Quick Details
-
Circulation Type:
-
Direct / Open Loop (Active)
-
Capacity:
-
300
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
FORTES
-
Model Number:
-
FT-NP150
Quick Details
-
Warranty:
-
3 years
-
Application:
-
Hotel, Commercial, Household
-
Type:
-
Evacuated Tube
-
Circulation Type:
-
Direct / Open Loop (Active)
-
Capacity:
-
300
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
FORTES
-
Model Number:
-
FT-NP150
Non-Pressurized Solar Hot Water Heating Solar Water Heater (etc-20) Evacuated Tube Solar Collector Geyser
Features:
1. Cheap and reliable solution, Simple structures, Easy installation.
2. High efficiency of heating,water heated by sun light directly.
3. Withstands water pressure no more than 0.1MPa.
4. Operated without any power supplying.
5. Electric heater can be used as back-up in rainy days.
6. Hot water can be used directly, or can be used as a pre-heated.
7. Water flow in the vacuum tubes and is operated when confined.
8. Tank is equiped with electric water heater setting,automatic temperature controller(optional ).
9. the insulating layer uses polyurethane bulk bubble,keep hot water 72 hours.
Specifications:
1.Inner tank: SUS304-2B,SUS316L,0.31mm,0.4mm,0.5mm
2.Outer tank:Galvanized Steel
3.Tank capacity:80L/100L/120L/150L/180L/200L/240L/250L/300L/320L/360L
4.Vacuum tube:58*1800mm Borosilicate Glass 3.3; Al-Ss-Cu Absorb Coating
5.Stand:Galvanized Steel, 1.5mm; 20-45 degree
6.Insulation layer: 50mm,55mm,60mm
7.Optional accessories : Electric heating, Intelligent controller, Mg. Rod, 3L/5L/8L assistant tank
Remark:
1.Solar hot storage tank diameter(mm): 460mm,470mm,480mm
2.Thickness, insulated(mm): 50/55/60
3.Vent connection(inch):1/2'' or 3/4''
4.Electric heater connection(mm): 47,1/2", 3/4"or 1"
5.Water connection(inch): 1/2'' or 3/4''
6.Collector angle(degree): 20-45 degree
Low Pressure Vacuum Tube Solar Water Heater :
|
Model |
Vacuum Tube |
Capacity
|
Container Loading Sets |
|||
|
Tube Qty |
Tube Size |
20GP |
40HQ |
|
||
|
JNP58/1800-10 |
10 Pcs |
Φ58*1800 MM |
100 L |
76 |
184 |
|
|
JNP58/1800-12 |
12 Pcs |
Φ58*1800 MM |
120 L |
65 |
157 |
|
|
JNP58/1800-15 |
15 Pcs |
Φ58*1800 MM |
150 L |
54 |
130 |
|
|
JNP58/1800-18 |
18 Pcs |
Φ58*1800 MM |
180 L |
45 |
108 |
|
|
JNP58/1800-20 |
20 Pcs |
Φ58*1800 MM |
200 L |
40 |
97 |
|
|
JNP58/1800-25 |
25 Pcs |
Φ58*1800 MM |
250 L |
33 |
81 |
|
|
JNP58/1800-30 |
30 Pcs |
Φ58*1800 MM |
300 L |
27 |
65 |
|
