Quick Details
-
Place of Origin:
-
Anhui, China
-
Engine:
-
Chinese engine & CUMMINS engine
-
Tire:
-
Pneumatic / solid Tire
-
Self Weight:
-
21 ton
-
Color:
-
Customer Demanded
-
Load Center:
-
600 mm
-
Mast:
-
2 / 3 stages
-
Turning Radius:
-
5800 mm
-
Travel speed (Unload):
-
30 Km/h
-
Lifting speed:
-
300 mm/h
Quick Details
-
Max. Lifting Height:
-
6 m
-
Min. Lifting Height:
-
3.5 m
-
Warranty:
-
1 Year
-
Place of Origin:
-
Anhui, China
-
Engine:
-
Chinese engine & CUMMINS engine
-
Tire:
-
Pneumatic / solid Tire
-
Self Weight:
-
21 ton
-
Color:
-
Customer Demanded
-
Load Center:
-
600 mm
-
Mast:
-
2 / 3 stages
-
Turning Radius:
-
5800 mm
-
Travel speed (Unload):
-
30 Km/h
-
Lifting speed:
-
300 mm/h
Best advantages:
1. Full automatic stepless speed adjustable electric controlled transmission gear box guarantee the forklift with superior travel and track performance.
2. New type engine with super power has features of good performance,low fuel consumption,enough power reservation,EPA standard displacement level.
3. Advanced hydraulic system ,2-speed lifting system can automatically adjust its lifting speed according to the goods weight ,electric controlled valve can work safety and efficiently.
4. Eqiupment with heavy-duty driving axle with big bearing capacity and enhanced oil-cooled braking system, increase the reliabillgy and durability.
5. Equipments with fine safety monitor to make it has clear visibility, 3-step switch-lock confirmation device to guarantee safe work.
6. Centralize controlled lever and stimulant automatic instrument is easy operated and has beautiful appearance.
7. High strength mast of CJ shape welded by refined steel, has features of high strength and rigid .Sweden “H” typed ELME spreader up to advanced international level, enhance its operation and reliability.
8. New cabin has comfort windows and wide view, with air conditioner can modify the operative circumstance.
9. The whole truck has advanced technology, beautiful, appearance, reasonable layout, is the best new model.
| Specification | Model | |||
| CPCD160 | CPCD180 | CPCD200 | ||
| CD-QB | F- | F- | ||
| Load Capacity(kg) | 16000 | 18000 | 20000 | |
| Load Center (mm) | 600 | 900 | ||
| Power Type | Diesel | |||
| Tire Type | Pneumatic | |||
| Lifting Speeds(With Load/Without Load(mm/s) | 270/310 | 240/390 | ||
| Lowering Speeds(With Load/Without Load(mm/s) | <600/>=300 | |||
| Max Driving Speeds(km/h) | 24/26 | 32/34 | ||
| Max Gradebility(%) | 17.5 | |||
| Brake Distance(m) | <=7 | |||
| Wheel (Front/Rear) | 4/2 | |||
| Tire (Front/Rear) | 12.00-20-18PR 12.00-20-18PR | 14.00-24-24PR 14.00-24-24PR | ||
| Weight Distribtion With Load(Front/Rear)(kg) | 30490/3810 | 41400/4610 | 44360/4930 | |
| Weight Distribtion Without Load(Front/Rear)(kg) | 8660/9640 | 14910/13070 | 14060/15230 | |
| Battery Voltange/Capacity(V/Ah) | 2x12/150 | |||
| Service Brake | AIR-BOOST TYPY | |||
| Parking Brake | SHDE-DRUM TYRE | |||
| Internal Combustion Enging Model | Dachai CA6DE1 | Mitsubishi 6D24-E1 | ||
| Internal Combustion Enging Fuel Tank Capacity(L) | 240 | 480 | ||
| Transmission Number Of Speed Fwd/Rvs-Rype | Mechanical | ELECTRIC-SHIFT | ||
| Total Weight(KG) | 18300 | 28010 | 29290 | |
