Quick Details
-
Ejector Force(kN):
-
45 kN
-
Theoretical Shot Volume(cm³):
-
226 cm³
-
Injection Rate (g/s):
-
99 g/s
-
Injection Weight (g):
-
216 g
-
Screw Speed (rpm):
-
0 - 300 rpm
-
Screw diameter (mm):
-
40 mm
-
Weight (KG):
-
8400 kg
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
250 mm
-
Model Number:
-
ZSJ-850R2ton
-
Brand Name:
-
Carst
-
Power (kW):
-
11 kW
-
Screw diameter:
-
32/36/40mm
-
Theoretical injectionvolume:
-
144.7/183/226cm³
-
Injection weight(PS):
-
138/175/216g(oz)
-
Max.(kgf/cm²):
-
229/181/146kgf/cm²
-
Injection Rate:
-
63.5/80.4/99cm³/s
-
Injection speed:
-
79mm/s
-
Injection stroke:
-
180mm
-
Screw speed rotation:
-
0-300 r.p.m
-
Min.Mold thickness:
-
230/330mm
-
Max.Mould size:
-
430*340mm
Quick Details
-
Plasticizing Capacity(g/s):
-
60
-
Mold Height(mm):
-
230 - 330 mm
-
Ejector Stroke(mm):
-
250 mm
-
Ejector Force(kN):
-
45 kN
-
Theoretical Shot Volume(cm³):
-
226 cm³
-
Injection Rate (g/s):
-
99 g/s
-
Injection Weight (g):
-
216 g
-
Screw Speed (rpm):
-
0 - 300 rpm
-
Screw diameter (mm):
-
40 mm
-
Weight (KG):
-
8400 kg
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
250 mm
-
Model Number:
-
ZSJ-850R2ton
-
Brand Name:
-
Carst
-
Power (kW):
-
11 kW
-
Screw diameter:
-
32/36/40mm
-
Theoretical injectionvolume:
-
144.7/183/226cm³
-
Injection weight(PS):
-
138/175/216g(oz)
-
Max.(kgf/cm²):
-
229/181/146kgf/cm²
-
Injection Rate:
-
63.5/80.4/99cm³/s
-
Injection speed:
-
79mm/s
-
Injection stroke:
-
180mm
-
Screw speed rotation:
-
0-300 r.p.m
-
Min.Mold thickness:
-
230/330mm
-
Max.Mould size:
-
430*340mm
Product Description
Specification
|
item
|
value
|
|
Model Number
|
ZSJ-850R2 ton
|
|
Brand Name
|
Carst
|
|
Plastic Processed
|
PP, PC, ABS, PET, PVC, FRPP/PVC, PPR, EVA, HDPE, MLLDPE, EPS, PA, Polystyrene, PE, LDPE, EVOH, HDPE/PP, ABS/PP, PE/PP, Polylactic Acid
|
|
Condition
|
New
|
|
Style
|
VERTICAL
|
|
Screw Diameter
|
32/36/40mm
|
|
Theoretical Injection Volume
|
144.7/183/226cm3
|
|
Injection Weight(PS)
|
138/175/216 g(oz)
|
|
Max.Injection Pressure
|
229/181/146Mpa(kgf/cm2)
|
|
Injection Rate
|
63.5/80.4/99cm3/s
|
|
Injection Speed
|
79mm/s
|
|
Injection Stroke
|
180mm
|
|
Screw Speed Rotation
|
0-300r.p.m
|
|
No.of Temperature control
|
3+1
|
|
Nozzle Out From Platens
|
≥45mm
|
|
Clamping Force
|
833(85)KN(tf)
|
|
Clamping Stroke
|
250mm
|
|
Min.Mold Thickness
|
230/330mm
|
|
Max.Opening
|
480/580mm
|
|
（L*W)Distance Between Tie Bars
|
--
|
|
（L*W)Max.Mould Size
|
300*340/430*300mm
|
|
（D） Rotary Table Size
|
980mm
|
|
Ejector Distance
|
100mm
|
|
Ejector Force
|
45(4.6)KN(tf)
|
|
System Pressure
|
13.7(140)Mpa(kgf/cm2)
|
|
Oil Tank Capacity
|
310L
|
|
Electric Power
|
11（15）/15（20）KW(HP)
|
|
Heater Power
|
6.4KW
|
|
Machine Dimensions
|
2.2*1.8*3.6m
|
|
Machine Weight
|
4.2tf
|
|
Key Selling Points
|
High-accuracy
|
|
Applicable Industries
|
Manufacturing Plant, Other, Advertising Company
|
|
Showroom Location
|
None
|
|
Marketing Type
|
Ordinary Product
|
|
Machinery Test Report
|
Provided
|
|
Video outgoing-inspection
|
Provided
|
|
Warranty of core components
|
1 Year
|
