pure color test
white color test
testing with videos
- Product Details
- {{item.text}}
Quick Details
-
Color:
-
full color
-
Panel Size:
-
320*160mm, 320*160mm
-
Place of Origin:
-
Fujian, China
-
Model Number:
-
P2.5 P2 P3 P4 P5 P6 P8 P10
-
Brightness:
-
≥1000cd/㎡, ≥1000cd/㎡
-
Color Depth:
-
RGB, RGB
-
Lifespan (hours):
-
10000hours, 10000hours
-
IP Rating:
-
65, 65
-
HS Code:
-
8528591090
-
Resolution:
-
1920/3840, 128*128
-
View Angle（H/V）:
-
170/120, 170/120
-
Product name:
-
Rental Led Display Screen
-
Usage:
-
Outdoor Adverting Display
-
LED chip:
-
Nationstar
-
Warranty:
-
2 Years
-
Certificate:
-
CE ROHS FCC
-
Refresh rate:
-
1920Hz-3840Hz
-
Scan mode:
-
1/16S
-
Display Function:
-
Video/Text/Picture/Time/3D Text/Office/SWF
-
Life span:
-
100000hr
Quick Details
-
Application:
-
Outdoor
-
Type:
-
LED
-
Brand Name:
-
HUACAI
-
Color:
-
full color
-
Panel Size:
-
320*160mm, 320*160mm
-
Place of Origin:
-
Fujian, China
-
Model Number:
-
P2.5 P2 P3 P4 P5 P6 P8 P10
-
Brightness:
-
≥1000cd/㎡, ≥1000cd/㎡
-
Color Depth:
-
RGB, RGB
-
Lifespan (hours):
-
10000hours, 10000hours
-
IP Rating:
-
65, 65
-
HS Code:
-
8528591090
-
Resolution:
-
1920/3840, 128*128
-
View Angle（H/V）:
-
170/120, 170/120
-
Product name:
-
Rental Led Display Screen
-
Usage:
-
Outdoor Adverting Display
-
LED chip:
-
Nationstar
-
Warranty:
-
2 Years
-
Certificate:
-
CE ROHS FCC
-
Refresh rate:
-
1920Hz-3840Hz
-
Scan mode:
-
1/16S
-
Display Function:
-
Video/Text/Picture/Time/3D Text/Office/SWF
-
Life span:
-
100000hr
Fujian Huacai Electronic Technology Co.,Ltd
Indoor & Outdoor LED Display Screen
full color, single color,rental, flexible, cube customised
Product Description
|
Product Name
|
P2.5
|
P3.0
|
P4
|
P5
|
P6
|
P8
|
P10
|
||||||
|
Pixel spacing (mm)
|
2.5
|
3.07
|
4
|
5
|
6.6
|
8
|
10
|
||||||
|
Panel size (mm)
|
320x160
|
320x160
|
320x160
|
320x160
|
320x160
|
320x160
|
320x160
|
||||||
|
Panel resolution (Pixel)
|
128*64
|
104*52
|
80*40
|
64*32
|
48*24
|
40*20
|
32*16
|
||||||
|
Lamp tube model
|
1515
|
1515
|
1921
|
1921
|
3535
|
3535
|
3535
|
||||||
|
Panel weight (Kg)
|
0.5
|
0.41
|
0.5
|
0.48
|
0.48
|
0.48
|
0.48
|
||||||
|
Box size (W * H * D)
|
960*960*90mm
|
|
|
|
|
|
|
||||||
|
Box resolution (Pixel)
|
384*384
|
312*312
|
240*240
|
192*192
|
144*144
|
120*120
|
96*96
|
||||||
|
Box weight (Kg)
|
25
|
|
|
|
|
|
|
||||||
|
Maintenance method
|
back maintenance
|
|
|
|
|
|
|
||||||
|
Protection level
|
IP65
|
|
|
|
|
|
|
||||||
|
Brightness (cd/m ³)
|
≥4000
|
≥4500
|
≥4500
|
≥5000
|
≥5000
|
≥5000
|
≥5000
|
||||||
|
Horizontal perspective
|
≥140
|
|
|
|
|
|
|
||||||
|
Vertical perspective
|
≥100
|
|
|
|
|
|
|
||||||
|
Color temperature (k)
|
11000-14000
|
|
|
|
|
|
|
||||||
|
Best Sight Distance (m)
|
3.8
|
4.5
|
6
|
7.5
|
8.5
|
10
|
12
|
||||||
|
working voltage（V）
|
4.5V
|
|
|
|
|
|
|
||||||
|
Refresh frequency (Hz)
|
1920/3840/7680
|
|
|
|
|
|
|
||||||
|
Gray level (Bit)
|
12~14
|
|
|
|
|
|
|
||||||
|
Maximum power consumption (W/㎡)
|
≤1000
|
≤1000
|
≤1000
|
≤1000
|
≤1000
|
≤1000
|
≤1000
|
||||||
|
Average power consumption (W/㎡)
|
≤300
|
≤300
|
≤300
|
≤300
|
≤300
|
≤300
|
≤300
|
||||||
|
Working temperature ℃
|
-20°C~+50°C
|
|
|
|
|
|
|
||||||
|
Working humidity
|
10~90% RH (without condensation)
|
|
|
|
|
|
|
||||||
|
working life
|
100000h
|
|
|
|
|
|
|
||||||
Production process
why choose us
high quality
higher gray scala
higher contrast
new upgrade
more options
more advantages
clean and standard operating environment
black color test
safe packaging
High praise from clients
Cooperation cases
Certification
FAQ
1. Is the product costomisable?
6.What's your payment term?
T/T,Western Union,Alibaba trade assurance
7.What's the brand of your diode chip?
Our led lamps are by Nationstar, kinglight, Sanan, Epistar ect.
Yes, we can customize the product according to customers' needs, you just need to provide the requirements details.
Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
2. Do you test all your goods before delivery?
Yes, we have 100% test before delivery, we have 72 hours aging test.
3. How about your delivery time?
Generally, it will takes about 10 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
4.Warranty:
24 months, a little investment for longer warranty time.
.5.Where is your nearest Sea Port?
Our nearest sea port is at Xiamen, Fujian Province
Our nearest sea port is at Xiamen, Fujian Province
6.What's your payment term?
T/T,Western Union,Alibaba trade assurance
7.What's the brand of your diode chip?
Our led lamps are by Nationstar, kinglight, Sanan, Epistar ect.
