: 66kV, 26/35kV, 21/35kV, 12/20 kV (24 kV), 8.7/10kV, 8.7/15kV, 6/6kV, 6/10kV.
2. No. of core: Single-core, Three-core etc.
3. The highest allowed operating temperature of conductor for long-term working is 90oC. In short-circuit (Max. Long-term is no more than 5 seconds). The highest temperature for conductor is no more than 250.
4. D.C Resistance of the conductor complies with the stipulations of GB/T3956-1997.
5. The environment temperature should be no lower than 0 when lay. Otherwise it should be preheated.
6.The cable is laid without horizontal drop limit. The Min. Bending radius of three-core cable should be no smaller than 12 times of cable outer diameter.
7. Working Frequency Voltage Test:.
For cable with Uo of 3.6kV or lower: 2.5Uo+2kV/5min without puncture.
For cable with Uo of 3.6kv~18kV: 3.5Uo/5min without puncture.
For cable with Uo of 21kV and 26 kV: 2.5Uo/30min without puncture.
8. Partial Discharge Test: The discharge volume should be no more than 10pC under 1.73Uo for the cable.
Other types available. Please contact for detailed specifications and prices. Our friendly service is aiming at giving you the most efficient buying experience available.
